TABLE OF CONTENTS PARTS AND FEATURES �����������������������������������������������������������������������������������3 Parts and Accessories �������������������������������������������������������������������������������������3 BLENDER SAFETY �������������������������������������������������������������������������������������������4 Important Safeguards �������������������������������������������������������������������������������������4 Electrical Requirements ����������������������������������������������������������������������������������6 Motor Horsepower �����������������������������������������������������������������������������������������6 USING THE BLENDER �������������������������������������������������������������������������������������7 Blender Function Guide ���������������������������������������������������������������������������������7 Preparing the Blender for use ������������������������������������������������������������������������8 Assembling and Running the Blender ������������������������������������������������������������9 CARE AND CLEANING ���������������������������������������������������������������������������������11 TROUBLESHOOTING ������������������������������������������������������������������������������������13 W11382110A.indb 2...
PARTS AND FEATURES PARTS AND ACCESSORIES Ingredient-measuring cap Flex Edge tamper Thermal control blender jar Blade Detachable power cord (not shown) Jar handle with Soft Touch handle grip Power switch (not shown) Removable blender jar pad Control dial Base Pulse toggle switch Start/Stop toggle switch Status indicator light PARTS AND FEATURES | 3...
BLENDER SAFETY IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed, including the following: 1. Read all instructions. Misuse of appliance may result in personal injury. 2. To protect against risk of electrical shock, do not put Blender in water or other liquid.
Page 5
15. Always operate the Blender with the lid in place. 16. The use of attachments not recommended or sold by KitchenAid may cause fire, electric shock, or injury. 17. This appliance is intended to be used in household and similar applications such as: - staff kitchen areas in shops, offices, or other working environments;...
BLENDER SAFETY 18. When blending hot liquids or ingredients, the ingredient-measuring cap should remain in place over the lid opening. Always start on lowest speed and slowly ramp to desired speed when blending hot liquids or ingredients. SAVE THESE INSTRUCTIONS ELECTRICAL REQUIREMENTS Voltage: 220-240 V Frequency: 50-60 HZ...
USING THE BLENDER BLENDER FUNCTION GUIDE The Blender has three preset recipe programmes: Juice, Smoothies, and Soups� It also features Variable Speed and Pulse functions that allow you to customise your blending for any recipe you make� The three preset recipe programmes were each developed based on typical recipes of that kind�...
USING THE BLENDER PREPARING THE BLENDER FOR USE Before first use Before using your Blender for the first time, wipe the blender base with a warm, damp cloth, then wipe clean with a damp cloth� Dry with a soft cloth� Wash the blender jar, lid, Flex Edge tamper, and ingredient-measuring cap in warm, sudsy water (see the “Care and cleaning”...
USING THE BLENDER ASSEMBLING AND RUNNING THE BLENDER Put the items to blend into the Make sure that the lid is fully secured blender jar� Add liquids first, then on the blender jar� Next, place the soft foods, then leafy greens, and blender jar on the base, making sure ice or frozen items last�...
Page 10
USING THE BLENDER Utilise the Flex Edge tamper If desired, use the Pulse function accessory as needed for optimal for a momentary boost of speed blending performance� Remove while blending on the variable the ingredient-measuring cap only, speed settings� and leave the lid in place� Stir or press contents down towards the PRESS AND HOLD the (Pulse)
CARE AND CLEANING CLEANING THE BLENDER AND ACCESSORIES Clean the Blender thoroughly after every use� NOTE: To avoid damaging the Blender, do not immerse the blender base or cord in water� To avoid scratching the Blender, do not use abrasive cleansers or scouring pads�...
Page 12
CARE AND CLEANING Rotate the control dial to the Clean The blender jar, lid, Flex Edge tamper, programme� Flip the (Start/Stop) and ingredient-measuring cap are toggle switch up or down� When the dishwasher-safe; the Flex Edge programme finishes, pour out the tamper, lid, and ingredient-measuring soapy water and rinse the blender jar cap should be placed in the top rack...
TROUBLESHOOTING 3. If the Blender stops while blending: • After 6 minutes of run time, the Blender will automatically shut off and go into Sleep mode, and the LED light will turn off� You can wake the Blender back up using the toggle switches (Start/Stop) or (Pulse High/Pulse Low)�...
Page 20
破壁料理机产品食品接触用信息(Food contact information for product KithchenAid Stand blender) 请根据说明书要求正常使用本产品, 本产品食品接触用材料及部件符合 GB 4806�1-2016和相应食品安全国家标准要求,具体信息如下(Please use this product according to the user guide, food contact material complied with GB 4806�1-2016 and other Nation food safety standards, see below table for details): 用途 (Function)/ 标准...
Page 29
목차 부품 및 기능 ��������������������������������������������������������������������������������������������������30 부품 및 부속품 ����������������������������������������������������������������������������������������������30 블렌더 안전����������������������������������������������������������������������������������������������������31 중요 주의 사항 ����������������������������������������������������������������������������������������������31 전기 요건 ������������������������������������������������������������������������������������������������������33 모터 출력 ������������������������������������������������������������������������������������������������������33 블렌더 사용����������������������������������������������������������������������������������������������������33 블렌더 기능 가이드 ���������������������������������������������������������������������������������������33 블렌더 사용 준비 ������������������������������������������������������������������������������������������35 블렌더 조립 및 가동 ��������������������������������������������������������������������������������������36 관리 및 세척 ��������������������������������������������������������������������������������������������������38 문제...
블렌더 안전 중요 주의 사항 전자 제품 사용 시 항상 다음과 같은 기본 안전 수칙을 준수해야 합니다. 1. 모든 지침을 읽으십시오. 제품을 잘못 사용하면 상해를 입을 수 있습니다. 2. 감전 위험 방지를 위해 블렌더를 물 또는 액체가 있는 곳에 두지 마십시오. 3.
Page 32
14. 뜨거운 음료를 블렌더에 넣을 때는 증기로 인해 음료가 제품 밖으로 튈 수 있으니 조심하십시오. 15. 항상 뚜껑을 덮은 상태로 블렌더를 작동하십시오. 16. KitchenAid 가 권장하거나 판매하지 않은 부속품을 사용하면 화재, 감전 또는 부상을 초래할 수 있습니다. 17. 이 기구는 가정 및 다음 장소에서 사용하기에 적합한...
블렌더 안전 전기 요건 전압: 200 V 주파수: 50-60 HZ 전력(와트): 1800 W 참고: 플러그가 콘센트에 맞지 않으면 전기 기술자에게 문의하십시오. 어떤 형태로든 플러그를 개조하지 마십시오. 어댑터를 사용하지 마십시오. 연장 코드를 사용하지 마십시오. 전원 코드가 너무 짧으면 전기 기술자 또는 서비스...
블렌더 사용 블렌딩 시간 설정 설명 블렌딩 품목 (분:초) 통 과일 또는 채소를 가장 잘 갈무리하여 내용물을 액화하는 주스 몇 가지 속도 변화. 주기의 1:10 과일 채소 마지막에 속도를 늦추면 재료가 가라앉으면서 거품이 줄어듭니다. 잘게 썬 얼린 블렌딩한 점차 최대 출력으로 증가하여 스무디...
Page 35
블렌더 사용 블렌더 사용 준비 처음 사용하는 경우 블렌더를 처음 사용하는 경우에는 먼저 따뜻한 물에 적신 천으로 본체를 닦은 후 젖은 천으로 깨끗하게 닦아 내십시오. 부드러운 천으로 닦아 말리십시오. 블렌더 용기, 뚜껑, 플렉스 엣지 탬퍼, 재료 측정 캡을 따뜻한 비눗물로 씻으십시오('관리 및...
Page 36
블렌더 사용 블렌더 조립 및 가동 블렌딩할 품목을 블렌딩 용기에 블렌더 용기에 뚜껑이 꽉 닫혀 넣으십시오. 음료, 부드러운 음식, 있는지 확인하십시오. 이어서, 블렌더 잎 채소, 얼음이나 얼린 품목 순서로 용기를 본체 위에 놓고 용기 패드와 넣으십시오. 완전히 일치하는지 확인하십시오. 특히 액체를 블렌딩할 때 블렌더 참고: 용기의...
Page 37
블렌더 사용 최적의 블렌딩 성능을 위해 원할 경우 속도 조절 설정으로 필요할 경우 플렉스 엣지 탬퍼를 블렌딩하는 동안 순간 작동 기능을 활용하십시오. 재료 측정 캡만 사용하여 순간적으로 속도를 높일 수 제거하고 뚜껑은 그대로 두십시오. 있습니다. 내용물을 날 쪽으로 휘젓거나 (순간 작동) 토글 스위치를 위로 아래로...
Page 38
관리 및 세척 블렌더와 부속품 세척 사용한 후에는 항상 블렌더를 깨끗히 세척해 주십시오. 참고: 블렌더 고장을 피하려면 본체나 코드를 물에 담그지 마십시오. 블렌더에 흠집이 나지 않도록 하려면 연마 세제나 수세미를 사용하지 마십시오. 매번 사용한 후에 반드시 블렌더 용기, 뚜껑, 재료 측정 캡을 블렌더...
Page 39
문제 해결 3. 작동 중 블렌더가 멈추는 경우: • 6분간 가동된 후 블렌더가 자동으로 꺼지고 절전 모드로 전환되면서 LED 등이 꺼집니다. 토글 스위치 [Start/Stop] 또는 Pulse High/ Pulse Low)를 사용하여 절전 모드를 해제할 수 있습니다. 6분이 되기 전에 전에 블렌더가 멈추는 경우, 블렌더 내부에...
