11.12 Simulation

You can simulate values at inputs and outputs for testing purposes:
• Current values at current outputs
• Measured values at inputs
Diagnostics/Simulation
Function
Current output x:y
Simulation
Current
Alarm relay
Relay x:y
Simulation
State
Meas. inputs
Channel : parameter
Sim. main value
Main value
Sim. temperature
162
Options
Options
• On
• Off
Factory setting
Off
2.4 to 23.0 mA
Factory setting
4 mA
Options
• On
• Off
Factory setting
Off
Options
• Low
• High
Factory setting
Low
Options
• On
• Off
Factory setting
Off
Depends on the sensor
Factory setting
Depends on the sensor
Options
• On
• Off
Factory setting
Off
Info
Simulation of an output current
This menu appears once for each current output.
If you simulate the value at the current output, this is
indicated on the display by a simulation icon in front of
the current value.
Set the desired simulation value.
Simulation of a relay state
This menu appears once for each relay.
If you simulate the relay state, this is indicated on the
display by a simulation icon in front of the relay display.
Set the desired state.
The relay switches in accordance with your setting when
you switch on the simulation. The display shows "On"
(="Low") or "Off" (="High") for the simulated relay state.
Simulation of a measured value (only for sensors)
This menu appears once for each measuring input.
If you simulate the measured value, this is indicated on
the display by a simulation icon in front of the measured
value.
Set the desired simulation value.
If you simulate the temperature measured value, this is
indicated on the display by a simulation icon in front of
the temperature.
