Diagnostics and troubleshooting
11.9

Logbooks

11.9.1 Available logbooks
Types of logbooks
• Logbooks physically available (all apart from the overall logbook)
• Database view of all logbooks (=overall logbook)
Logbook
Overall logbook
Calibration logbook
Operation logbook
Diagnostics logbook
Analyzer event logbook
Analyzer calibration log-
book
Analyzer data logbook
Version logbook
Hardware version
logbook
Data logbook for sensors
(optional)
Debugging logbook
1) Data in brackets means this depends on the overall logbook
11.9.2 Logbooks menu
Diagnostics/Logbooks
Function
All events
Show
Go to date
154
Visible in
All events
Calibration events
Configuration events
Diagnostic events
Analyzer events
Analyzer calibration logbook
Analyzer data logbooks
All events
All events
Data logbooks
Only accessible with the
special activation code
(Service)
Options
Events are displayed
User input
• Go to date
• Time
Max. Can be
entries disabled
1)
1000 Yes
75 (Yes)
250 (Yes)
250 (Yes)
2500 No
250 (Yes)
5000 No
50 No
125 No
150,000 Yes
1000 Yes
Info
Chronological list of all the logbook entries, with
information on the type of event.
Select a particular event to display more detailed
information.
Use this function to go directly to a specific time in the
list. In this way, you avoid having to scroll through all
the information. The complete list is always visible,
however.
Liquiline System CA80PH
Logbook Entries
can be can be
deleted deleted
No Yes
No Yes
No Yes
No Yes
No Yes
No Yes
No Yes
No No
No No
Yes Yes
No Yes
Endress+Hauser
Can be
exported
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
