Hatco MC-10 Specification Sheet

The Hatco Mini-Compact electric specialty
water heater provides 180°F (82°C)
water for either hot water sanitizing
or point-of-use water dispensing.
FLEXIBILITY
The Mini-Compact can be installed
almost anywhere and comes with
standard 6" (152 mm) legs. Available
in two models, both with a storage
capacity of 3.2 gallons (12 liters).
QUALITY
The following features assure the finest
performance for years to come:
• Mini-Compact water heaters feature a
stainless steel tank and a fast recovery.
• Available in two models: 10kW
and 11kW.
• All models include stainless steel
front with powdercoated silver-gray
hammertone body, black base,
and 6" (152 mm) legs.
• Options include stainless steel body
and base, brass pressure reducing
valve, stainless steel adjustable legs,
or deck mounting legs.
• Features include a temperature/pressure
relief valve, a pressure reducing valve,
two temperature/pressure gauges,
a high-temperature limit control, and
a low-water cut-off to prevent element
burnout due to a low water condition.
• Each booster has fiberglass insulation
to minimize heat loss.
MINI-COMPACT
Models MC-10, MC-11
Mini-Compact Model
WATER QUALITY REQUIREMENTS
Incoming water in excess of 3.0 grains of hardness per gallon (GPG) (.75 grains
of hardness per liter) must be treated and softened before being supplied to
water heater(s). Water containing over 3.0 GPG (.75 GPL) will decrease the
efficiency and reduce the operating life of the unit.
Note: Product failure caused by liming or sediment buildup is not covered
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A.
(800) 558-0607 • (414) 671-6350 • Fax (800) 543-7521 • Int'l. Fax (414) 671-3976
www.hatcocorp.com • E-mail: equipsales@hatcocorp.com
Form No. MC-1006(S)
ITEM#
ELECTRIC SPECIALTY WATER HEATERS
Water Temperature Recovery Table
40°F (22°C) Rise
MC-10 99 gph (375 Iph)
MC-11 114 gph (432 Iph)
under warranty.
Model MC-10 on
6" (152 mm) legs
70°F (39°C) Rise
57 gph (216 Iph)
65 gph (247 Iph)
Printed in U.S.A.
