  • Page 1 SOUND YOU CAN FEEL C A R A U D I O 2 0 1 7...
  • Page 2 SOUND THAT AMPLIFIES LIFE No one understands the power and beauty of music like JBL. For over 70 years now our award-winning range of audio equipment has enriched the lives of countless people across the globe. The music community depends on JBL for performances, mixes and masters.
  • Page 3 UPGRADE TO JBL Your current car will most likely have a car radio and speakers already. So why invest money in upgrading your car? The standard radio in your car has limited power. This can easily be heard when listening to your music at higher volumes.
  • Page 5 CAR SPEAKERS From years of developing professional equipment, and working with car manufacturers, we have mastered the art of great sound. And we bring that same level of audio perfection to car speakers for better depth, clarity, and power. Our car audio systems feature best-in-class technologies that deliver performance you can hear and appreciate.
  • Page 6 STAGE SERIES E N T R Y L E V E L S P E A K E R S The JBL Stage speakers are specifically designed in mind the bare essentials. Their compact design will enable fitment in almost any car and their rigid cones will make your music sound great.
  • Page 7 STAGE 402 STAGE 602E STAGE 8602 STAGE 9603E 4” (100mm) 6-1/2” (165mm) 6” x 8” (152mm x 203mm) 6” x 9” (152mm x 229mm) Dual cone speaker 2-way speaker 2-way speaker 3-way speaker STAGE 502 STAGE 600CE STAGE 6402 5-1/4” (130mm) 6-1/2”...
  • Page 8 CLUB SERIES M I D L E V E L S P E A K E R S The sound provided by JBL Club speakers will attract the ones who seek more from their car sound system. Their high sensitivity will get the most power and highest quality out of your car radio and really make your music come to life.
  • Page 9 CLUB 750T CLUB 3020 CLUB 6500C CLUB 9630 3/4” (19mm) 3-1/2” (87mm) 6-1/2” (165mm) 6” x 9” (152mm x 230mm) tweeter 2-way speaker 2-way component speaker system 3-way speaker CLUB 4020 CLUB 5020 CLUB 6520 CLUB 6420 CLUB 8620 4” (100mm) 5-1/4”...
  • Page 10 GX SERIES M I D L E V E L S P E A K E R S Even closer to perfection are the JBL GX speakers, featuring edge dome tweeters with deflectors and 3 ohm coils. They will keep on sounding great at high volumes, for a long time.
  • Page 11 GX302 GX402 GX600C GX963 3-1/2” (89mm) 4” (100mm) 6-1/2” (165mm) 6” x 9” (152mm x 230mm) 2-way speaker 2-way speaker 2-way component speaker system 3-way speaker GX502 GX602 GX642 GX862 5-1/4” (130mm) 6-1/2” (165mm) 4” x 6” (100mm x 152mm) 5”...
  • Page 12 STADIUM SERIES P R E M I U M S P E A K E R S For the most demanding music enthusiast, introducing our JBL Stadium series. Their rigid design provide the best balance and accuracy in sound, without any distortion, even at high volumes. TECHNOLOGY POWER ACCURATE...
  • Page 13 STADIUM GTO620 STADIUM GTO930 STADIUM GTO860 6-1/2” (160mm) 6” x 9” (87mm) 6” x 8” (130mm) 2-way multi-element speaker 2-way multi-element speaker 2-way multi-element speaker STADIUM GTO600C STADIUM GTO20M STADIUM GTO750T 6-1/2” (160mm) 2” (50mm) 3/4” (19mm) 2-way component system Dome midrange Tweeter...
  • Page 15 CAR AMPLIFLIERS With almost seven decades of experience in bringing live music to life, JBL has adapted many professional technologies for use in our car amplifiers. They provide unmatched ease of installation, configuration and calibration for clean, powerful sound.
  • Page 16 GX SERIES E N T R Y L E V E L A M P L I F I E R S Due to their compact design, the JBL GX amplifiers will fit most cars and provide the JBL sound you’re used to.
  • Page 17 GX-A602 GX-A604 280-Watt 435-Watt 2-channel power amplifier 4-channel power amplifier GX-A3001 415-Watt mono subwoofer amplifier...
  • Page 18 CLUB SERIES M I D L E V E L A M P L I F I E R S If you want more power, then the JBL Club series is for you. These solid, highly efficient amplifiers have a small footprint and yet provide high power output with low distortion.
  • Page 19 CLUB-5501 CLUB-4505 High-performance 1300-Watt High-performance 1800-Watt mono subwoofer amplifier 5-channel power amplifier CLUB-704 High-performance 1000-Watt 4-channel power amplifier...
  • Page 20 GTR SERIES P R E M I U M A M P L I F I E R S You want the best sound quality, power and innovation? Check out the JBL GTR amplifiers. They’re full class D on all channels. The multiple channel versions feature Clarify and BT, which will allow you to make safe phone calls and listen to music straight from your smartphone with the best possible...
  • Page 21 GTR-601 GTR-1001 High-performance 1500-Watt High-performance 2600-Watt mono subwoofer amplifier mono subwoofer amplifier GTR-104 GTR-7535 High-performance 1500-Watt High-performance 2300-Watt 4-channel power amplifier with 5-channel power amplifier with Bluetooth Bluetooth...
  • Page 23 CAR SUBWOOFERS Our rich experience in developing live stage equipment has helped us in designing subwoofers that are known for their incredible high endurance and reliability. Whether it’s a polypropylene woofer cone to ensure maximum efficiency and performance or a progressive spider cone to provide exceptional control and reduce distortion at the highest output levels, JBL subwoofers outperform anything you may have heard before.
  • Page 24 STAGE SERIES E N T R Y L E V E L S U B W O O F E R S Looking for more bass at an entry level price? The JBL STAGE subwoofers provide the legendary JBL sound. Whether in a standard enclosure, tube or your own built cabinet, you’ll clearly hear your music both inside and outside your car.
  • Page 25 STAGE 810 STAGE 1010 STAGE 1210 8” (200mm) 800-Watt 10” (250mm) 900-Watt 12” (300mm) 1000-Watt subwoofer subwoofer subwoofer STAGE1220B STAGE 1200B CSX-1400BP CS1214T Dual 12” 2000-Watt 12” (300mm) 1000-Watt 12” (300mm) 1400-Watt 12” (300mm) 1000-Watt subwoofer enclosure sealed subwoofer enclosure subwoofer bandpass enclosure subwoofer ported tube enclosure...
  • Page 26 CLUB/BASSPRO SERIES M I D L E V E L S U B W O O F E R S Focused on providing accuracy, these JBL subs are able to provide what JBL does best; powerful, accurate and low distortion bass for your music. The unique SSI switch (2/4Ω) will allow for any configuration you can think of.
  • Page 27 S2 1024 S2 1224 S2 1224SS 10” (250mm) 1000-Watt 12” (300mm) 1100-Watt 12” (300mm) 1100-Watt subwoofer with SSI subwoofer with SSI subwoofer ported enclosure with SSI CLUB WS1200 BASSPRO MICRO BASSPRO SL 12” (300mm) 1000-Watt 8” (200mm) 140-Watt 8” (200mm) 125-Watt Optional RC for subwoofer shallow Powered sealed...
  • Page 28 SERIES 3 P R E M I U M S U B W O O F E R S Efficient cooling technologies coming from JBL’s professional division, allow for extreme power handling for extensive periods of time. The unique SSI switch (2/4Ω) will allow for any configuration you can think of.
  • Page 29 S3 1024 High power 10” (250mm) 1350-watt subwoofer with SSI S3 1224 High power 12” (300mm) 1500-Watt subwoofer with SSI...
  • Page 31 ® HANDSFREE KIT The JBL Trip is designed to make phone calls safely while driving. HARMAN’s patented noise cancellation technology allows for crystal clear phone calls even with high levels of road and wind noise. As well as supporting Siri and Google now, it can also receive safety and navigation prompts via Bluetooth.
  • Page 32 SPEAKERS STAGE 402 STAGE 502 STAGE 602E STAGE 6402 Type 4" (100mm) Dual Cone Speaker 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (101mm x 152mm) 2-Way Car Speaker 2-Way Car Speaker 2-Way Car Speaker High-Frequency Transducer n.a. PEI balanced dome tweeter PEI balanced dome tweeter PEI balanced dome tweeter Power Handling, RMS...
  • Page 33 SPEAKERS CLUB 4020 CLUB 6420 CLUB 5020 CLUB 6520 Type 4" (100mm) 4" x 6" (100mm x 152mm) 5-1/4" (130mm) 6-1/2" (160mm) 2-Way Car Speaker 2-Way Car Speaker 2-Way Car Speaker 2-Way Car Speaker High-Frequency Transducer PEI balanced dome tweeters PEI balanced dome tweeters PEI balanced dome tweeters PEI balanced dome tweeters...
  • Page 34 SPEAKERS GX302 GX402 GX502 GX602 Type 3-1/2" (89mm) 4" (100mm) 5-1/4" (130mm) 6-1/2" (165mm) 2-Way Car Speaker 2-Way Car Speaker 2-Way Car Speaker 2-Way Car Speaker High-Frequency Transducer Edge-driven soft dome tweeter Edge-driven soft dome tweeter Edge-driven soft dome tweeter Edge-driven soft dome tweeter Power Handling, RMS Power Handling, Peak...
  • Page 35 SPEAKERS STADIUM GTO620 STADIUM GTO930 STADIUM GTO860 Type 6-1/2” (165mm) 6” x 9” (152mm x 228mm) 6” x 8” (152mm x 203mm) 2-Way Car Speaker 3-Way Car Speaker 2-Way Car Speaker High-Frequency Transducer Edge-driven soft dome tweeter Edge-driven soft dome tweeter Edge-driven soft dome tweeter Power Handling, RMS 110W...
  • Page 36 AMPLIFIERS CLUB 704 CLUB 4505 CLUB 5501 Number of Channels/Type 4 Channels 5 Channels Mono / Subwoofer 4-Ohm Power Output 70W rms x 4* 45W rms x 4*; 320W rms x 1* 370W rms x 1* 2-Ohm Power Output 100W rms x 4* 65W rms x 4*;...
  • Page 37 AMPLIFIERS GTR-104 GTR-7535 GTR-601 GTR-1001 Number of Channels/Type 4 Channels 5 Channels Mono / Subwoofer Mono / Subwoofer 4-Ohm Power Output 100Wrms x 4* 75Wrms x 4* 380Wrms x 1* 700Wrms x 1* 2-Ohm Power Output 120Wrms x 4* 100Wrms x 4* 600Wrms x 1* 1000Wrms x 1* Bridged Power Output...
  • Page 38 SUBWOOFERS STAGE 810 STAGE 1010 STAGE 1210 STAGE 1200B STAGE 1220B Type 8" (200mm) 10" (250mm) 12" (300mm) 12" (300mm) 2 x 12” (300mm) Subwoofer Subwoofer Subwoofer Subwoofer Sealed Enclosure Subwoofer Porter Enclosure Power Handling, RMS 200W 225W 250W 250W 500W Power Handling, Peak 800W...
  • Page 39 AMPLIFIED SUBWOOFERS BASSPRO SL BASSPRO MICRO Type 8" Powered Sealed Underseat 8" (200mm) Powered Sealed Dockable Optional RC for BassPro SL Subwoofer Enclosure Subwoofer Enclosure & BassPro Micro Power Handling, RMS 125 Watt 140 Watt n.a. Input Sensitivity 200mV - 20V 50mV –...
  • Page 40 8500 Balboa Boulevard, Northridge, CA 91329 USA © 2017 HARMAN International Industries, Incorporated. All rights reserved. JBL, Logic 7 and Plus One (patent no. 7,548,631 B2) are trademarks of HARMAN International Industries, Incorporated, registered in the United States and/or other countries. BassPro and Hear the truth are trademark of HARMAN International Industries, Incorporated.
