NI PXIe-5665 3.6 GHz Getting Started

Hide thumbs Also See for PXIe-5665 3.6 GHz:

Advertisement

Quick Links

Download this manual
PXIe-5665 3.6
GHz Getting
Started
2022-07-11

Advertisement

loading
Need help?

Need help?

Do you have a question about the PXIe-5665 3.6 GHz and is the answer not in the manual?

Questions and answers

Related Manuals for NI PXIe-5665 3.6 GHz

Summary of Contents for NI PXIe-5665 3.6 GHz

  • Page 1 PXIe-5665 3.6 GHz Getting Started 2022-07-11...

  • Page 2: Table Of Contents

    NI PXIe-5665 3.6 GHz MIMO Getting Started Guide....... . .

  • Page 3: Ni Pxie-5665 3.6 Ghz Mimo Getting Started Guide

    Note The master NI 5665 is the RF signal analyzer that receives the LO signal directly from the NI 5653 module. Slave NI 5665 devices refer to the additional analyzer channels that receive daisy-chained LO and Reference Clock signals.
  • Page 4 1. Install the NI 5665 master device in your chassis. To use the cables included with your module kit, install the NI 5622 IF digitizer module immediately to the left of the NI 5603 RF downconverter module, and install the NI 5653 LO module immediately to the right of the NI 5603.

  • Page 5: Interconnecting The Modules

    PXIe-5665 3.6 GHz Getting Started 2. Install the slave NI 5665 device in your chassis to the left of the master NI 5665 device. You can install multiple NI 5665 devices to the left of the master NI 5665, depending on your application requirements.

  • Page 6: Interconnecting The Master Ni 5665 Modules

    1. Using the three medium semi-rigid SMA-to-SMA cables (labeled J), connect the LO1, LO2, and LO3 connectors on the NI 5653 front panel to the associated LO1 IN, LO2 IN, and LO3 IN connectors on the NI 5603 front panel.

  • Page 7: Interconnecting The Slave Ni 5665 Modules

    2. Using the flexible SMA-to-SMA cable, connect the REF OUT 100 MHz connector on the NI 5653 front panel to the CLK IN connector on the NI 5622 front panel. 3. Using the short semi-rigid SMA-to-SMA cable (labeled K), connect the IF OUT connector on the NI 5603 front panel to the IF IN connector on the NI 5622 front panel.
  • Page 8 3. Medium, Semi-Rigid SMA-to-SMA Cables, Labeled M 1. Using the short, semi-rigid SMA-to-SMA cable (labeled K), connect the IF OUT connector on the slave NI 5603 front panel to the IF IN connector on the slave NI 5622 front panel.

  • Page 9: Configuring The Ni 5665 In Max

    4. Record the device identifier MAX assigns to the hardware. Use this identifier when programming the NI 5665. 5. Associate the hardware modules that comprise the master and slave NI 5665. © National Instruments...

  • Page 10: Where Do I Go From Here

    PXIe-5665 3.6 GHz Getting Started 1. Select the master NI 5603 module that is identified as not configured in the configuration tree. 2. In the Associated Devices section, select the appropriate module from each system component drop-down listbox. For the master NI 5665, you must associate the NI 5622 IF digitizer module and the NI 5653 LO source module.

  • Page 11: Worldwide Support And Services

    RF multi-channel reference software in LabVIEW for phase-coherent and non-phase-coherent hardware configurations. NI RF Vector Signal Analyzers Help—Use this help file, located at Start > All ■ Programs > National Instruments > NI-RFSA > Documentation, to learn how to operate the NI 5665.
  • Page 12 PXIe-5665 3.6 GHz Getting Started States, create your service request at ni.com/support or dial 1 866 ASK MYNI (275 6964). For telephone support outside the United States, visit the Worldwide Offices section of ni.com/niglobal to access the branch office websites, which provide up-to-date contact information, support phone numbers, email addresses, and current events.
