Getting Started with the NI PCI-1405
The NI PCI-1405 (NI 1405) is a PCI monochrome and color image acquisition device that supports a
diverse range of analog cameras. This document describes how to install and configure the necessary
hardware and software components to begin using the NI 1405.
What You Need to Get Started
You need the following items to set up and use the NI 1405:
❑
NI 1405 image acquisition device
❑
Video camera or other video source
❑
BNC-1 shielded, 75 Ω BNC cable for VIDEO, included with the NI 1405
❑
Computer running Microsoft Windows Vista/XP/2000 with at least one available PCI slot
Note
Visit
National Instruments image acquisition device compatibility with Windows Vista.
❑
NI Vision Acquisition Software 8.0 or later, which includes the NI-IMAQ driver software
❑
Optional software for developing applications:
–
NI Vision Builder for Automated Inspection
–
NI Vision Development Module
–
LabVIEW
–
LabWindows
–
Microsoft Visual Basic
Related Documentation
The following documents contain additional information that you may find helpful:
•
NI PCI-1405 User Manual—Contains information about programming options, hardware
functionality, and signal connections.
•
NI Vision Acquisition Software Release Notes—Contains information about new functionality,
minimum system requirements, and installation instructions for the NI-IMAQ driver software.
•
Measurement & Automation Explorer Help for NI-IMAQ—Describes how to configure the
NI-IMAQ driver software, NI image acquisition devices, and cameras using Measurement &
Automation Explorer (MAX).
•
NI-IMAQ Help—Contains fundamental programming concepts for the NI-IMAQ driver software
and terminology for using NI image acquisition devices.
and enter
ni.com/info
™
™
/CVI
for more information about
rdvisionvista
Advertisement
Table of Contents
Related Manuals for NI PCI-1405
Summary of Contents for NI PCI-1405
- Page 1 Getting Started with the NI PCI-1405 The NI PCI-1405 (NI 1405) is a PCI monochrome and color image acquisition device that supports a diverse range of analog cameras. This document describes how to install and configure the necessary hardware and software components to begin using the NI 1405.
-
Page 2: Safety Information
Caution National Instruments measurement products may be classified as either Measurement Category I or II. Operate products at or below the Measurement Category level specified in the hardware specifications. Getting Started with the NI PCI-1405 ni.com... - Page 3 Unpacking The NI 1405 ships in an antistatic package to prevent electrostatic discharge from damaging device components. To avoid such damage in handling the device, take the following precautions: Ground yourself using a grounding strap or by touching a grounded object, such as the computer chassis.
- Page 4 You can install the NI 1405 in any available PCI expansion slot in the computer. However, to achieve the best noise performance, leave as much room as possible between the NI 1405 and other devices or hardware.
-
Page 5: Specifications
Specifications The following specifications apply to the NI 1405 image acquisition device. These specifications are typical at 25 °C, unless otherwise stated. Formats Supported Input formats RS-170/NTSC..........30 frames/s CCIR/PAL............25 frames/s Output formats RGB ...............24-bit R, G, B, or L ..........8-bit Pixel aspect ratio ..........Square pixel... - Page 6 Dimensions ............10.7 cm × 17.5 cm (4.2 in. × 6.9 in.) Weight ..............0.136 kg (0.3 lb) Environment The NI 1405 is intended for indoor use only. Operating temperature ...........0 °C to 55 °C Storage temperature ..........–20 °C to 70 °C Relative humidity...........5% to 90%, noncondensing Pollution Degree ............2...
- Page 7 At the end of their life cycle, all products must be sent to a WEEE recycling center. For more information about WEEE recycling centers and National Instruments WEEE initiatives, visit ni.com/environment/weee.htm © National Instruments Corporation Getting Started with the NI PCI-1405...
- Page 8 Thailand 662 278 6777, Turkey 90 212 279 3031, United Kingdom 44 0 1635 523545 National Instruments, NI, ni.com, and LabVIEW are trademarks of National Instruments Corporation. Refer to the Terms of Use section on ni.com/legal for more information about National Instruments trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies.
