- Page 1 We have 45,000 LP502030-PCM-NTC-LD-A02554 - EEMB - Lithium Battery Rectangular 3.7V 250mAh Rechargeable in stock now. Starting at $0.034. This EEMB part is fully warrantied and traceable. 00000005981LF-000 BM92A21MWV-EVK-001 EOS Power ROHM SEMICONDUCTOR Buy Now Buy Now Looking for a discount?
- Page 2 ROHM USB Type-C Power Delivery Evaluation Board Manual BM92A21MWV-EVK-001 Ver.1.00 ROHM USB Type-C Power Delivery Evaluation Board Manual BM92A21MWV-EVK-001 Ver.1.00 Date:03-Mar,2017 ROHM Co.,Ltd. URL http://www.rohm.com...
- Page 3 ROHM USB Type-C Power Delivery Evaluation Board Manual BM92A21MWV-EVK-001 Ver.1.00 Introduction This board is dedicated to supplying power with USB Type-C Power Delivery, and voltage profile (PDO) is 5V, 9V, 12V, 15V, 20V. If you want to check the operation of Power Delivery, please prepare capable of receiving power USB Type-C Power Delivery device and USB Type-C dedicated cable and AC cable.
- Page 4 ROHM USB Type-C Power Delivery Evaluation Board Manual BM92A21MWV-EVK-001 Ver.1.00 How to use and evaluate 1. As shown in the picture below, please insert the AC cable into this board. Please tighten the screw securely with the screwdriver from the top.
- Page 5 ROHM USB Type-C Power Delivery Evaluation Board Manual BM92A21MWV-EVK-001 Ver.1.00 3. Please connect to capable of receiving power USB Type-C Power Delivery device with Type-C dedicated cable. The following is a picture connected to the selling separately BM92A12MWV-EVK-001. BM92A21MWV-EVK-001 From...
- Page 6 ROHM USB Type-C Power Delivery Evaluation Board Manual BM92A21MWV-EVK-001 Ver.1.00 Power Delivery Operating Waveform When connecting this board (Source side) and power receiving device (Sink side) using Type-C dedicated cable, the Source side detects the Sink side and outputs 5V voltage to the VBUS pin.
- Page 7 ROHM USB Type-C Power Delivery Evaluation Board Manual BM92A21MWV-EVK-001 Ver.1.00 The Specification and Caution of the BM92A21MWV-EVK-001 <Specification> ・PDO PDO-1:5V 3A PDO-2:9V 3A PDO-3:12V 3A PDO-4:15V 3A PDO-5:20V 3A ・AC input voltage range:90Vac～270Vac ・AC input current limit:2A ・Output voltage range:5V～20V ・Output power:100W...
- Page 8 Products. ROHM does not grant you, explicitly or implicitly, any license to use or exercise intellectual property or other rights held by ROHM or any other parties. ROHM shall have no responsibility whatsoever for any dispute arising out of the use of such technical information.
