Rohm BM2P016T-EVK-002 User Manual

AC/DC Converter
Isolation Fly-back Converter PWM method Output 22.5W 15V
BM2P016T Reference Board
BM2P016T-EVK-002
The BM2P016T-EVK-002 evaluation board outputs 15V voltage from the input of 90Vac to 264Vac. The output current supplies up to 1.5A.
BM2P016T which is PWM method DC/DC converter IC built-in 650V MOSFET is used.
The BM2P016T contributes to low power consumption by built-in a 650 V starting circuit.
Current mode control imposes current limitation on every cycle, providing superior performance in bandwidth and transient response. The switching
frequency is 65 kHz in fixed mode. At light load, frequency is reduced and high efficiency is realized. Built-in frequency hopping function contributes
to low EMI. Low on-resistance 1.4 Ω 650 V MOSFET built-in contributes to low power consumption and easy design.
The flywheel diode is a fast recovery diode of 6A/600 V RF601TDNZ, contributing to low power consumption.
The conduction / radiation emission test is based on CISPR 22 Class B with best EMI design.
Electronics Characteristics
Not guarantee the characteristics, is representative value. Unless otherwise noted :V
Parameter
Input Voltage Range
Input Frequency
Output Voltage
Maximum Output Power
Output Current Range
(NOTE1)
Stand-by Power
Efficiency
Output Ripple Voltage
(NOTE2)
Operating Temperature Range
(NOTE1) Please adjust operating time, within any parts surface temperature under 105°C
(NOTE2) Not include spike noise
© 2018 ROHM Co., Ltd.
Min Typ Max
90 230 264
47 50/60 63
13.5 15.0 16.5
- 15.0 22.5
0 1000 1500
- 130 -
- 84.5 -
- 200 -
-10 25 65
1/10
User's Guide
= 230Vac, I = 1500mA, Ta:25° C
IN OUT
Units Conditions
Vac
Hz
V
W I = 1500mA
OUT
mA
mW I = 0A
OUT
%
mVpp
° C
No. 61UG006E Rev.001
MAR.2018
