Alto LYNX-MIX82 Service Manual page 20

S/N Part No.
1 MB06340 ZB-bottom board-RS-5249
2 MA07945 ZC-front panel-RS SR#2000 5249
3 HK10818 K-PCB
4 HK10820 K-PCB
5 HI00026 Power supply Switch-RS
6 MG00304 Copper column-RS
7 MG00244 Copper column-RS
8 HK10819 K-PCB
9 MG00580 Black screw-RS
10 MG00804 Black screw-RS-CT
11 NI02714 Plastic knob-RS-C
Plastic knob-RS-C-ABS
12 NI04004
13 NI02252 Knob cover-RS-C-ABS
14 NI04601 Knob cover-RS-C-ABS
15 NI04602 Knob cover-RS-C-ABS
16 NI02692 Knob cover-RS-C-ABS
17 NI01147 Knob cover-RS-C-ABS
18 NI02386 Plastic knob-RS
19 NI01863 Button-RS
20 ME00060 MIC Jack screw-RS-ACT-HC00125
21 MF00061 Washer-RS-ACT
22 MG00041 Black screw-RS-ball
23 HC00212 DC outlet-RS
24 MF00022 Multicolored washer-RS
Mechanical Parts List
Description
--- 18 ---
Specification
LYNX-MIX82FX_V1.0
LYNX-MIX82FX ALTO_V1.0
P-LYNX-MIX82FX-DIP
P-LYNX-MIX82FX-POWER-DIP
RA12KKATOF 2P
M3*14*0.5PH
M3*10*0.5PH
P-SKU-FX04(LYNX-MIX82FX)-DIP
M3*10(ψ5.0)_V1.0
M3*6*0.5PH_V1.0
φ10*13.5mm
φ10*16.5(cool grey8C)90°_V1.0
φ7*3.5 072Cblue
φ7*3.5 3298Ugreen_V1.0
φ7*3.5 123Uyellow_V1.0
φ7*3.5 black
φ7*3.5 white_V2.0
φ14*13mm
φ5.5*W10*7.5 black
hexJY-6351G-02-250
φ9.6*φ13*0.5t
M3*6
DJ-23 2.0mm
φ14.1*φ20*1.8t
Qty
1
1
1
1
1
11
3
1
9
11
6
47
18
6
8
6
9
2
3
17
17
37
1
1
