- Page 1 E - B I K E USER‘S MANUAL Thank you for purchasing the ANCHEER EBIKE. The EBIKE features the most recent innovation in technology.
- Page 2 Thank you for purchasing the ANCHEER EBIKE. The EBIKE features the most recent innovation in technology. WARNING Read OWNER'S MANUAL and follow all Safety Messages and Instructions. Wear helmet while riding the bike. Do not use this bike for downhill competition or any aggressive off-road riding.
- Page 3 SAFE RIDING TECHNIQUES & TIPS Following these techniques and tips can ensure you have a safe, fun riding experience on your E-Bike. Check to make sure your brakes are fully intact, pedals are securely installed, and handlebars are locked in place. Always wear a helmet and protective gear to avoid possible injury.
- Page 4 TABLE OF CONTENT Contents Check List General Information Unpacking Your E-Bike Unfolding Your E-Bike Fitting The Saddle Pre-Ride Checks Getting Started Understanding Your Battery Charging Your Battery Simple Troubleshooting Warranty Warnings...
- Page 5 Two Set of Keys a. Battery Charger b. Battery Lead Box Containing 2 c. Manual d. Tools Specification: Model NO. : 16'' Folding ANCHEER Frame : Steel Motor : 36V 250W Brushless Battery : 36V 8AH Lithium Charging time:...
- Page 6 ANCHEER GENERAL INFORMATION 1. Bike Components Rear Disc Brake Callipers Tyre Chain Front Fork Battery Stem Crank Frame Front Disc Brake Calipers Seat Post Clamp/ Seat Clamp Disc Saddle Wheel Reflector Saddle Post/ Seat Tube...
- Page 7 ANCHEER GENERAL INFORMATION Left Brake Lever Right Brake Lever Left Grip Right Grip Meter Handle Bar Pedal Motor Kick Stand...
- Page 8 ANCHEER GENERAL INFORMATION 2. Tool List 0.24 inch (6mm)Allen Key Phillips - Slotted head Screwdriver 0.20 inch (5mm)Allen Key 8-10 Open End Wrench 0.16 inch (4mm)Allen Key 13-15 Open End Wrench 0.12 inch (3mm)Allen Key 14-17 Open End Wrench 3. Standover Height...
- Page 9 Once you have unpacked the bike,check to make sure there has not been any damage in transit. If you find anything missing or damaged, contact ANCHEER customer service: 626-333-4255 (US), ancheer.us@gmail.com (US) / support@iancheer.com (International) / service@ancheer.shop (International)
- Page 10 ANCHEER UNFOLDING YOUR E-BIKE Step1. Frame Unfold the frame until the 2 sections are in line. (Fig. 1) Fig.1 Push the large lever towards the frame to lock together. (Fig. 2) Fig.2 Turn the sliver security clip as photo show ( Fig.
- Page 11 ANCHEER UNFOLDING YOUR E-BIKE Step 2. Handlebar and stem Insert the handlebar into the stem Tighten the two side screw of handlebar by allen key Please refer to the picture below Fig.5 Fig.6 Fig.7 Fig.8 Be sure to tighten the screws at the stem, otherwise, the handlebar riser will easily loosen.
- Page 12 ANCHEER UNFOLDING YOUR E-BIKE Step 3. Pedals • Pull pedals out from folded position until they spring into flat position. (Fig.11) • To fold the pedals for storage or for transportation, you must press the pedal inward towards the bike and then upward/downward once it has cleared the locking mechanism .
- Page 13 ANCHEER FITTING THE SADDLE The saddle and seat post are already fitted together. Rease the seat post, use a tool to pull out the black tube, and check the seat tube. Slide the seat post into the seat tube and close the tension lever on the quick-release clamp to lock your seat in place.
- Page 14 ANCHEER PRE-RIDE CHECKS Complete these checks before every ride. Improper assembly or maintenance can lead to a crash. Failure to do these pre-ride check may lead to severe injury. Check to make sure all fasteners are tight. (See that at right for bolt sizes and locking torque spec.) Check that your tires are inflated sufficiently.
- Page 15 ANCHEER GETTING STARTED Simply explained, this is how your E-Bike works. Switch on the battery on the left side of the frame. (Fig.18) To tum on your E Bike, insert the ignition key below the battery indicator and tum clockwise. (Fig.18) THAT’S IT.
- Page 16 ANCHEER UNDERSTANDING YOUR BATTERY The more you use the assist, the more power it uses. Each rider is different, so power usage can vary considerably with different rider weights and the terrain you ride. With normal use, you should generally be able to obtain around 20 miles before you need to recharge your battery.
- Page 17 ANCHEER UNDERSTANDING YOUR BATTERY Fig.21 Fig.22 Fig.23 Fig.24 Fig.25 Fig.26 IMPORTANT! Any statements regarding battery performance or distances which can be obtained per single charge are based on standard test conditions. Diverse terrain and rider weight will of course produce varying results from those stated.
- Page 18 ANCHEER UNDERSTANDING YOUR BATTERY Brake Adjustment Ensure that the brake cables are properly inserted into the brake levers before aligning a mechanical disc brake. If the disc rotor is bent or damaged, replace the rotor first. If the brake is not sensitive, loosen the...
- Page 19 ANCHEER CHARGING YOUR BATTERY WHEN CHARGING THE BATTERY ❶ Insert the charger probe into the charger port on the e-bike battery. As shown in the figure. ❷ Insert the pronged end of the battery cord into the battery charger. ❸...
- Page 20 ANCHEER CHARGING YOUR BATTERY MAINTENANCE OF YOUR E-BIKE Improper maintenance can lead to a crash. Follow the below maintenance guidelines. Failure to do so could result in injury. General Maintenance Wipe your bike with a dry cloth, or neutral detergent.
- Page 21 ANCHEER SIMPLE TROUBLESHOOTING If unsure on any of these points, or you fail to correct the problem, you can contact us by email on the sales platform you bought at the first time. Our after-sell service team will be glad to help you!!
- Page 22 WARRANTY 1 Year Limited Hardware Warranty Your ANCHEER Electric bike includes a One Year Limited Hardware Warranty. The Warranty covers product defects in materials and workmanship under normal use. This Warranty is limited to original purchasers. This Warranty starts on the date of your purchase and lasts for one year (the "Warranty Period").
- Page 23 ANCHEER WARNINGS Operation General ● Only use the e-bike and the drive assist system for safe, recreational riding. Use of the e-bike for a purpose it was not intended for is dangerous and could result in property damage, serious injury or death. Always follow the instructions for intended use and limitations.
- Page 24 ANCHEER WARNINGS Like any mechanical device, a bicycle and its components are subject to wear and stress. Different materials and mechanisms wear or fatigue from stress at different rates and have different life cycles. If a component’s life cycle is exceeded, the component can suddenly and catastrophically fail, causing serious injury or death to the rider.
- Page 25 ANCHEER WARNINGS ● Overcharging the battery could result in electrical fires, explosion, or severe burns. Always disconnect the battery from the battery charger when the battery is fully charged. Unplug the battery charger from the wall outlet when not in use.
- Page 26 ANCHEER WARNINGS use, helmet laws, child carrier laws, special bicycle traffic laws. It’s your responsibility to know and obey the laws. Failure to wear a helmet when riding may result in serious injury or even death. Do not remove the front or rear reflectors or reflector brackets from your bicycle. They are an integral part of the bicycle’s safety system.
- Page 27 ANCHEER WARNINGS the handlebar/stem assembly. If you can twist the stem in relation to the front wheel, turn the handlebars in relation to the stem, or turn the bar end extensions in relation to the handlebar, the bolts are insufficiently tightened.Be aware that adding aerodynamic extensions to handlebars will change the steering and braking response of the bicycle.
- Page 28 E Bike Model: AMA005639 TIANJIN GAMMA ELECTRIC TECHNOLOGY CO.,LTD Made in China support@iancheer.com ANCHEER Customer Service Tel: 626-330-6385 Monday-Friday 9:30AM-6:00PM...
