F5 WANJet 300 Quick Start Card

WANJet 300 | Quick Start Card
®
7 Complete the WANJet 300 appliance setup
Log on to the appliance remotely through the browser interface, and use the Setup utility to activate the
license and complete the setup, as follows. For more detailed information, click the Help tab or refer to the
WANJet Appliance Administrator Guide.
®
To log on
a. In a web browser, go to https://<Mgmt IP
address, if you set up a management network.
Otherwise use the Bridge IP address.
b. In the user authentication popup screen, type
the user name and password, and click OK.
The default credentials are:
User Name: admin
Password: admin
The WANJet Setup Utility Welcome screen opens.
To activate the license
a. On the WANJet Setup Utility Welcome screen,
click Next to open the first License screen.
b. Click Activate to open the second License
screen. In the Base Registration Key box, your
registration key appears. If it does not appear, see
the note below.
c. Click Next.
d. Read the End User License Agreement (EULA), and
then click Accept if you agree to the conditions.
Note: If automatic license activation does not work,
you can use manual activation instead. On the
second License screen, for Activation Method, select
Manual and follow the directions on the screen.
8 Configure the WANJet 300 appliance
Use the browser interface, called the Configuration utility, to configure the WANJet appliance, such as adding
remote WANJet appliances, setting up optimization and QoS policies, and creating static routes. For more
information, click the Help tab, or consult the WANJet
F5 Networks, Inc. Technical Support
(206) 272-6888 Voice • (888) 88ASKF5 Toll-free • (206) 272-6802 Fax
Web: http://tech.f5.com and enroll at AskF5 , our online knowledge base. Email: support@f5.com
SM
© 2007 F5 Networks, Inc. All rights reserved. F5, F5 Networks, the F5 logo, and WANJet are trademarks or registered trademarks, and Ask F5 is a service mark, of F5 Networks, Inc. in the U.S. and
in certain other countries. This product protected by U.S. Patent 6,327,242. Other patents pending.
To complete the setup
When the license activation has finished, the
Platform screen opens.
a. Verify the Management Port settings. If you are
not using a management interface, you must still
type an IP address and netmask (use fictitious
ones) to proceed with the setup.
b. For the Host Name, type a fully qualified domain
name, for example, mywanjet.wanopt.net.
c. Select the local time zone.
d. Change and confirm the passwords for the root
and Admin accounts.
e. Click Next to open the Local WANJet screen.
f. In the WANJet Alias box, optionally type a
common name for the WANJet appliance.
g. If you set up the local WANJet appliance using
the Bridge menu on the LCD, verify that the
addresses you specified appear on this screen.
If you did not specify these addresses, type them
in the appropriate boxes.
h. Click Save.
To reboot
After you complete the Setup utility, you must
reboot the WANJet appliance from the command
line. To reboot, use a terminal emulator program
(if you are working locally using a serial console
connected to the WANJet appliance) or an SSH
program. Log on to the WANJet appliance and run
the reboot command.
When the reboot has finished, you need to log on
again to continue using the browser interface.
® Appliance Administrator Guide.
F5 WANJet 300 Appliance
®
Quick Start Card
How to get started with the WANJet 300 appliance
