  • Page 1 ® 250 Crossways Park Drive, Woodbury, New York 11797 1-800/422-8027 (USA only) Fax: 516/682-3523 © 2001 Harman Kardon, Incorporated Printed 11/01 Part No. ai5170...
  • Page 2 HKTS 10 Home Theater Speaker System OWNER’S MANUAL ® ™ Power for the Digital Revolution.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Safety Information Introduction Included SUB-TS10 Subwoofer Amplifier Panel Controls and Connections Speaker Placement Mounting Options Speaker Connections Dolby Digital or DTS (or Other Digital Surround Mode) Connection Dolby Pro Logic (Non-Digital) – Line Level Dolby Pro Logic (Non-Digital) – Speaker Level Operation Volume Additional Bass Adjustments...
  • Page 4 Read First! Important Safety Precautions! CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: To prevent electric shock, do not use this (polarized) plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted to prevent blade exposure.
  • Page 5: Introduction

    While sophisticated electronics and state- of-the-art speaker components are hard at work within the HKTS 10 to make all of this happen, hookup and operation are simple. Color-keyed connections and simple con- trols make the HKTS 10 easy to use.
  • Page 6: Sub-Ts10 Subwoofer Amplifier Panel Controls And Connections

    SUB-TS10 SUBWOOFER AMPLIFIER PANEL CONTROLS AND CONNECTIONS ¢ ™ ¡ IMPORTANT: CONNECT STRIPED WIRE TO RED ( ) SPEAKER TERMINAL. SUB-TS10 For use with HKTS 10 System harman/kardon Made in China CAUTION CAUTION RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK...
  • Page 7 • Filter Remote Control Input: This input accepts a remote control signal from a compatible Harman Kardon A/V receiver that enables you to override the High-Cut (Low-Pass) Filter Switch §, by signal- ing the SUB-TS10 to engage the filter even when the switch is in the OFF position.
  • Page 8: Speaker Placement

    SPEAKER PLACEMENT Front Speakers Front Speakers The front speakers should be placed the same distance from each other as they are from the listening position. They should be placed at about the same height from the floor as the listeners’ ears will be, or they may be angled toward the listeners.
  • Page 9: Mounting Options

    MOUNTING OPTIONS Satellites and Surrounds The satellite speakers may be placed on a shelf. They may be tilted upwards simply by tilting them back onto their sculpted surfaces. Wall-Mounting Attach bracket to wall. If possible, position the speakers so that the mounting screws used connect directly to a wooden wall stud.
  • Page 10: Speaker Connections

    Harman Kardon, use red to denote the (+) terminal and black for the (–) terminal. Newer Harman Kardon receivers conform to the new CEA standard and therefore use a color other than red or black for the (+) ter- minal to indicate some speaker positions: e.g., surround left.
  • Page 11: Dolby Digital Or Dts (Or Other Digital Surround Mode) Connection

    SPEAKER CONNECTIONS (continued) Dolby Digital or DTS (or other Digital Surround Mode) Connection USE THIS INSTALLATION METHOD FOR DOLBY DIGITAL, DTS OR OTHER DIGITAL SURROUND PROCESSORS: Use the line-level input jack marked SUB £ for the Low-Frequency Effects channel. Connect this jack to the subwoofer output or LFE output on your receiver or amplifier.
  • Page 12: Dolby Pro Logic (Non-Digital) – Line Level

    SPEAKER CONNECTIONS (continued) Dolby Pro Logic (Non-Digital) – Line Level USE THIS INSTALLATION METHOD FOR DOLBY PRO LOGIC APPLICATIONS (NOT DOLBY DIGITAL, DTS OR OTHER DIGITAL PROCESSING), WHERE THE RECEIVER/ PROCESSOR IS EQUIPPED WITH A SUB- WOOFER OUTPUT, OR A VOLUME- CONTROLLED PREAMP (LINE-) LEVEL OUTPUT: Use the supplied RCA-type patch cord to...
  • Page 13: Dolby Pro Logic (Non-Digital) - Speaker Level

    SPEAKER CONNECTIONS (continued) Dolby Pro Logic* (Non-Digital) – Speaker Level USE THIS INSTALLATION METHOD FOR DOLBY PRO LOGIC APPLICATIONS (NOT DOLBY DIGITAL, DTS OR OTHER DIGITAL PROCESSING), WHERE THE RECEIVER/ PROCESSOR DOES NOT HAVE A SUB- WOOFER OUTPUT, OR A VOLUME- CONTROLLED PREAMP (LINE-) LEVEL OUTPUT: Connect your receiver or amplifier’s front...
  • Page 14: Operation

    OPERATION Move the Master Power Switch ⁄ • (marked Power) to the “ ” (On) position. The SUB-TS10 subwoofer will automatically turn itself on or go into Standby mode, depending on whether or not a signal is being sent to it by your receiver or surround processor, and provided that the Music- Sense On/Off Switch ¶...
  • Page 15: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING If there is no sound from any of the speakers: • Check that receiver/amplifier is on and a source is playing. • Check that the powered subwoofer is plugged in and its Master Power Switch ⁄ is switched on to the “ •...
  • Page 16: Specifications

    SPECIFICATIONS HKTS 10 System Frequency Response 35Hz – 20kHz (–6dB) SAT-TS10 Satellites Recommended Power 10 – 110 watts Impedance 8 ohms nominal Sensitivity 86dB @ 1 watt/1 meter Tweeter One 1" dome, video-shielded Midrange One 4" driver, video-shielded Dimensions (H x W x D) 10-1/8"...
