Harman Kardon HKTS 5 Owner's Manual
Home theater speaker system
Hide thumbs
Also See for HKTS 5:
- Owner's manual (71 pages) ,
- Service manual (22 pages) ,
- Specifications (2 pages)
Subscribe to Our Youtube Channel
Related Manuals for Harman Kardon HKTS 5
Summary of Contents for Harman Kardon HKTS 5
- Page 1 ® 250 Crossways Park Drive, Woodbury, New York 11797 1-800/422-8027 (USA only) Fax: 516/682-3523 © 2001 Harman Kardon, Incorporated Printed 8/01 Part No. ai5161...
- Page 2 HKTS 5 Home Theater Speaker System OWNER’S MANUAL ® ™ Power for the Digital Revolution.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Safety Information Introduction Included Speaker Placement Mounting Options Speaker Connections Operation Volume Troubleshooting Specifications... - Page 4 Read First! Important Safety Precautions! CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: To prevent electric shock, do not use this (polarized) plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted to prevent blade exposure.
-
Page 5: Introduction
While sophisticated electronics and state- of-the-art speaker components are hard at work within the HKTS 5 to make all of this happen, hookup and operation are simple. Color-keyed connections and simple con- trols make the HKTS 5 easy to use. -
Page 6: Speaker Placement
SPEAKER PLACEMENT Front Speakers Front Speakers The front speakers should be placed the same distance from each other as they are from the listening position. They should be placed at about the same height from the floor as the listeners’ ears will be, or they may be angled toward the listeners. -
Page 7: Mounting Options
MOUNTING OPTIONS Satellites and Surrounds The satellite speakers may be placed on a shelf. They may be wall-mounted using the sup- plied brackets. On optional stands (FSTS1) Wall-Mounting Attach plate to wall. If possible, position the speakers so that the mounting screws used connect directly to a wooden wall stud. -
Page 8: Speaker Connections
AC power source. The HKTS 5 should not be connected to an AC power source until all speaker wire connections have been made. - Page 9 SPEAKER CONNECTIONS (continued) Use the supplied RCA-type patch cord to connect the line-level SUB or LFE output on your receiver or amplifier to the SUB input on the SUB-TS5 subwoofer. Connect the satellite and center speakers to the corresponding speaker terminals on your receiver or amplifier.
-
Page 10: Operation
Standby mode, depend- ing on whether or not a signal is being sent to the HKTS 5 by your receiver or surround processor, and provided that the Auto/On switch ™ is moved to the left so that it is in the “Auto”... -
Page 11: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING If there is no sound from any of the speakers: • Check that receiver/amplifier is on and a source is playing. • Check that the powered subwoofer is plugged in and its Power switch ¡ is switched on to the “ •... -
Page 12: Specifications
SPECIFICATIONS HKTS 5 System Frequency Response 35Hz – 20kHz (–6dB) Satellites Recommended Power 10 – 70 watts Impedance 8 ohms nominal Sensitivity 86dB @ 1 watt/1 meter Tweeter One 1/2" dome, video-shielded Midrange One 3" driver, video-shielded Dimensions (H x W x D) 4-5/8"...
