Instructions for use, installation
MT
IE
GB
and connection
Glass-ceramic induction built-in coking hob

Advertisement

loading

Related Manuals for Gorenje IT641KR

Summary of Contents for Gorenje IT641KR

  • Page 1 Instructions for use, installation and connection Glass-ceramic induction built-in coking hob...

  • Page 2: Table Of Contents

    Glass-ceramic built-in cooking hob Dear customer! Glass-ceramic hob is intended for use in households. Our products are packed in environment-friendly materials which can be recycled, disposed of, or destroyed without imposing any burden on the environment. Instructions for use Instructions for use are intended for the user. They describe the appliance and its operation.

  • Page 3: Important - Read Before Using The Appliance

    Important - Read before using the appliance Safety percautions • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or metal capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 4 • The appliance is intended solely for cooking. Do not use it for any other purpose, e.g. for room heating. Do not place empty cookware on the cooking zones. • If another electrical appliance is connected to a AC power socket near the appliance, make sure the power cord does not come into contact with hot cooking zones.

  • Page 5: Appliance Description

    Appliance description Control panel SIVK6ATF 1. Keep food warm/melt with indicator 12. On/Off button with indicator 2. Cooking timer indicator left front zone 13. Stop/Go function with indicator 3. Reduce time button 14. Setting indicator right front zone 4. Minute minder indicator 15.
  • Page 6 Safety instructions What you should pay attention to Induction cooking is extremely safe. Various safety devices have been incorporated in the hob such as a residual heat indicator and a cooking time limiter. There are nevertheless a number of precautions you should take. Connection and repair •...
  • Page 7 • The ceramic top is extremely strong, but not unbreakable. A spice jar or pointed utensil falling on it, for example, could cause it to break. • Stop using the hob if a break or crack appears. Switch the appliance off immediately, unplug it to avoid electric shocks, and call the service department.
  • Page 8 Cooking-time limiter The cooking-time limiter is a safety function of your cooking appliance. It will operate if you forget to switch off your hob. Depending on the setting you have chosen, the cooking time will be limited as follows: Setting The cooking zone switches automatically off after: 12 hours...

  • Page 9: Use

    Getting used to it... Using the touch controls The touch controls may take some getting used to if you are used to other (rotary) controls. Place the tip of your fi nger fl at on the control to achieve the best results. You do not have to apply any pressure.
  • Page 10 Induction cooking A magnetic fi eld is generated in the appliance. By placing a pan with an iron base on a cooking zone, a current is induced in the pan base. This induced current generates heat in the base of the pan.
  • Page 11 You can check for yourself whether your pans are suitable using a magnet. A pan is suitable if the base of the pan is attracted by the magnet. Suitable Unsuitable Special stainlesssteel pans Earthenware Class Induction Stainless steel Hard-wearing enamelled pans Porcelain Enamelled cast-iron pans Copper...

  • Page 12: Operation

    Operation Settings Switching on the hob and setting the power The power has 9 settings. There is also a ‘boost’ setting, which is indicated by a ‘P.’ in the display. 1. Put a pan on a cooking zone. 2 Touch the On/Off button. You will hear a short bleep and the display for each cooking zone will show ‘0.’.
  • Page 13 Automatic heat-up function The automatic heat-up function temporarily increases the power (setting ‘9.’) to heat the contents of the pan faster. This function is available in all settings except the ‘Boost’ setting and setting ‘9.’. Switching on the automatic heat-up function The hob is switched on and a pan has been placed in a cooking zone.
  • Page 14 Boost The ‘Boost’ function is used to cook at maximum power for a short period of time (maximum 10 minutes). The power is reduced to setting 9 at the end of the maximum boost time. Switching on the boost function The hob is switched on and a pan is on the cooking zone.
  • Page 15 Melting/keeping food warm Use the button to switch on the function to melt or keep food warm. The cooking timer is used to set the maximum melting/ warming time. The melt function (u) The function to keep food warm (U) The melt function keeps The function to keep food warm the temperature of the...
  • Page 16 2. Select setting ‘0.’ by touching the button. You will hear a bleep and the display will show ‘0.’. If all of the cooking zones are set to ‘0.’, the hob automatically switches to stand-by mode (see also ‘Stand-by mode’). Switching off all of the cooking zones at the same time The hob is in stand-by mode, or one or more of the cooking zones are active.
  • Page 17 Switch the hob to (standard) lock mode One or more cooking zones are active. 1. Touch and hold the button. Attention! All of the set cooking processes remain active. The red light to the right above the button and the On/ Off button are constantly illuminated.
  • Page 18 Switching off Stop / Go mode Press the button again within 10 minutes. The hob continues with the settings that were set before the Stop / Go. Recognising a mode The display for each cooking zone shows ‘0.’. The red light to the right above the Stand-by mode On/Off button is constantly illuminated.
  • Page 19 Cooking timer/Minute minder A cooking timer can be set for each cooking zone. All of the cooking timers can be used at the same time. The hob also has an minute minder. Both the cooking timer and the minute minder can be set to a maximum of 99 minutes.
  • Page 20 Assigning and switching on the cooking timer The hob is switched on. The cooking timer can only be linked to active cooking zones. 1. Touch the and button for the cooking timer/minute minder twice at the same time to set the timer for the fi rst active cooking zone (in this example, the cooking timer for the rear left zone is active).

  • Page 21: Cooking

    Healthy cooking Burning point of different types of oil To ensure your food is fried as healthily as possible, Gorenje recommends choosing the type of oil according to the frying temperature. Each oil has a different burning point at which toxic gasses are released.

  • Page 22: Maintenance

    • Use setting 6 and 5 to: - complete the cooking of large quantities; - defrost hard vegetables; - fry thin slices of breaded meat. • Use settings 1-4 to: - simmer bouillon; - stew meats; - simmer vegetables; - melting chocolate; - melting cheese.

  • Page 23: Troubleshooting

    Troubleshooting The service department telephone number can be General found on the guarantee card provided. If you notice a crack in the glass top (however small), switch the hob off immediately, unplug the hob, turn off the (automatic) fuse switch(es) in the meter cupboard or, in the event of a permanent connection, set the switch in the power supply lead to zero.) Contact the service department.

  • Page 24: Installation Instructions

    SYMPTOM POSSIBLE CAUSE SOLUTION A fuse blows as soon as the The hob has been wrongly Check the electrical hob is switched on. connected. connections. The hob simply switches off. You accidentally touched the Switch the hob back on. On/Off button or touched two buttons at the same time.
  • Page 25 Clearance Suffi cient all-round clearance is essential to the safe use of the hob. Check that there is enough clearance. cooker hood cabinet side wall *SIVK 6 ... 61 cm Installation dimensions The dimensions and recesses are shown in the illustrations beneath.
  • Page 26 • Cooking hobs can be installed into worktops that are 30 to 50 mm thick. • If the board is thicker than 40 mm, its inner edge should be trimmed, or ground. Thus, suffi cient air circulation will be provided. If the hob is wider than the cupboard, with a worktop less than 46 mm thick, saw a cut-out in both sides of the cupboard, so the appliance is detached from the cupboard.
  • Page 27 Ventilation The electronics in the appliance need cooling. The appliance will automatically switch off if there is insuffi cient air circulation. There are ventilation openings on the underside of the appliance. It must be possible for cool air to be drawn in through these openings.
  • Page 28 B Lower kitchen cabinet with an oven • Installing the oven under an induction hob is possible with oven types EVP4.., EVP2.., which are fi tted with a cooling fan. Before installing the oven, the rear wall of the kitchen cabinet should be removed.
  • Page 29 Electrical connection Common connection: • 2 phase and 1 zero connection (2 1N, 400 V~/ 50 Hz): - The voltage between the phases and the zeros is 230 V~. The voltage between the two phases is 400 V~. Fit a connecting bridge between connecting points 4-5.
  • Page 30 The bridges on the connecting block can be used to create the required connections, as indicated in these illustrations. Building in Check that the cabinet and the cut-out meet the dimension and ventilation requirement Threat the sawn ends of wooden or synthetic worktops with sealing varnish if necessary, to prevent moisture causing the worktop to swell.
  • Page 32 G_5_KARIM RASHID en (01-14)
