  • Page 1: Table Of Contents

    Multi outdoor units Multi - Zone SERVICE MANUAL heat pump units Model Numbers: KMIR218-H221 / KMIR327-H217 / KMIR436-H217 / KMIR545-H219 Table of Contents Indoor Unit Combination Suggested Indoor Unit Model Numbers Dimension Of Outdoor Unit Refrigerant Cycle Diagram Installation Details...
  • Page 2 https://appliancetechmanuals.com CONTENTS Indoor Unit Combination ............................4 Suggested Indoor Unit Model Numbers ........................5 Dimension Of Outdoor Unit............................6 Refrigerant Cycle Diagram ............................7 Installation Details ..............................9 5.1 Wrench torque sheet for installation ......................... 9 5.2 Connecting the cables ............................9 5.3 Pipe length and the elevation ..........................

  • Page 3: Indoor Unit Combination

    https://appliancetechmanuals.com 1. Indoor Unit Combination Multi DC Nominal Suggested Limit Outdoor Unit capacity Combination Multi-Zone Nominal Suggested 9+18 Limit Outdoor Unit capacity Combination 12+12 12+18 KSIM218-H221 18k Btu 18+18 None 9+12 1drives 2 9+9+9 12+12 9+9+12 9+9+18 Multi-Zone Nominal Suggested 9+12+12 Combination Outdoor Unit...
  • Page 4 https://appliancetechmanuals.com 18+18+24 12+12+18+18 9+9+9+9 9+9+9+9+9 9+9+9+12 9+9+9+9+12 9+9+9+18 9+9+9+9+18 9+9+9+24 9+9+9+9+24 9+9+12+12 9+9+9+12+12 KSIM545-H219 KSIM545-H219 48k Btu 9+9+12+18 9+9+9+12+18 48k Btu 1 drives 5 1 drives 5 9+9+12+24 9+9+9+18+18 9+9+18+18 9+9+12+12+12 9+9+18+24 9+9+12+12+18 9+12+12+12 9+12+12+12+12 9+12+12+18 9+12+12+12+18 9+12+12+24 12+12+12+12+12 9+12+18+18 9+18+18+18 12+12+12+12 12+12+12+18...

  • Page 5: Dimension Of Outdoor Unit

    https://appliancetechmanuals.com 2. Dimension Of Outdoor Unit Model Unit： KSIM218-H221 33.3 14.3 27.6 36.0 21.3 13.8 inch 1034 KSIM327-H217 inch 37.2 16.5 31.9 40.6 26.5 15.9 1034 KSIM436-H217 37.2 16.5 31.9 40.6 26.5 15.9 inch 1333 1045 KSIM545-H219 inch 37.5 16.3 52.5 41.1 25.0...

  • Page 6: Refrigerant Cycle Diagram

    https://appliancetechmanuals.com 3. Refrigerant Cycle Diagram 4.1 Refrigeration circuit drawing of inverter 1 drives 2 type INDOOR OUTDOOR EXV A CAPILIARY A LIQUID VALVE A CHECK VALVE EXV B CAPILIARY B LIQUID VALVE B Condenser temp. sensor CAPILIARY TUBE HEAT HEAT EXCHANGE T4 Ambient T1 Room...
  • Page 7 https://appliancetechmanuals.com 4.3 Refrigeration circuit drawing of inverter 1 drives 4 type INDOOR OUTDOOR EXV A CAPILIARY A LIQUID VALVE A EXV B CAPILIARY B LIQUID VALVE B CHECK VALVE EXV C CAPILIARY C LIQUID VALVE C Condenser temp. sensor EXV D CAPILIARY D CAPILIARY TUBE LIQUID VALVE D HEAT...

  • Page 8: Installation Details

    https://appliancetechmanuals.com Additional refrigerant charge 4. Installation Details 1 drive 2 1 drive 3 1 drive 4 1 drive 5 5.1 Wrench torque sheet for installation Chargeless pipe 22.5 37.5 length (m) (49.2ft) (73.8ft) (98.4ft) (123ft) Additiona 15 x 15 x 15 x 15 x Outside diameter...
  • Page 9 https://appliancetechmanuals.com will create an acid that will damage the motor achieved, close the low pressure gauge windings and components. handle off and shut the vacuum pump off. Therefore, the indoor units and the pipes between Recheck the reading after 10 minutes, the indoor and outdoor units must be leak tested and vacuum may change slightly, this is normal.

  • Page 10: Adding The Refrigerant After Running The System For Many Years

    https://appliancetechmanuals.com 7). Mount the valve stems nuts and the service the system close the low pressure valve on the port cap. gauge manifold set and record the operating Be sure to use a torque wrench to tighten the pressure. The system is now charged and the service port cap to a torque 18N·m (13.27 ft·lbs).

  • Page 11: Procedure When Servicing The Indoor Unit Refrigeration Circuit

    https://appliancetechmanuals.com manifold set to start charging the unit with liquid running the compressor in a vacuum could refrigerant, keep track of the refrigerant being damage the motor windings. Note that units with added to the system (do not overcharge the extended lines and additional refrigerant charge system).

  • Page 12: Evacuation After Servicing The Outdoor Unit Refrigeration Circuit

    https://appliancetechmanuals.com 5.7 Evacuation after servicing the outdoor 2). Purge the air from the charge hose Open the valve at the bottom of the cylinder and press unit refrigeration circuit the check valve on the charge set to purge the air (be careful of the liquid refrigerant).

  • Page 13: Electronic Function

    https://appliancetechmanuals.com 6.3 Main Protection 6.3.1 Three Minutes Delay at restart for compressor. ---- 1min delay for the 1 time start-up and 3 minutes delay for others. 6.3.2 Temperature protection of compressor discharge. When the compressor discharge temperature is getting higher, the running frequency will be limited as below rules: ----If 221 ºF(105 ºC)≦T5<230 ºF (110ºC), keep the current frequency.
  • Page 14 https://appliancetechmanuals.com Note: if the low voltage protection occurs and not ºF resumes within 3min, it will keep the protection always after restart the machine. HeatT4Zone4I 6.3.6 Compressor current limit protection HeatT4Zone3I Temperature interval.of current limit is same as range of T4 limited frequency. HeatT4Zone2I Cooling mode: HeatT4Zone1I...

  • Page 15: Control And Functions

    https://appliancetechmanuals.com 6.3.10 Oil return According to the final capacity request to confirm the operating frequency, as following Running rules: table. 1. If the compressor frequency keeps lower than … COOL setting frequency for setting time, the AC will rise Frequency (Hz) L_F2 …...
  • Page 16 https://appliancetechmanuals.com 3)If the compressor cumulate running time is up to Then modify it according to T2 average 40 minutes and T3< -11ºF (-24C) for 3 minutes. (correction): 4)If the compressor cumulate running time is up to Note:Average value of T2：Sum T2 value of all 120 minutes and T3<-5ºF (-15ºC).
  • Page 17 https://appliancetechmanuals.com Outdoor temperature ºF Increase fan speed increase Supper high fan speed LowCoolT3_ON High fan speed Keep current fan speed LowCoolT3_Down Middle fan speed Decrease fan speed Low fan speed LowCoolT3_OFF Supper low fan speed Fan stop Breeze fan speed F fan speed G fan speed H fan speed...
  • Page 18 https://appliancetechmanuals.com starts. 3. The action priority of the EXVs is A-B-C-D-E. 4. Compressor and outdoor fan start operation only after EXV is initialized. 6.4.4.1 Cooling mode The initial open angle of EXV is depend on indoor model size, adjustment range is 100-400p. When the unit start to work for 3 minutes, the outdoor will receive indoor units( of capacity demand) T2B information and calculate the average of them.

  • Page 19: Wiring Diagrams

    7. Wiring Diagrams 8.1 Wiring diagram of 1 drive 2 outdoor KMIR218-H221 8.2 Wiring diagram of 1 drive 3 outdoor KMIR327-H217...
  • Page 20 https://appliancetechmanuals.com 8.3 Wiring diagram of 1 drive 4 outdoor KMIR436-H217...
  • Page 21 https://appliancetechmanuals.com 8.4 Wiring diagram of KMIR545-H219...

  • Page 22: Troubleshooting

    https://appliancetechmanuals.com 8. Troubleshooting 8.1Safety Because of there are capacitors in PCB and relative circuit in outdoor unit, even shut down the power supply, electricity power still are kept in capacitors, do not forget to discharge the electricity power in capacitor. The value of resistance is about 1500 ohm to 2000 ohm Electrolytic Capacitors (HIGH VOLTAGE! CAUTION!)

  • Page 23: Indoor Unit Error Display

    https://appliancetechmanuals.com The voltage in P3 and P4 in outdoor PCB is high voltage about 310V The voltage in P5 and P6 in outdoor PCB is high voltage about 310V 8.2 Indoor Unit Error Display Console series Operation Timer De-frost Failure ★...

  • Page 24: Outdoor Unit Display

    https://appliancetechmanuals.com  ★ ★ Outdoor fan has been out of control —— ★   Indoor fan speed has been out of control   ★ Voltage protection ★  Temperature protection of compressor top. ★ ★ ★ Outdoor unit over-current protection ——...
  • Page 25 https://appliancetechmanuals.com Push the switch SW1 to check the states of unit when the unit is running. The digital display tube will display the follow procedure when push SW1 each time. Display Remark Normal display Display running frequency, running state or malfunction code Quantity of indoor units in good connection Actual data Display...
  • Page 26 https://appliancetechmanuals.com A Indoor unit capacity demand code B Indoor unit capacity demand code Norm code*HP C Indoor unit capacity demand code (9K:1HP,12K:1.2HP,18K:1.5HP) D Indoor unit capacity demand code E Indoor unit capacity demand code Outdoor unit amendatory capacity demand code Forced cooling:7 The frequency corresponding to the total indoor units amendatory capacity demand...
  • Page 27 https://appliancetechmanuals.com Average value of T2 (Sum T2 value of all indoor units)/( number of indoor units in good connection) Outdoor unit fan motor state Off:0, High speed:1, Med speed:2, Low speed:3 Breeze:4, Super breeze:5 The last error or protection code 00 means no malfunction and protection F indoor unit capacity F Indoor unit capacity demand code...
  • Page 28 https://appliancetechmanuals.com 8.3.3 Outdoor unit error display Display LED STATUS Error Error (KDIR) (KSIE) Outdoor EEPROM malfunction Communication malfunction between indoor and outdoor units Communication malfunction between IPM board and outdoor main —— —— board Open or short circuit of outdoor temperature sensor (T3、T4、T5、 T2B) Voltage protection ——...

  • Page 29: Diagnosis And Solution

    https://appliancetechmanuals.com 8.4 Diagnosis and Solution 8.4.1 Indoor unit trouble shooting 8.4.1.1 Indoor EEPROM malfunction diagnosis and solution. Malfunction decision PCB main chip does not receive feedback from EEPROM chip conditions ● Installation mistake ● PCB faulty Trouble shooting: Shut off the power supply and turn it on 1 minute later.
  • Page 30 https://appliancetechmanuals.com 8.4.1.2 Communication malfunction between indoor and outdoor units diagnosis and solution. Malfunction decision Indoor unit does not receive the feedback from outdoor unit conditions during 120 seconds. ● Wiring mistake Supposed causes ● Indoor or outdoor PCB faulty Trouble shooting:...
  • Page 31 https://appliancetechmanuals.com Indoor / outdoor units communication error Start: Power off , then Power on the A/C by the Breaker. (reconnect the power wire). Is it still displaying the error code? Check wiring on the outdoor and indoor terminal follow the wiring diagram. Is all Reconnect the wiring connecting correctly? Reconnect the wiring...
  • Page 32 https://appliancetechmanuals.com Pic 1: Use a multimeter to test the DC voltage between L2 port and S port of outdoor unit. The red pin of multimeter connects with L2 port while the black pin is for S port. When AC is normal running, the voltage will move alternately between positive value and negative value.
  • Page 33 https://appliancetechmanuals.com PIC3: Main board LED when power on and unit standby. PIC 4: Check point button, press 1 time for check how many indoor units are connected.
  • Page 34 https://appliancetechmanuals.com 8.4.1.3 zero-crossing signal error diagnosis and solution. Malfunction decision When PCB does not receive zero crossing signal feedback for conditions 4 minutes or the zero crossing signal time interval is abnormal. Supposed causes ● Connection mistake ● PCB faulty Trouble shooting: Check if the connections and Correct the connections.
  • Page 35 https://appliancetechmanuals.com 8.4.1.4 Indoor fan speed has been out of control diagnosis and solution. Malfunction decision When indoor fan speed keeps too low (300RPM) for certain time, the unit conditions will stop and the LED will display the failure. Supposed causes ●...
  • Page 36 https://appliancetechmanuals.com Index 1: 1: Indoor AC fan motor Power on and set the unit running in fan mode at high fan speed. After running for 15 seconds, measure the voltage of pin1 and pin2. If the value of the voltage is less than 100V (208~240V power supply)or 50V(115V power supply), the PCB must have problems and need to be replaced.
  • Page 37 https://appliancetechmanuals.com 8.4.1.5 Open or short circuit of temperature sensor diagnosis and solution. Malfunction decision If the sampling voltage is lower than 0.06V or higher than conditions 4.94V, the LED will display the failure. Supposed causes ● Wiring mistake ● Sensor faulty ●...
  • Page 38 https://appliancetechmanuals.com 8.4.1.6 IPM module or IGBT over-strong current protection diagnosis and solution. Malfunction decision When the voltage signal that IPM send to compressor drive chip is abnormal, the display LED will show “P6” and AC will conditions turn off. ● Wiring mistake Supposed causes ●...
  • Page 39 https://appliancetechmanuals.com IPM module protection Check whether the voltage range Check whether the input Regulate it to correct, then of P-N on IPM module is normal? power supply is correct? check whether the system DC277-356V for 18-27KBtu/h; 208-230V, 1N, 60Hz can work normally? DC277-410V for 36KBtu/h Check whether the connecting line between main board and...
  • Page 40 https://appliancetechmanuals.com 8.4.1.7 Over voltage or too low voltage protection diagnosis and solution. Voltage protection Check the voltage of outdoor unit power supply, whether the voltage Check the power supply between L(L1) and N (L2) is about 187~253VAC Check whether the voltage of IPM board P and N is normal? DC277-356V for 18-27KBtu/h;...
  • Page 41 https://appliancetechmanuals.com 8.4.1.8 Temperature protection of compressor top diagnosis and solution. Malfunction decision If the sampling voltage is not 5V, the LED will display the conditions failure. ● Wiring mistake Supposed causes ● Over load protector faulty ● System block ● Outdoor PCB faulty Temperature protection of compressor top Whether compressor...
  • Page 42 https://appliancetechmanuals.com Water-level alarm malfunction (For cassette / ducted) 8.4.1.10 diagnosis and solution Malfunction decision If the sampling voltage is not 5V, the LED will display the conditions failure. ● Wiring mistake Supposed causes ● Water-level switch faulty ● Water pump faulty ●...
  • Page 43 https://appliancetechmanuals.com 8.4.1.11 Mode conflict. Error Code Malfunction decision The indoor units cannot work cooling mode and heating at same time. conditions Heating mode has a priority. ● Suppose Indoor unit A working in cooling mode or fan mode, and Unit action indoor unit B is set to heating mode, then A will change to off and B will work in heating mode.
  • Page 44 https://appliancetechmanuals.com 8.4.2 Outdoor unit trouble shooting 8.4.2.1 E0 (Outdoor EEPROM malfunction) error diagnosis and solution Error Code Malfunction decision PCB main chip does not receive feedback from EEPROM chip conditions Supposed causes ● Installation mistake ● PCB faulty Trouble shooting: Outdoor EEPROM malfunction Outdoor EEPROM malfunction Power off, then restart the...
  • Page 45 https://appliancetechmanuals.com 8.4.2.2 E2(Communication malfunction between indoor and outdoor units) error diagnosis and solution. Error Code Malfunction decision Indoor unit does not receive the feedback from outdoor unit conditions during 120 seconds or outdoor unit does not receive the feedback from any one indoor unit during 180 seconds. Supposed causes ●...
  • Page 46 https://appliancetechmanuals.com Communication malfunction between indoor and outdoor units Start: Power off , then Power on the A/C by the Breaker. (reconnect the power wire). Is it still displaying the error code? Check wiring on the outdoor and indoor terminal follow the wiring diagram. Is all Reconnect the wiring connecting correctly? Reconnect the wiring...
  • Page 47 https://appliancetechmanuals.com Pic 1: Use a multimeter to test the DC voltage between L2 port and S port of outdoor unit. The red pin of multimeter connects with L2 port while the black pin is for S port. When AC is normal running, the voltage will move alternately between positive value and negative value.
  • Page 48 https://appliancetechmanuals.com Pic 2: IPM (For qua-zone) Power, Self-Check Operating PIC3: Main board LED when power on and unit standby. PIC 4: Check point button, press 1 time for check how many indoor units are connected.
  • Page 49 https://appliancetechmanuals.com 8.4.2.3 E3 (Communication malfunction between IPM board and outdoor main board) error diagnosis Error Code Malfunction decision PCB main chip does not receive feedback from IPM module conditions during 60 seconds. ● Wiring mistake Supposed causes ● PCB faulty Trouble shooting: Communication malfunction between IPM board and outdoor main board...
  • Page 50 https://appliancetechmanuals.com Remark: Use a multimeter to test the DC voltage between black pin and white pin of signal wire The normal value should be around 5V. Use a multimeter to test the DC voltage between black pin and red pin of signal wire. The normal value should be around 12V.
  • Page 51 https://appliancetechmanuals.com 8.4.2.4E4(open or short circuit of outdoor temperature sensor) diagnosis and solution F1/F2/F3/F4/F5 (open or short circuit of indoor coil temperature sensor) diagnosis and solution. Error Code E4/F1/F2/F3/F4/F5 Malfunction decision If the sampling voltage is lower than 0.06V or higher than conditions 4.94V, the LED will display the failure.
  • Page 52 https://appliancetechmanuals.com 8.4.2.5 E5 (Voltage protection) error diagnosis and solution. Error Code Malfunction decision An abnormal voltage rise or drop is detected by checking the conditions specified voltage detection circuit. Supposed causes ● Power supply problems. ● System leakage or block ●...
  • Page 53 https://appliancetechmanuals.com IPM (for dual/tri- zone) IPM (for qua- zone) P-N (for dual/tri-zone)
  • Page 54 https://appliancetechmanuals.com P-N (for qua-zone)
  • Page 55 https://appliancetechmanuals.com bridge rectifier (for dual/tri-zone) bridge rectifier (for qua-zone)
  • Page 56 https://appliancetechmanuals.com Remark: Measure the DC voltage between + and - port. The normal value should be 190V~250V.
  • Page 57 https://appliancetechmanuals.com 8.4.2.7 E8 (Outdoor fan speed has been out of control) diagnosis and solution Error Code Malfunction decision When outdoor fan speed keeps too low (300RPM) or too high(2400RPM) conditions for certain time, the unit will stop and the LED will display the failure. Supposed causes ●...
  • Page 58 https://appliancetechmanuals.com 1. DC fan motor(control chip is inside fan motor)  Power on and when the unit is in standby, measure the voltage of pin1-pin3, pin4-pin3 in fan motor connector. If the value of the voltage is not in the range showing in below table, the PCB must have problems and need to be replaced.
  • Page 59 https://appliancetechmanuals.com...
  • Page 60 https://appliancetechmanuals.com 8.4.2.8 P0 (Temperature protection of compressor top) error diagnosis and solution. Error Code If the sampling voltage is not 5V, the LED will display the failure. Malfunction decision conditions ● Wiring mistake Supposed causes ● Over load protector faulty ●...
  • Page 61 https://appliancetechmanuals.com...
  • Page 62 https://appliancetechmanuals.com 8.4.2.9 P1 (High pressure protection) error diagnosis and solution. Error Code Malfunction decision If the sampling voltage is not 5V, the LED will display the conditions failure. ● Wiring mistake Supposed causes ● Over load protector faulty ● System block ●...
  • Page 63 https://appliancetechmanuals.com High pressure protection High pressure protection Whether the wiring Whether the wiring between the high pressure between the high pressure switch and main control switch and main control Connect it well Connect it well board is connected well or board is connected well or correctly correctly...
  • Page 64 https://appliancetechmanuals.com...
  • Page 65 https://appliancetechmanuals.com 8.4.2.10 P2 (Low pressure protection) error diagnosis and solution. Error Code Malfunction decision If the sampling voltage is not 5V, the LED will display the conditions failure. ● Wiring mistake Supposed causes ● Over load protector faulty ● System block ●...
  • Page 66 https://appliancetechmanuals.com Low pressure protection Low pressure protection Whether the wiring Whether the wiring between the low pressure between the low pressure protector and main control protector and main control Connect it well Connect it well board is connected well or board is connected well or correctly correctly...
  • Page 67 https://appliancetechmanuals.com...
  • Page 68 https://appliancetechmanuals.com 8.4.2.11 P3 (Current protection of compressor) error diagnosis and solution. Error Code Malfunction decision If the outdoor current exceeds the current limit value, the LED conditions will display the failure. ● Wiring mistake Supposed causes ● Over load protector faulty ●...
  • Page 69 https://appliancetechmanuals.com...
  • Page 70 https://appliancetechmanuals.com 8.4.2.12 P4 (Temperature protection of compressor discharge) error diagnosis and solution. Error Code Malfunction decision When the compressor discharge temperature(T5) is more than 239ºF (115ºC) for 10 seconds, the compressor will conditions stop andrestart till T5 is less than 194ºF (90ºC). ●...
  • Page 71 https://appliancetechmanuals.com 8.4.2.13 P5 (High temperature protection of condenser) error diagnosis and solution. Error Code When outdoor pipe temperature is more than 149ºF (65°C), the Malfunction decision unit will stop, and unit runs again when outdoor pipe temperature conditions is less than 126ºF (52°C). Supposed causes ●...
  • Page 72 https://appliancetechmanuals.com 8.4.2.14 P6 (IPM module protection) error diagnosis and solution. Error Code Malfunction decision When the voltage signal that IPM send to compressor drive chip is abnormal, the display LED will show “P6” and AC will conditions turn off. ● Wiring mistake Supposed causes ●...
  • Page 73 https://appliancetechmanuals.com IPM module protection Check whether the voltage range Check whether the input Regulate it to correct, then of P-N on IPM module is normal? power supply is correct? check whether the system DC277-356V for 18-27KBtu/h; 208-230V, 1N, 60Hz can work normally? DC277-410V for 36KBtu/h Check whether the connecting line between main board and...
  • Page 74 https://appliancetechmanuals.com 8.4. 2.15 The cooling operation or heating operation does not operate. ● 4-way valve faulty Supposed causes Check of 4-way, please refer to part 5 in 9.5 Trouble Criterion Of Main Parts. 8.4.2.16 When cooling, heat exchanger of non-operating indoor unit frosts. When heating, non-operating indoor unit get warm.
  • Page 75 https://appliancetechmanuals.com 8.5 Trouble Criterion Of Main Parts. Spec. Indoor unit KSIE009-H221-I KSIE012-H220-I KSIE018-H220-I KSIE024-H220-I Model Indoor fan motor WZDK20-38G WZDK20-38G WZDK58-38G WZDK60-38G KDIR09-H2 KDIR12-H2 KDIR18-H2 KDIR24-H2 Model Indoor fan motor WZDK55-38GS-W WZDK55-38GS-W WZDK90-38GS-W WZDK90-38GS-W KDIR09-H2 KDIR12-H2 KDIR18-H2 Model Indoor fan motor WZDK46-38G WZDK46-38G WZDK46-38G...
  • Page 76 https://appliancetechmanuals.com 1.Temperature sensor checking Disconnect the temperature sensor from PCB, measure the resistance value with a tester. Temperature Sensors. Room temp.(T1) sensor, Indoor coil temp.(T2) sensor, Outdoor coil temp.(T3) sensor, Outdoor ambient temp.(T4) sensor, Compressor discharge temp.(T5) sensor. Measure the resistance value of each winding by using the multi-meter.
  • Page 77 https://appliancetechmanuals.com Appendix 1 Temperature Sensor Resistance Value Table (ºC-K) ºF ºF ºF ºF K Ohm K Ohm K Ohm K Ohm 12.6431 2.35774 0.62973 115.266 108.146 12.0561 2.27249 0.61148 101.517 11.5000 2.19073 0.59386 96.3423 10.9731 2.11241 0.57683 89.5865 10.4736 2.03732 0.56038 84.2190 10.000...
  • Page 78 https://appliancetechmanuals.com Appendix 2 Unit: ºF-K Discharge temp. sensor table 542.7 68.66 13.59 3.702 511.9 65.62 13.11 3.595 62.73 12.65 3.492 455.9 59.98 12.21 3.392 430.5 57.37 11.79 3.296 406.7 54.89 11.38 3.203 384.3 52.53 10.99 3.113 363.3 50.28 10.61 3.025 343.6 48.14 10.25...
  • Page 79 https://appliancetechmanuals.com Appendix 3: ℃ 10 11 12 13 14 15 16 17 18 19 20 21 22 ℉ 48 50 52 54 56 58 60 62 64 66 68 70 72 ℃ 23 24 25 26 27 28 29 30 31 32 33 34 35 ℉...
  • Page 80 https://appliancetechmanuals.com 3. IPM continuity check Turn off the power, let the large capacity electrolytic capacitors discharge completely, and dismount the IPM. Use a digital tester to measure the resistance between P and UVWN; UVW and N. Normal Normal resistance Digital tester Digital tester resistance value...
  • Page 81 https://appliancetechmanuals.com Position Resistance Value YDK53- YDK70-6FB YDK180-8GB YSK27-4G YSK68-4B YDK45-6B YSK25-6L 6FB(B) 56Ω±8% 24.5Ω±8% 317Ω±8% 145Ω±8% 345Ω±8% 627Ω±8% 88.5Ω±8% Black - (68 ºF - 20 ºC) (68 ºF - 20 ºC) (68 ºF - 20 ºC) (68 ºF - 20 ºC) (68 ºF - 20 ºC) (68 ºF - 20 ºC) (68 ºF - 20 ºC)
  • Page 82 https://appliancetechmanuals.com 6.EXV check Disconnect the connectors.
  • Page 83 https://appliancetechmanuals.com Resistance to EXV coil Color of lead wire Normal Value Red- Blue Red - Yellow About 50Ω Brown-Orange Brown-White...
  • Page 84 https://appliancetechmanuals.com Red- Blue Red - Yellow...
  • Page 85 https://appliancetechmanuals.com Brown-Orange Brown-White...
