WALL MOUNTED SPLIT-TYPE AIR CONDITIONERS SERVICE MANUAL Models KSWT009-C/H113 KSWT012-C/H113 KSWT018-C/H213 KSWT024-C/H213 CONTENTS 1. IMPORTANT NOTICE ······························2 2. TECHNICAL SPECIFICATION ···················3 3. OPERATION DETAILS ······························4... -
Page 2: Important Notice
Air Conditioner Service Manual IMPORTANT NOTICE This service manual is intended for use by individuals possessing adequate background of electrical, electronic and mechanical experience. It is to be installed and serviceG by a licensed HVAC technician. Any attempt to repair the appliance may result in personal injury and property damage. -
Page 3: Operation Details
Air Conditioner Service Manual Operation Details Remote control Remote control The remote control transmits signals to the system. ON/OFF button Used to start and stop operation when pressed. TIMER button SLEEP TIMER ON TMIER OFF AUTO FEEL HIGH COOL Used to select TIMER operation. HEAT SWING UP button (TOO COOL button) -
Page 4: Remote Control
Air Conditioner Service Manual REMOTE CONTROL GYKQ-05... - Page 6 Air Conditioner Service Manual Room Temp. Set TEMP. + 1.8º F Set TEMP. ˉ1.8º F Time More than 2 min More than 2 min More than 2 min More than 2 min More than 2 min Indoor Fan Set Speed Set Speed Set Speed Set Speed...
- Page 8 Air Conditioner Service Manual Defrosting time chart Outdoor Fan Revering V alve Compressor Relay ON 39S 5S Defrost Count MAX 12min 19S 15S “FAN” mode operation The indoor fan motor always turns on at the set speed and the vane motor turns on at the set fettle. 7.
- Page 9 Air Conditioner Service Manual motor is shut off. 10 seconds later, the electric current is applied to the fan motor again. During the fan motor lock-up, the POWER indicator lamp flashes on and off 6times/cycle or E6 to show the fan motor abnormality.
- Page 10 Air Conditioner Service Manual Press the Timer button(‘h’ flashes). Use the button to select the time at which the air conditioner must activate (between 0 and 10 hours can be set at every half hour-between 10 and 24 hours can be set at every hour). Press the Timer button (‘h’...
- Page 11 Air Conditioner Service Manual this, it displays the failure and the protection is failing. You must power off/on to operate it. In the failure, you can operate the FAN mode. When the outdoor protects in the COOLING or DRY, the outdoor unit stops, the indoor fan operates in set speed ;...
- Page 12 The Klimaire logo is a registered Trademark of Klimaire Products inc. Copyright 2010 Klimaire Products inc. 2190 NW 89 Place, Doral, FL 33172 - USA Tel: (305)594-4972 Fax (305) 675-2212 www.klimaire.com sales@klimaire.com...
