- Page 1 KSIM UNITS User´s Manual...
-
Page 2: Table Of Contents
CONTENTS SOCIABLE REMARK Sociable remark..........................2 SAFETY PRECAUTIONS Warning ............................3 Caution .............................4 OPERATING INSTRUCTIONS Parts names .............................5 Operating temperature........................7 Manual operation..........................7 Airflow direction control ........................8 How the air conditioner works ......................9 CARE AND MAINTENANCE Care and maintenance ........................10 OPERATION TIPS Operation tips ..........................12 TROUBLESHOOTING TIPS Troubleshooting tips ........................14 CAUTION... -
Page 3: Sociable Remark
SOCIABLE REMARK When using this air conditioner in the European countries, the follow information must be followed: DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. It is prohibited to dispose of this appliance in domestic household waste. For disposal, there are several possibilities: A) The municipality has established collection systems, where electronic waste can be disposed of at least free of charge to the user. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The seriousness is classified by the following indications. This symbol indicates the possibility of death or serious injury. -
Page 5: Caution
SAFETY PRECAUTIONS CAUTION When the air filter is to be Do not clean the air Ventilate the room well conditioner with water. when used together removed, do not touch the with a stove, etc. metal parts of the unit. It may cause an injury. Water may enter the unit and An oxygen shortage degrade the insulation. -
Page 6: Operating Instructions Parts Names
OPERATING INSTRUCTIONS Parts names Indoor unit Indoor unit Air inlet 1. Signal receptor 2. LCD Display window 3. Panel frame 4. Chassis 5. Front panel 6. Horizontal louver 7. Vertical louver 8. Air filter 9. Manual control button Remote controller holder 11. - Page 7 OPERATING INSTRUCTIONS TIMER display FAN SPEED display Illuminated during Timer operation. Displayed the selected fan speed: AUTO and three fan speed CLEAN AIR display(optional) levels: LOW( ), MED( ) and Illuminated when Ionizer is activated. HIGH( Operation Frequency display TURBO operation display Illuminated when select TURBO This display is separated into five function on cooling operation or...
-
Page 8: Operating Temperature
OPERATING INSTRUCTIONS NOTE: This manual does not include Remote Controller Operations, see the <<Remote Controller Instruction>> packed with the unit for details. Operating temperature Mode Cooling operation Heating operation Drying operation Temperature > 62 F Room temperature >50 F <86 F 64 F 122 F 5 F 83 F 50 F 122 F... -
Page 9: Airflow Direction Control
OPERATING INSTRUCTIONS Airflow direction control Adjust the air flow direction properly otherwise, it might cause discomfort or cause uneven room temperatures. Adjust the horizontal louver using the remote controller. ¡£ SET TEMPERATURE( F) ( C) Adjust the vertical louver manually. AUTO HIGH COOL... -
Page 10: How The Air Conditioner Works
OPERATING INSTRUCTIONS How the air conditioner works AUTO operation SLEEP operation 7 hours timer off When you set the air conditioner in AUTO mode, it will automatically select cooling, heating(cooling/heating models only), or fan only operation depending on what temperature you have selected and the room temperature. Temperature The air conditioner will control room temperature automatically round the temperature point set by you. -
Page 11: Care And Maintenance
CARE AND MAINTENANCE Care and maintenance Cleaning the Grille, Case and Remote Controller Turn the system off before cleaning. To clean, wipe with a soft, dry cloth. Do not use bleach or abrasives. Household Drain NOTE: Supply power must be disconnectd before Cleaner cleaning the indoor unit. - Page 12 CARE AND MAINTENANCE 3. Remove the AIR FILTER from the indoor unit. Clean the AIR FILTER once two weeks. Clean the AIR FILTER with a vacuum cleaner or water, then dry it up in cool place. 4. Remove the Air Freshening Filter(Optional filter: Silver Ion filter /Bio filter / Vitamin C filter/3M air purifier filter) from its support frame.
-
Page 13: Operation Tips
OPERATION TIPS The following events may occur during normal operation. 1. Protection of the air conditioner. Compressor protection The compressor can't restart for 3 minutes after it stops. Anti-cold air (Cooling and heating models only) The unit is designed not to blow cold air on HEAT mode, when the indoor heat exchanger is in one of the following three situations and the set temperature has not been reached. - Page 14 OPERATION TIPS 7. Dripping water may generate on the surface of the indoor unit when cooling in a high relatively humidity (relative humidity higher than 80%). Adjust the horizontal louver to the maximum air outlet position and select HIGH fan speed. 8.
-
Page 15: Troubleshooting Tips
TROUBLESHOOTING TIPS Troubleshooting Tips Stop the air conditioner immediately if one of the following faults occur. Disconnect the power and contact the nearest customer service center. If the following code appears on the LED window, disconnect the power and contact the service people: E0,E1,E2,E3,E4,E5,E6,E7,E8 or P0,P1,P2,P3,P4. - Page 16 KSIM UNITS Klimaire Products Inc. Miami, FL. 33166 Toll Free: 1-800-KLIMAIRE www.klimaire.com...
