Police Force PFTB12R Instruction Manual

Triple Stun
Contact Probes
CREE LED
Flashlight
Important: Before using we recommend that you take time to familiarize yourself with this unit. The key to understanding how it operates is the
"Function-Select Button." Each time this button is pressed, the function changes in the following order: Light, Stun, Off. To help you remember the
order, the corresponding symbol is shown below the Function-Select Button:

Inserting and Charging the Rechargeable Batteries

1. We recommend fully charging the rechargeable batteries before inserting them into the unit. To do so, insert both 18650 4000mAh 3.7V li-ion batteries
(included) into the charging port according to the polarity diagram shown on the port. If the batteries are inserted correctly a red light will illuminate on the
charging port. Next, plug the slide-out plug into a standard wall outlet. When plugged into a standard wall outlet, a red light on the wall charger will come
on while the batteries are charging and change to green when completely charged. IMPORTANT: Do not charge for more than 8 hours at a time.
Overcharging can damage the batteries and void the warranty. If the flashlight becomes dim or if the electrical stun current becomes noticeably weaker,
the batteries will need to be charged. When not in use, charge the batteries every 60 days to ensure the unit will function optimally when needed.
2. To insert the batteries into the stun baton, unscrew the end cap by turning it in a counterclockwise direction (See above diagram for location to unscrew).
3. Insert the batteries according to the polarity diagram below. IMPORTANT: Batteries must be inserted as shown below. Inserting the batteries incorrectly
could damage the unit and void the warranty. Replace the end cap by turning in a clockwise direction until snug. Do not over tighten.

Using the Flashlight

Overview: This unit features three (3) light strengths (Maximum, Medium, & Low) and two light patterns (SOS & Strobe). When the situation does not require
maximum light strength, the lower light settings can be used to extend the battery life.
1. Fully press the Push-Button Tail Switch. You will hear the button click and the green LED will come on indicating that the power to the unit is on. If the
Function – Select Button is in Light mode the flashlight will turn on. If the flashlight does not turn on see #3 below.
2. Once the flashlight turns on you can change the light mode by Half Pressing either the Push-Button Tail Switch or the Function-Select Button. If you press
either of these buttons too hard you will hear a click and the flashlight will turn off.
3. If you press the Push-Button Tail Switch and the flashlight does not turn on, then the Function-Select Button is either set to Stun or OFF mode. If both the
green and red LED lights are on, then it is in Stun mode. Fully press (you will hear a click) the Function-Select Button two times to get to Light mode. If
only the green light is on, but the flashlight is not, it is in the OFF mode. Fully press (you will hear a click) the Function-Select Button one time to get to
Light mode.
4. To turn off the light, fully press
5. If you turn the light off by fully pressing
pressing 1 the Function-Select Button, be careful to note that you are now in stun mode (red light will be ON) and pressing the Stun Activation Button will
activate the stun feature. To return to light function, you will need to fully press
Testing the Stun Baton (WARNING: Do not test fire the stun baton for more than 1 second as this will damage the unit and void the warranty.)
1. Fully press the Push-Button Tail Switch to turn on the unit. If both the red and green LED lights turn on it is in stun mode and ready to test the stun baton.
1
Go to #3 below. If only the green LED is on and the flashlight is on it is in the Light mode. Fully press
STUN mode. If only the green LED is on and the flashlight is off it is in the OFF mode. Fully press
STUN mode.
2. Be sure both the red and green LED lights are on to confirm it is in the STUN Mode.
Full Press: When full y pressed, you will hear a cli c king sound.
1
PFTB12R
Instruction Manual
Stun Mode ON: Red Light
Pow er Indicator: Green Light
Positive ( + )
either the Function-Select Button or the Push-Button Tail Switch.
1
the Push-Button Tail Switch, you will need to press this same button again to turn it on. If you turn it off by fully
1
Stun Activation Button
Function-Select Button
(Light, Stun, Off)
Push-Button Tail Sw itch (Not Show n):
o Full Press
o Half Press changes light mode.
for Light, for stun, and
Negative ( - )
the Function-Select Button two more times.
1
the Function-Select Button one time to move to the
1
the Function-Select Button two times to move to the
1
Unscrew Here to
Insert Batteries
1
turns unit On/Off.
for off.
End Cap
Rev ised: 08-03-2016
