Police Force PFT6F52 Instruction Manual

Charging the 18650 Battery

Warning: Never attempt to charge standard (non-rechargeable) batteries. Doing so could result in injury and

will void the warranty.

This unit operates on one rechargeable 18650 Li-Ion battery (included) and we recommend fully charging it first. To do

so, insert the battery into the home charger following the polarity diagram shown on the charger. Flip out the charging

plug on the back of the charger and plug it into a standard wall outlet.

Important: Do not charge for longer than 3 hours or continue to charge once the light on the charger turns

green. Once the light on the charger changes from red to green, the battery is fully charged and should be

removed from the charger.

1. To access the battery compartment, unscrew the end cap (at the opposite end of the light) by turning it

counterclockwise.

2. Insert the fully charged battery into the flashlight. The positive (+) end of the battery should be inserted first

(toward the head of the light) as shown in the diagram below. Screw the end cap back on by turning it clockwise.

PFT6F52

Instruction Manual

Slide Zoom

Included Li-Ion Battery

Positive

Unscrew Here to Insert Battery

Belt Clip

Home Charger

(Flip Plug)

Negative

End Cap

Push Button Tail Switch

(Not Shown)

Revised 09-29-2016

Table of Contents

Do you have a question about the PFT6F52 and is the answer not in the manual?

Page 1 PFT6F52 Instruction Manual End Cap Unscrew Here to Insert Battery Slide Zoom Push Button Tail Switch (Not Shown) Belt Clip Included Li-Ion Battery Home Charger (Flip Plug) Charging the 18650 Battery Warning: Never attempt to charge standard (non-rechargeable) batteries. Doing so could result in injury and will void the warranty.
Page 2 4. To turn the flashlight off, press the rubber Push Button Tail Switch until it clicks. WARRANTY: Streetwise Security Products extends a Lifetime warranty to the PFT6F52 for the product against defects in materials or workmanship, with the following exceptions: 1.
