Police Force PFTTS17 Quick Start Manual

Contact Probes
LED Flashlight

CHARGING BATTERIES

1. We recommend fully charging the rechargeable batteries before inserting them into the unit. To do so, insert both 18650
batteries (included) into the charger according to the polarity diagram shown on the charger. If the batteries are inserted
correctly a red light will illuminate. Next, insert the flip-out plug into a standard wall outlet. When plugged in, a red light on
the charger will come on while the batteries are charging. Charge unit for 4-6 hours. IMPORTANT: Do not charge for
more than 6 hours at a time. Overcharging can damage the batteries and will void the warranty. If the flashlight
becomes dim or if the electrical stun current becomes noticeably weaker, the batteries will need to be charged. When not in
use, charge the batteries every 60 days to ensure the unit will function optimally when needed.
2. To insert the batteries into the stun baton, unscrew the end cap by turning it in a counterclockwise direction. Insert the
positive end of the batteries first. Screw the tail switch back on.

USING THE FLASHLIGHT

Note: When the Power ON/OFF Push Button Tail Switch is turned on, fully pressing the Power/Mode Button changes the mode
from Light, Stun, to Stand-by.
1. Press the Power ON/OFF Push Botton Tail Switch until the flashlight turns on. Half press either the Power/Mode Button or
the Power ON/OFF Tail Switch Button to select one of the following light settings: Hi, Medium, Low, Strobe or SOS.
2. Fully press the Power/Mode Button to remove the safety and enable the Stun Activation Button. The Stun Warning Light will
change to red or orange, indicating the unit is now in stun mode.
3. Fully press the Power/Mode Button once more to enter the standby mode. (NOTE: Press the Power ON/OFF Tail Switch
button to power off the unit.)
Tactical Torch 17,000,000 Stun Flashlight
Stun Activation
Button
Stun Warning Light
PFTTS17
Power/Mode Button
(2) 18650 Batteries
Power ON/OFF Push Button
Tail Switch
Rev 4/13/2021
