PT4500-PEDESTAL
15" Teleprompter, Pedestal & Dolly Turnkey
OVERVIEW
Ikan's Turnkey Broadcast Solutions include everything you need for your professional camera setup. This solution includes a 15" teleprompter,
pedestal, and dolly. All of our systems have been tested internally for payload compatibility.
The remaining payload capacity, after mounting the full 15" teleprompter system, can accommodate camera setups up to 19 lbs. The pedestal,
without the teleprompter system, can accommodate cameras up to 41.1 lbs. This solution also includes a hard case for the teleprompter &
carrying bag for the pedestal.
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com
Quick Start Guide
Advertisement
Related Manuals for Ikan PT4500-PEDESTAL
Summary of Contents for Ikan PT4500-PEDESTAL
- Page 1 15” Teleprompter, Pedestal & Dolly Turnkey OVERVIEW Ikan’s Turnkey Broadcast Solutions include everything you need for your professional camera setup. This solution includes a 15” teleprompter, pedestal, and dolly. All of our systems have been tested internally for payload compatibility.
- Page 2 PT4500 What’s Included 15” High Bright Beam Splitter Teleprompter 1 x Teleprompter Base 1 x Bracket with Glass 1 x Teleprompter Hood with Boot 1 x Monitor 1 x AC Adapter with Cord 1 x PrompterPro Software 1 x Counterweight Set (2 x 2.5 lbs) 2 x D-Ring ¼-20”...
- Page 3 Step 3 Step 4 The metal frame is directional. Make sure the thicker side is on top and Put the washers on before tightening the screws. The washers and 4 the slimmer side is on the bottom. additional screws are inside a bag on the bottom foam. Step 5 Step 6 Extend the teleprompter hood open and attach teleprompter boot...
- Page 4 Step 7 Attach the monitor mounts on the back of the monitor’s VESA compatible threads using the 4 included screws and provided 2mm hex key. Step 8 After the monitor mounts are attached, adjust the 15mm rods to accommodate the monitor. Leave about 1 inch of room for the teleprompter bracket. Make sure the 15mm rods go through both set of monitor mounts.
- Page 5 Foam Case To make your teleprompter more portable, we packed it in a reusable, high-quality foam. The shape and size of the foam was designed to fit into Ikan’s PT-CASE-V2. ** DO NOT THROW AWAY FOAM CASE ** www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
-
Page 6: Monitor Ports
Monitor Ports Monitor Menu Settings Video Config Contrast (White Level) Brightness (Black Level) Tint (Chroma Hue) Chroma (Chroma Saturation) Sharpness (Detail) RGB Setup – Manually configure RGB Return System Config Menu Duration – Set duration of how long menu stays on screen Video Ratio –... -
Page 7: Specifications
Watch our VIDEO TUTORIAL on how to assemble Ikan Professional Telepromopters https://youtu.be/5TjIxzBc_Vc Specifications PT4500 Aspect Ratio Backlight Brightness 1000 nits Build Material Aluminum Diagonal 15” Input Signal Composite BNC, VGA, HDMI Input Voltage DC 12v / 4A Power Consumption Reading Range 17’... -
Page 8: Learn More
Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company. • Damage caused by natural disaster, abnormal voltage, and environmental factors, etc. ©2021 Ikan International. All rights reserved. www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com... - Page 9 AT7903 Pedestal PGRADE VERSION 184.5cm 20.0kg 72.6in 44.1lbs 15.8kg 102.0cm 40.2in 34.8lbs 32.0cm 100mm 12.6in Component: Pedestal AT7903 Dolly EI-7005 Pneumatic assist center Easy height-adjustment Quick locking Ergonomic hand wheel column lever...
- Page 10 GH20 100mm Fluid Head 212mm/8.3in 100mm 73mm/2.9in 20.0kg 175mm/6.9in 44.0lbs FEATURES Leveling bubble Fixed drag of pan & tilt Longer sliding plate 8 plus 0 steps of counterbalance SPECIFICATIONS Model GH20 Payload Range 20.0kg / 44.0lbs Counterbalance Range Grades Of Pan Drag Fixed Grades Of Tilt Drag Fixed...
- Page 11 EI-7005 Video dolly Super sturdy,designed for heavy duty systems.The 100mm/4 inch wheels can be individually braked. Folds for transporting. Φ 6.8kg 100cm 100.0kg 100mm 18.5cm 39.4in 4.0in 7.3in 15.0lbs 220.5lbs FEATURES 50cm 18.5cm 100mm Pull the knob to extend the dolly, Height : 18.5cm / 7.3in Casters diameter: 100mm / 3.9in.
- Page 12 Pan bar Telescopic pan bar for GH08L, GH10L, GH15, GH25 heads SPECIFICATIONS Length range 405-605mm / 15.9-23.8in Net weight 385g / 0.8lbs...
