ORIGINAL MANUAL ISSUE DATE: 2022.05
Model:
XR-55A95K
XR-65A95K
Conditions of Use:
(1) Please use this information only for the purpose of performing repair and recycling Sony products. Using this information
for any purpose other than the purpose described foregoing is forbidden.
(2) Do not copy, replicate, reproduce, alter, translate, transmit, sell, lease, or distribute this information in whole or in part
without the prior written permission of the author.
Revision of Information:
This information may be changed or updated at any time without any prior notice. Please confirm that this information is up-to-
date before using it.
Dismantling Information forUse
by Professional Recyclers
9-888-902-41
OLED TV
Sony EMCS (Malaysia) Sdn. Bhd., HES-M
© 2022.05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR-55A95K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony XR-55A95K

Summary of Contents for Sony XR-55A95K

  • Page 1 OLED TV Conditions of Use: (1) Please use this information only for the purpose of performing repair and recycling Sony products. Using this information for any purpose other than the purpose described foregoing is forbidden. (2) Do not copy, replicate, reproduce, alter, translate, transmit, sell, lease, or distribute this information in whole or in part without the prior written permission of the author.

  • Page 2: Model Lists

    MODEL LISTS Model Remote Destination RMT-TX440E RMF-TX900U XR-55A95K RMF-TX900U CEI , UKA RMT-TX440E XR-65A95K RMF-TX900U CEI , UKA RMT-TX440E...

  • Page 3: Optional Equipments

    TOOLS & EQUIPMENTS 1 LIST OF ITEMS TO BRING i. Screwdriver (e.g., #2 Phillips Screwdriver) ii. Multimeter iii. ESD Wrist Straps iv. Metal Washer (Flat) or Coin (for remove Rear Cover) v. Ruler (for remove Rear Cover) vi. Service Manual (Unique) (for remove & replace details) Thickness: approx.

  • Page 4: Safety Notes

    Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that are critical for safe operations are identified in this manual.
  • Page 5 SAFETY NOTES Refer to the panel handling chapter of each Service manual, or the "Transporting" information of 1-2. Caution for OLED Panel. the Reference Guide of each model on how to hold it. 1) Handling. When repairing the TV set, be sure you are grounded by using a wrist band. 2) OLED Screen.
  • Page 6 SAFETY NOTES Pixel shift. To reduce the risk of image retention: Automatically moves the image on the screen to prevent image retention. • Fill the screen by changing [Wide mode] to eliminate the black bars. Select [Wide mode] other than [Normal]. •...

  • Page 7: Safety Check-Out

    SAFETY NOTES 1-3. Safety Check-Out Stabilized power supply instrument and isolated voltage transformer: Use too much current capacity and isolated voltage transformer does not need to use After correcting the original service problem, perform the following safety checks stabilized power supply equipment. before releasing the set to the customer:- Specification of RMS volt meter: Input resistance >...

  • Page 8: Lead Free Information

    SAFETY NOTES 1-5. How to Find a Good Earth Ground. 1-6. Lead Free Information 1) A cold-water pipe is a guaranteed earth ground; the cover-plate retaining screw on The circuit boards used in these models have been processed using Lead Free Solder. The most AC outlet boxes is also at earth ground.
  • Page 9 DISASSEMBLY AND REMOVAL CAUTION 55” REAR COVER Notes : If the table-top style is the front position, change it to the back position Front position Back position Remove the SET from the stand, flip it over, and insert it into the stand and then screw tightening.
  • Page 10 DISASSEMBLY AND REMOVAL CAUTION 55” REAR COVER 1. Release screw which is quantity 10 pcs, and it can be done with two conditions : Face down Upright i. Face Down ii. Upright...
  • Page 11 DISASSEMBLY AND REMOVAL CAUTION 55” REAR COVER 2. Release Recess Hook ⑤ ④ ① ③ ② ii. Upright i. Face Down ① Insert hand into the gap and release the Rear Cover ⑤ ② Release hooks from 1 to 5 ⑤...
  • Page 12 DISASSEMBLY AND REMOVAL CAUTION 55” REAR COVER 3. Release Right Side Hook ① ① Lightly press the left side of the hook ② Insert hand into the gap and lift the Rear Cover. ③ Release 1 hook ii. Upright i. Face Down...
  • Page 13 DISASSEMBLY AND REMOVAL CAUTION 55” REAR COVER 4. Release Left Side Hook ③ ① Insert hand into the gap and lift the Rear Cover. ② ② Lightly press the right side of the hook. Insert hand into the gap and lift the Rear Cover and release hook. ①...
  • Page 14 DISASSEMBLY AND REMOVAL CAUTION 55” REAR COVER 5. Release Bottom Hook ① Lift the bottom of Rear Cover. ② Release Hook ①,② ① ② ii. Upright i. Face Down...
  • Page 15 DISASSEMBLY AND REMOVAL CAUTION 55” REAR COVER 6. Release Top Hook ① Move the Rear Cover toward the top of the TV and remove the hook on the top side ② Release 8 hooks in the same time hook. ii. Upright i.
  • Page 16 DISASSEMBLY AND REMOVAL CAUTION 55” REAR COVER 7. Hook Positioning Panel Outline Panel Outline Panel Outline Panel Outline : Position to press...

  • Page 17: Exploded View And Part List

    EXPLODED VIEW & PART LIST 55” • Place the TV set facing downwards on a stable, level surface before disassembly and assembly of parts.  (*) Parts are not stocked since they are seldom required for routine service. Some delays should be anticipated when ordering these components.
  • Page 18 EXPLODED VIEW & PART LIST 55” • Place the TV set facing downwards on a stable, level surface before disassembly and assembly of parts.  (*) Parts are not stocked since they are seldom required for routine service. Some delays should be anticipated when ordering these components.
  • Page 19 EXPLODED VIEW & PART LIST 55” SET PART LIST REMARKS REF. NO PART NO. DESCRIPTION A-5041-914-A COMPL SVC BM5S22_FD_EUUK Printed Circuit Board, incl. capacitors 1-013-517-11 G212 - STATIC CONVERTER(TV) Internal Power Supply A-5045-536-A P-MOD(S55FF1)(SVC) Liquid Crystal Display OTHER PART POWER-SUPPLY CORD SET(EU) 1-912-832-11 Cable 1-002-007-11...
  • Page 20 EXPLODED VIEW & PART LIST 55” CONNECTOR REF. NO PART NO. DESCRIPTION REMARKS 1-014-834-11 FLEXIBLE FLAT CABLE 51P CN6800(B)-CN5(TCON)(1) 1-014-833-11 FLEXIBLE FLAT CABLE 41P CN6801(B)-CN7(TCON)(1) 1-014-818-11 FLEXIBLE FLAT CABLE 25P CN102(H)-CN1200(B)(1) 1-014-817-11 FLEXIBLE FLAT CABLE 20P CN3803(B)-BT(1) 1-014-819-11 FLEXIBLE FLAT CABLE 25P(C) CN3804(B)-CAMERA(1) 1-014-898-11 CONNECTOR ASSY 30P...

  • Page 21: Front Position

    DISASSEMBLY AND REMOVAL CAUTION 65" REAR COVER Notes : If the table-top style is the front position, change it to the back position Front position Back position Remove the SET from the stand, flip it over, and insert it into the stand and then screw tightening.
  • Page 22 DISASSEMBLY AND REMOVAL CAUTION 65" REAR COVER 1. Release screw which is quantity 10 pcs, and it can be done with two conditions : Face down Upright ii. Upright i. Face Down...
  • Page 23 DISASSEMBLY AND REMOVAL CAUTION 65" REAR COVER 2. Release Recess Hook ① Insert hand into the gap and release the Rear Cover ⑤ ② Release hooks from 1 to 5 ④ ① ③ ② ii. Upright i. Face Down ⑤ ⑦...
  • Page 24 DISASSEMBLY AND REMOVAL CAUTION 65" REAR COVER 3. Release Bottom Hook ① Press the corner of the recess. ② Insert hand into the gap and lift the Rear Cover. ③ Release the hook Then repeat step 1 to 3 with second screw ①...
  • Page 25 DISASSEMBLY AND REMOVAL CAUTION 65" REAR COVER 4. Release Side Hooks ④ ① Insert hand into the gap and lift the Rear Cover. ③ ② Release the hooks in order from the bottom.. ② ① i. Face Down ii. Upright...
  • Page 26 DISASSEMBLY AND REMOVAL CAUTION 65" REAR COVER 5. Release Top Hooks ① Lift the bottom of Rear Cover. ② Move the Rear Cover toward the top of the TV and remove the hook on the top side. (10 places at the same time) i.
  • Page 27 DISASSEMBLY AND REMOVAL CAUTION 65" REAR COVER 6. Hooks Positioning Panel Outline Panel Outline Panel Outline Panel Outline : Position to press...
  • Page 28 EXPLODED VIEW & PART LIST 65” • Place the TV set facing downwards on a stable, level surface before disassembly and assembly of parts.  (*) Parts are not stocked since they are seldom required for routine service. Some delays should be anticipated when ordering these components.
  • Page 29 EXPLODED VIEW & PART LIST 65” • Place the TV set facing downwards on a stable, level surface before disassembly and assembly of parts.  (*) Parts are not stocked since they are seldom required for routine service. Some delays should be anticipated when ordering these components.
  • Page 30 EXPLODED VIEW & PART LIST 65” SET PART LIST REMARKS REF. NO PART NO. DESCRIPTION Printed Circuit Board, incl. capacitors A-5041-914-A COMPL SVC BM5S22_FD_EUUK 1-013-518-11 Internal Power Supply G213 - STATIC CONVERTER(TV) A-5045-537-A P-MOD(S65FF1)(SVC) Liquid Crystal Display OT HERS PART 1-002-007-11 C17 AC CORD SET(SWISS) Cable...
  • Page 31 EXPLODED VIEW & PART LIST 65” CONNECTOR REF. NO PART NO. DESCRIPTION REMARKS 1-014-836-11 FLEXIBLE FLAT CABLE 51P CN6800(B)-CN5(TCON)(1) 1-014-835-11 FLEXIBLE FLAT CABLE 41P CN6801(B)-CN7(TCON)(1) 1-014-823-11 FLEXIBLE FLAT CABLE 25P CN102(H)-CN1200(B)(1) 1-014-822-11 FLEXIBLE FLAT CABLE 20P CN3803(B)-BT(1) 1-014-824-11 FLEXIBLE FLAT CABLE 25P(C) CN3804(B)-CAMERA(1) 1-014-898-11 CONNECTOR ASSY 30P...
  • Page 32 Sony EMCS (Malaysia) Sdn. Bhd. English HES-M 9-888-902-41 © 2022.05...
