AV Link 128.841UK User Manual

Stylish, slimline HDMI switch that allows a single display to be connected to up to 3 HDMI sources and
selected using the IR remote control or button on the unit. Gold plated connections ensure optimum signal
transfer and the LED's on the front of the unit inform you as to which of the inputs are live at any one time.
This updated version has a smart switching function and will support HDMI v2.0 signals, compatible with the
latest 4K digital TV boxes producing 3840 x 2160 @ 60Hz resolutions.
Technical Specifications:
HDMI version
Video format
Display colours
Audio format
Max. bandwidth
Max. baud rate
Max. working current
Transmission distance
Operating temperature range
Battery : remote
Power adaptor
Dimensions
Weight
Application Diagram:
www.avsl.com
4K HDMI 2.0 Switch with Remote Control
2.0b
Up to 3840 x 2160 @ 60Hz
24/30/36 bit deep colour
DTS-HD, Dolby-trueHD, DTS, Dolby-AC3 and DSD
600 MHz
6x3Gbps
350mA
16m max 4K @ 30Hz and FHD or 8m max 4K @ 60Hz
-15°C to +55°C
CR2025 (supplied)
Input: AC (50Hz, 60Hz) 100-240V, Output: DC5V/1A
102 x 79 x 22(mm)
90g
Item ref: 128.841UK
