This slimline HDMI switch allows a single display to be connected to multiple HDMI sources and selected using
the IR remote control or selection button on the unit. Gold plated connections ensure optimum signal transfer
and the LED's on the front of the unit keep you informed as to which of the inputs is live at any one time.
Technical Specifications and Features
HDMI Version
Video Format
Audio Format
Operating Temperature Range
Power Adaptor
Max. Bandwidth
Max. Baud Rate
Max. Working Current
Dimensions
Weight
Connection Instructions
1.4a
Up to 1080p @ 60Hz, 3D, 24/30/36 bit deep colour
DTS-HD, Dolby-trueHD, DTS, Dolby-AC3 and DSD
-15 to +55°C
Input: AC (50Hz, 60Hz) 100-240V, Output: DC5V/1A
225 MHz
2.25Gbps
600mA
178 x 58 x 20(mm)
220g
HDMI Switch 5x1 with Remote Control
Item ref: 128.824UK
User Manual
Advertisement
Table of Contents
Related Manuals for AV Link 128.824UK
Summary of Contents for AV Link 128.824UK
-
Page 1: Connection Instructions
HDMI Switch 5x1 with Remote Control Item ref: 128.824UK User Manual This slimline HDMI switch allows a single display to be connected to multiple HDMI sources and selected using the IR remote control or selection button on the unit. Gold plated connections ensure optimum signal transfer and the LED's on the front of the unit keep you informed as to which of the inputs is live at any one time. - Page 2 This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste at the end of its useful life. The goods must be disposed of according to your local council guidelines. Errors and omissions excepted. Copyright© 2016. AVSL Group Ltd. 128.824UK User Manual...
