Wl042R*, Wl040R*, Wl041R*
JINGLE II
DESCRIPTION
Webbing width25 mm
Black fabric
Label
Big „O" ring
Small „O" ring
STANDARDS
1019
EN 795 B:2012
TECHNICAL DATA
CODE
type
Wl040Rl00 Steel rings
Wl040Rl20 Steel rings
Wl040Rl50 Steel rings
Wl041Rl00 Alu. rings
Wl041Rl20 Alu. rings
Wl041Rl50 Alu. rings
Wl042Rl00 without rings
Wl042Rl20 without rings
Wl042Rl50 without rings
*) code of type and length
*) – 100, 120, 150 cm
*) – 100, 120, 150 cm
*) 100–92cm, 120–112 cm, 150–142 cm
FEATURES
3
YEARS
SMALL– 960 g/34 oz
guarantee
UNI – 1050 g/37 oz
[cm]
[in]
[kN]
[g]
100
39
25
378
120
47
25
398
150
58
25
427
100
39
25
201
120
47
25
221
150
58
25
250
92
39
25
105
112
47
25
125
142
58
25
154
webbing
webbing
webbing
Cambium saver intended for use in tree climbing as anchor device and
belay anchor. The different size of the rings enables easy and quick insta-
lling and removing of the sling from the ground. As well suitable in indus-
try as an anchor device.
MATERIALS
CZ
variant with
Steel rings
40 % PES
made in
60 % steel
Czech Republic
MARKING
SINGING ROCK ETIKETA SLEDOV ATELNOSTI
I
TRACEABILITY LABEL
001/9999 /MM/YY
JINGLE II 120
5
EN 795 B:12
1 CZ jedinečné číslo
I
EN unique No.
I
DE Eindeutige nummerr
2 výrobní číslo
I
batch No.
I
Chargennummer
I
Numero de lot de fabrication
3 měsíc/rok výroby
I
month/year of manufacture
I
produkzion monat/jahr
4 model
I
model
I
Model
I
le modéle
I
modelo
5 evropská norma
I
european standard
I
Europische Norm
6 výrobce
I
producer
I
Hersteller
I
Le fabricant
I
fabricante
7 značka shody / číslo oznámeného subjektu, který provádí shodu s typem
conformity with type
I
die Konformität Markierung / nummer die notifizierte Stelle durchführen die entsprechenden Konformität mit type
la marque de confirmit / numero d´organisme notifie effectuer la conformité avec type
notificado efectuará la conformidad con typo
8 viz návod k použití
I
read instructions for use
I
Gebrauchsanweisung beachten
I
Consulter les instructions d'utilisation
I
Consulte las instrucciones de uso
9 max. 1 osoba
I
max. 1 person
I
max. 1 Person
I
max. 1 personne
Nařízení evropského parlamentu a rady (EU)
2016/425
I
Regulation (EU) 2016/425
Posouzení shody
I
Conformity assessment:
VVUÚ, a.s., Pikartská 1337 /7, Ostrava-Radvanice, Czech Republic, NB 1019
Shoda s typem
I
Conformity to type:
VVUÚ, a.s., Pikartská 1337 /7, Ostrava-Radvanice, Czech Republic, NB 1019
EU prohlášení o shodě naleznete na:
EU declaration of conformity available on:
www.singingrock.com
Use according EN 795 B
KEY PROPERTIES
25 mm webbing reduces
twisting
The small „O" ring indicated
by a black fabric for easy
identification
Distinctive color for better
visibility
variant with
Alu. rings
61 % PES
39 % aluminium
8
9
I
FR Numéro unique
I
ES Número único
I
No. de serie
I
mois/année de fabrication
I
mes/ańo de producción
I
La norme europenne
I
Normativa europea
I
conformity marking / no. of notified body shell carrying out
I
marca de conformidad / numero del organismo
I
max. 1 persona
info@singingrock.com
www.singingrock.com
Verion: 3/2019
variant
without rings
100 % PES
I
