INSTRUCTIONS AND CARE MANUAL FOR PHOENIX CHAIR
Folding arm bars
www.adaptivestar.com
This chair can accommodate up to 200LBS
Carefully remove the chair, canopy and wheels from the box. In the back
of the seat inside the mesh pocket you will find 2 folding arm bars..
Before completely opening the chair, open it partially and add the arm
bars to each side. You will find a washer and nut attached to a bolt. With
a zip tie and a corresponding zip tie on the bars. With a 7/16 wrench
remove them. Attach each arm bar, washer, then nut and tighten. Once
this is done you will not need to remove them again.
OPEN the chair completely and swing the folding arm bar down in-
serting the knob into the hole on the side of the frame.
When folding the chair, unscrew the knobs and lift the arms up toward
the frame, then push forward on the handle to collapse the chair.
That is all there is to it!
