Haier XPB50-23BS User Manual

Twin-tub washing machine
Hide thumbs

Advertisement

Quick Links

XPB50-23BS
Twin-tub Washing Machine
Please read this manual carefully before using.
Please retain it for future reference.
Haier
Contents
Names of the parts.............the 2
Safety precautions ...............................1
Installation and adjustment ..................3
Preparation before washing ................6
The musts in washing .........................7
Usage of the detergent .......................8
Washing sequence ..............................9
Disposal after washing .......................13
Answers to question.....................15
Packing list ......................................17
Specification..............the back cover
cover
nd

Advertisement

loading

  Also See for Haier XPB50-23BS

  Related Manuals for Haier XPB50-23BS

  Summary of Contents for Haier XPB50-23BS

  • Page 1: Table Of Contents

    XPB50-23BS Twin-tub Washing Machine Please read this manual carefully before using. Please retain it for future reference. Haier Contents Before using Names of the parts...the 2 Safety precautions ...1 Installation and adjustment ...3 Introduction of the major functions ...5 Using process Preparation before washing ...6...
  • Page 2: Before Using

    Names of the parts Spin timer Wash w ater-filling entrance Wash selector Wash timer Control panel Overflow filter Water level adjusting lever Lint filter Pulsator Wash tub Base frame Accessories Water inlet hose (one piece) (one piece) Meaning and description of the symbols Warning sign Forbidding sign Gland...
  • Page 3: Safety Precautions

    Safety precautions Be sure to use three-phase receptacle. Earth the earthing terminal of the receptacle reliably. Earth If the power cord is bad, to avoid risk it is required to replace it by the technicians of our special shop or the after-sale service department. Keep the pin of the power plug clean.
  • Page 4 Safety precautions Do not stretch hands into the working machine. It is dangerous even if the rotation is slow. Take special care of the children. Do not put any hot or heavy items ( such as the kettle with hot water ) on the washing machine.
  • Page 5: Installation And Adjustment

    Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Usage of the drain hose The drainage shall be smooth with the drain hose. 1.The height of the drain hose shall be less than 10cm , or the drainage will not be smooth enough and cause...
  • Page 6: How To Change The Direction Of The Drain Hoses

    How to change the direction of the drain hoses Figure 1 indicates the ex factory installation position of the drain hose. Extend the drain hose from the side of wash tub Put soft items on the ground. Lean the machine down gently with the front surface facing the ground.
  • Page 7: Introduction Of The Major Functions

    Introduction of the major function The machine has good comprehensive performance, and nice appearance. It adopts streamline appearance and full plastic shell, which will never get rust. For the design on safety and reliability, it adopts the wash shelf, spin shelf and water reception groove design, and reduces the unfavorable influence on the electrical component by the vapor.
  • Page 8: Preparation Before Washing

    Preparation before washing Pay attention to followings before washing the laundries Confirm Clear the pocket. there's special Take out the requirement for coins , sand, the laundries. hairpins etc. Preparation before washing 1.Connect the water inlet hose. 2.Confirm that the washing machine is earthed reliably .
  • Page 9: The Musts In Washing

    The musts in washing Reference weight of the laundries Working suit up,down cotton,about 1120g Blanket cotton,about 900g Pajamas Shirt cotton,about 300g Undershirt cotton,about 180g The capacity of washing and spinning of the machine refer to the largest weight of the standard laundries under dry condition that can be washed or spinned in one time.
  • Page 10: Usage Of The Detergent

    Usage of the detergent How to use the whitener Fill water to decided level. Dilute the whitener with container. Pour it slowly into the washing tub. Avoid using whitener on laundries with color or pattern as they are prone to lose color. The whitener shall not touch the laundries directly.
  • Page 11: Washing Sequence

    Washing sequence Wash timer Wash selector (To set to below 2 minute, (Soft current, first set to 5 minute then strong current) turn it back. it can increase the service life of the timer). WASH SELECTOR WASH TIMER STRONG SILK WOOL SOFT COTTON...
  • Page 12 Midway spinning Put the laundries into the spin tub evenly and smoothly. Spin (1) Put the gland in properly. Please put in the gland properly even if the laundries quantity is small. Push Gland The laundries Proper are slanting (2) Close the inner and outer cover of the spin tub. (3) Spin for 1-2 minutes.
  • Page 13: Rinse With Water-Filing

    Rinsing Rinse with water-filing 1.Put the laundries into the wash tub. Select suitable current according to the laundries. 2.Adjust the water level Set the water level with water level adjusting lever according to the laundries quantity. Then fill suitable water continuously. 3.Rinse Adjust the wash timer to 5-7 minutes to do rinsing.
  • Page 14 Spinning 1. Put the laundries into the spin tub evenly and smoothly. 2. Press the gland in the tub properly. Close the inner and outer cover of the spin tub. 3. Spin Select suitable spin time according to the laundries, and do spinning. During spinning, if there's abnormal sound, it is generally owing to slanting placement of the laundries.
  • Page 15: Disposal After Washing

    Disposal after washing After using, please clean the lint and foreign materials of the lint filter and overflow filter in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Cleaning the lint filter The lint filter must be used during washing.
  • Page 16: Cleaning The Overflow Filter

    Cleaning the overflow filter 2. Take off the corrugation pipe. Dismantle the upper part of the corrugation pipe inside overflow filter ( as indicated in Figure 1). 3. Cleaning the overflow filter Clean the lint around the filter and flush with tap water. 4.
  • Page 17: Trouble-Shooting* Answers To Question

    Trouble-shooting Answer to question If the laundries fall to the outer side of the spin tub If the laundries fall to the outer side of the spin tub, please take them out immediately. 1.Dismantle As indicated in the figure, push the point marked with "...
  • Page 18 Trouble-shooting Answer to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
  • Page 19: Packing List

    Packing list User's manual Water inlet hose Gland Twin-tub washing machine...
  • Page 20: Specification

    Rated washing capacity kg Rated spinning capacity kg Rated input power W Dimension(mm) Wash pattern Weight kg Injection pressure Twin-tub washing machine XPB50-23BS Rated voltage 220-240V~, Rated frequency 50Hz High/39L Medium/30L Low/24L wash 380 spin 135 L750 W428 H850 New current...

This manual is also suitable for:

Sgw-535Sgw-535p
