Morris MKV-64311 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
MKV-64311
(EN) INSTRUCTION MANUAL
IO-CFS-1311 / 8505589
(04.2019 / v1)

Advertisement

loading
Need help?

Need help?

Do you have a question about the MKV-64311 and is the answer not in the manual?

Questions and answers

Related Manuals for Morris MKV-64311

Summary of Contents for Morris MKV-64311

  • Page 1 MKV-64311 (EN) INSTRUCTION MANUAL IO-CFS-1311 / 8505589 (04.2019 / v1)
  • Page 2 DEAR CUSTOMER, The cooker is exceptionally easy to use and extremely efficient. After reading the instruction manual, operating the cooker will be easy. Before being packaged and leaving the manufacturer, the cooker was thoroughly checked with regard to safety and functionality. Before using the appliance, please read the instruction manual carefully.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Safety instructions ......................4 Description of the appliance ..................... 9 Installation ..........................11 Operation ........................... 14 Baking in the oven – practical hints ................23 Test dishes..........................26 Cleaning and maintenance ....................28 Technical data ........................34...

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS Warning: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or...
  • Page 5 SAFETY INSTRUCTIONS Warning: If the surface is cracked, switch off the ap- pliance to avoid the possibillity of electric shock. During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven. Accessible parts may become hot during use. Young children should be kept away.
  • Page 6 SAFETY INSTRUCTIONS  Always keep children away from the cooker. While in operation direct contact with the cooker may cause burns!  Ensure that small items of household equipment, including connection leads, do not touch the hot oven or the hob as the insulation material of this equipment is usually not resistant to high temperatures.
  • Page 7 HOW TO SAVE ENERGY  Make use of residual heat from the Using energy in a respon- sible way not only saves oven. money but also helps the If the cooking time is greater than 40 minutes switch off the oven 10 minutes before the environment.
  • Page 8 DISPOSAL OF THE APPLIANCE UNPACKING During transportation, protec- Old appliances should not sim- tive packaging was used to ply be disposed of with normal protect the appliance against household waste, but should any damage. After unpack- be delivered to a collection and ing, please dispose of all recycling centre for electric and elements of packaging in a...

  • Page 9: Description Of The Appliance

    DESCRIPTION OF THE APPLIANCE 3, 4 5, 6 1 Temperature control knob 2 Oven function selection knob 3, 4, 5, 6 Heating zone control knobs 7 Temperatureregulatorsignal light L 8 Cooker operation signal light R 9 Oven door handle 10 Drawer 11 Ceramic hob...
  • Page 10 SPECIFICATIONS OF THE APPLIANCE Ceramic hob: Cooker fittings: Grill grate Baking tray* (drying rack) Fork and rotisserie frame Roasting tray* Sideracks *optional...

  • Page 11: Installation

    INSTALLATION Mounting the overturning prevention Installing the cooker bracket.  The kitchen should be dry and airy and The bracket is mounted to prevent overtur- have effective ventilation according to the ning of the cooker. When the overturning existing technical provisions. prevention bracket is installed, a child who climbs on the oven door will not overturn the ...
  • Page 12 INSTALLATION Electrical connection Warning! All electrical work should be carried out by a suitably qualified and authorised electrician. No alterations or wilful changes in the electric- ity supply should be carried out. Fitting guidelines The cooker is manufactured to work with three–phase alternating current (400V 3N~50Hz).
  • Page 13 INSTALLATION CONNECTION DIAGRAM Recommen- Caution! Voltage of heating elements 230V type of connection Caution! In the event of any connection the safety lead wire must be connected to the PE terminal For 230 V earthed one–phase connection, bridges connect 1–2–3 H05VV-F3G4 terminals and 4–5 terminals, safety wire to...

  • Page 14: Operation

    OPERATION Important! Before first use In ovens equipped with the electronic Remove packaging, empty the drawer, programmer Ts, the time “0.00” will start flashing in the display field upon clean the interior of the oven and the hob. Take out and wash the oven fittings with connection to the power supply.
  • Page 15 OPERATION Controlling the heating zones of the ceramic hob. Choice of cookware Choose a pan with a diameter that is at least as large as the heating zone. Do not use pans with a concave or convex base. Always remember to put a proper cover on the pan. We recommend the use of pans with thick, even bases.
  • Page 16 OPERATION Zone heating indicator Switching on the wider heating zone If the temperature of a heating zone exceeds Important! 50°C this is signalled by an indicator which Only switch on a heating zone by lights up for that zone. turning the knob clockwise. Turning When the heating indicator lights up it warns the knob in the opposite direction can the person using the cooker against touching...
  • Page 17 OPERATION Electronic programmer Timer The timer can be activated at any time, re- gardless of the status of other functions. The functions timer can be set for from 1 minute to up to 23 hours and 59 minutes. – function selection button MENU To set the timer you should: <...
  • Page 18 OPERATION Semi–automatic operation Automatic operation If the oven is to be switched off at a given If the oven is to be switched on for a specified time, then you should: period of time and switched off at a fixed hour then you should set the operation time and Set the oven function knob and the tem- the operation end time:...
  • Page 19 OPERATION Change the timer beeps The function AUTO is now on; the oven will start operating from the point when the differ- The tone of the timer beeps may be ence between the set operation end time and changed as follows: the operation duration time occurs (e.g.
  • Page 20 OPERATION Oven is off Oven functions and operation. Rapid Preheating Oven with automatic air circulation Ring heater and roaster on. Use to (including a fan and an ultra-fan heater) preheat the oven. The oven can be heated up using the bottom and top heaters, the grill or the ultra-fan he- Defrosting ater.
  • Page 21 OPERATION Bottom heater on Convection with ring heating ele- When the knob is set to this position ment and bottom heater on the oven is heated using only the With this setting the convection fan bottom heater. Baking of cakes from and bottom heater are on, which in- the bottom until done (moist cakes creases the temperature at the bottom...
  • Page 22 OPERATION Use of the grill Use of the rotisserie The grilling process operates through infrared The rotisserie enables rotating grilling in the rays emitted onto the dish by the incandes- oven. It is intended for grilling poultry, kebabs, cent grill heater. sausages and similar dishes.

  • Page 23: Baking In The Oven - Practical Hints

    BAKING IN THE OVEN – PRACTICAL HINTS Baking  we recommend using the baking trays which were provided with your cooker;  it is also possible to bake in cake tins and trays bought elsewhere which should be put on the drying rack; for baking it is better to use black trays which conduct heat better and shorten the baking time;...
  • Page 24 BAKING IN THE OVEN – PRACTICAL HINTS ECO Fan Heater  ECO Fan Heater is an optimised heating function designed to save energy when preparing food.  You cannot reduce the cooking time by setting a higher temperature; preheating the oven is not recommended. ...
  • Page 25 BAKING IN THE OVEN – PRACTICAL HINTS Oven with automatic air circulation (including a fan and ring heater) Type of Type Temperature Level Time dish of heating (min.) Sponge cake 160 - 200 2 - 3 30 - 50 Yeast cake/ 160 - 170 25 - 40 Pound cake...

  • Page 26: Test Dishes

    TEST DISHES. According to standard EN 60350-1. Baking Type of dish Accessory Level Type Temperature Baking of heating time (min.) Baking tray 28 - 32 Baking tray 23 - 26 Baking tray 26 - 30 Small cakes 2 + 4 Baking tray 2 - baking tray 27 - 30...
  • Page 27 TEST DISHES. According to standard EN 60350-1. Grilling Type of dish Accessory Level Type Temperature Time of heating (min.) Wire rack 1,5 - 2,5 White bread toast Wire rack 2 - 3 Wire rack + 4 - wire rack roasting tray 1st side 10 - 15 Beef burgers 3 - roasting...

  • Page 28: Cleaning And Maintenance

    CLEANING AND MAINTENANCE By ensuring proper cleaning and mainte- Caution! The sharp blade should always nance of your cooker you can have a sig- be protected by adjusting the cover (just nificant influence on the continuing fault-free push it with your thumb). Injuries are pos- operation of your appliance.
  • Page 29 CLEANING AND MAINTENANCE Oven Replacement of the oven light bulb  The oven should be cleaned after every In order to avoid the possibility of an use. When cleaning the oven the lighting electric shock ensure that the appliance is switched off before replacing the bulb.
  • Page 30 CLEANING AND MAINTENANCE  Ovens in cookers marked with the letter  Ovens in cookers marked with the letters D are equipped with easily removable Dp have stainless steel sliding telescopic wire shelf supports. To remove them for runners attached to the wire shelf sup- washing, pull the front catch, then tilt the ports.
  • Page 31 CLEANING AND MAINTENANCE Removing the inner panel Door removal 1. Pull the upper door slat loose. (fig. B, C) In order to obtain easier access to the oven chamber for cleaning, it is possible to remove the door. To do this, tilt the safety catch part of the hinge upwards (fig.
  • Page 32 CLEANING AND MAINTENANCE 2. Pull the inner glass panel from its seat Regular inspections (in the lower section of the door). Re- move the inner panel (fig. D). Besides keeping the oven clean, you should: 3. Clean the panel with warm water with ...
  • Page 33 OPERATION IN CASE OF EMERGENCY In the event of an emergency, you should:  switch off all working units of the oven  disconnect the mains plug  call the service centre  some minor faults can be fixed by referring to the instructions given in the table below. Before calling the customer support centre or the service centre check the following points that are presented in the table.

  • Page 34: Technical Data

    TECHNICAL DATA Electrical supply 230 / 400 V ~50Hz Maximum load 10,4 kW Electric hob MKV-64311: 14,5 cm heating zone x 2 1,2 kW 17x26,5 cm heating zone 2,2 kW 21/12 cm heating zone 2,2 kW Oven MKV-64311: oven 3,6 kW...
  • Page 36 Exclusive importer in Greece: Amiridis – Savvidis S.A. 87A, 17th November str. 55535 - Thessaloniki – Greece T: +302310944944 | F: +302310944940 www.morris.gr...
