ASSEMBLY
Unpack the lawn mower ensuring all parts are present
(see parts list overleaf) before discarding the packaging.
1
Set the height adjustment to
lowest position; fix the lower
handle onto deck firmly with
supplied wrench using
the handle fixing bolts.
2
Lift the upper handle, align it with
the lower handle, making sure
the cables are not twisted, and
fasten the two handles together
by using the bolts and handle
tension knobs.
MOWING THE LAWN
Fill the petrol tank with 0.8l of normal 95 Octane petrol
(standard unleaded) using a funnel and measuring jug.
9
When starting a cold
engine, press down the
primer fully 3~5 times.
When starting a warm
engine, the primer
does not need to be
used.
10
Hold the stop/start bar
firmly to the handle to
Engine start
disengage the motor
Engine stop
brake and automatic
cut out.
3
Make sure the rope guide is
on right hand side
when you stand behind
the mower.
4
Using the cable
clamp provided,
secure the cables to
the handle without
trapping them.
11
To start the engine slowly
pull the start cord out
until resistance is felt
(approx 10-15cm) then
start the engine with a
sharp vigorous pull.
When the engine is ticking over ensure the throttle
is in the rabbit position. ALL mowing must be done in
the rabbit position.
To stop the mower release the stop/start
bar.
PREPARING TO MOW
Follow these steps to ensure quick and easy set up
5
Firstly attach the grass bag to
the frame by fixing all
plastic hooks.
Raise the safety flap, and
hook the collection bag onto
the mower.
Release the safety flap.
6
Pull the lever towards
the wheel, then move it
forward or backward to
adjust the cutting height.
Return lever into securing
plate.
IMPORTANT INFORMATION!
Always read the instruction manual thoroughly
before starting the lawnmower.
In cold weather it may be necessary to repeat the cold engine starting
process.
Never allow the starter cord to snap back.
Check the oil level before every use.
If you have any difficulties please contact the
helpline on 0845 034 2279
email support@gardenservicecentre.co.uk
or visit www.gardenservicecentre.co.uk
every time.
7
The engine does not
come with oil. Add a
minimum of 0.6 litres of
Add Full
oil.
CHECK THE OIL
BEFORE EVERY USE.
8
Slowly pull out starter
cord & hook it through
the eye of rope guide.
You should ALWAYS
start your mower
from this position.
