Operations Manual
Demon Tornado Bowser Range
Including electric start variants and bowser washers
We, Demon International Limited of Abbots Close, Lee Mill Industrial Estate,
Ivybridge, Devon, PL21 9GA, declare that this machine must be operated in
accordance with the operation and safety instructions as supplied with this
machine.
This machine is manufactured in accordance with the following standards
and recommendations.
HSE PVB PM29 - BS5415 Part - BS5415 Section 2.4 1986
This instruction manual is relevant only to the following machine and will not
be kept updated unless specifically requested by the customer. However,
any changes to the operating procedure or changes which might affect the
safety of this machine will be notified to the registered owner
Machine Type
Serial Number
Working Pressure
Date of Supply
Tornado P4
Tornado P5
Tornado D1ES
Declaration of Conformity
(E.H.S.R.)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tornado Bowser P4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Demon Tornado Bowser P4

  • Page 1 Including electric start variants and bowser washers Declaration of Conformity (E.H.S.R.) We, Demon International Limited of Abbots Close, Lee Mill Industrial Estate, Ivybridge, Devon, PL21 9GA, declare that this machine must be operated in accordance with the operation and safety instructions as supplied with this machine.
  • Page 2: Technical Specifications

    Technical Specifications Tornado P4 Engine Honda GX340 11HP @ 3600rpm Pump AR RK15-20H Pressure 2900psi / 200 bar Flow 15 lpm / 3.3gpm HP Nozzle 2504 Gearbox 2:1 Reduction Unloader Gymatic 3A Pump Oil 10W/40 Gearbox Oil EP 90 Tornado P5 Engine Honda IGX390 Pump...
  • Page 3: Fault Finder

    Fault Finder FAULT CAUSE REMEDY check and top up oil  Machine stops suddenly P4—low oil Check/replace battery, re-  Or will not start. D1—flat battery/fuse place fuse Water supply failed. Check water supply. Sudden pressure loss. No chemical Check chemical drum, close valve HP nozzle worn or Replace HP nozzle.
  • Page 4 Minimum Service DAILY CHECK THE FOLLOWING Oil level - top up as required. Fuel tank - top up as required. All hose unions for leaks- replace O rings if leaking. Hose condition - cuts etc. EVERY 500 HOURS OR SIX MONTHS (WHICHEVER COMES FIRST) Drain and replace pump oil.
  • Page 5 Operating Instructions SAFETY Water at high pressure is dangerous and can cause serious injury. This machine is to be used with great caution. Petrol is extremely flammable and explosive under certain conditions. EXHAUST FUMES CONTAIN CARBON MONOXIDE – Inhalation of such fumes can KILL. Diesel is flammable and harmful if swallowed.
  • Page 6 Always ensure that there is a suitable type fire extinguisher available and is within easy access. DO NOT leave an engine running unattended, ALWAYS STOP it before leaving the area. NEVER point the high pressure spray jet at any person, animal, glass or other Material which may shatter.
  • Page 7: Operation

    Preparation Water Supply: Ensure there is an adequate water supply either from the mains or a reservoir. Attach water supply hoses to suitable tap or immerse the suction hose with approved suc- tion filter into the reservoir. NOTE: ONLY CLEAN WATER SHOULD BE USED. THE PUMP MAY BE DAMAGED IF DIRTY OR CONTAMINATED WATER IS ALLOWED TO PASS THROUGH THE PUMP.
  • Page 8 Adjust pressure regulator as required to obtain working pressure if required. NOTE;:The high pressure water will cause the gun to “kick”. Make sure you have a firm grip of gun and lance. On completion of operation stop the engine. Operate lance trigger Turn “...
  • Page 12 Tornado Bowser General Arrangement...
  • Page 14: Warranty

    It is the owners responsibility to return the machine to a service depot or pay the travelling expenses of a engineer to attend. Demon Internationals decision in warranty matters is final and binding.
  • Page 15: Warranty Procedure

    5. If required Demon will arrange for a carrier to collect a damaged machine, if the warranty claim is valid we will pay this cost, if not it will be charged to the customer.
  • Page 16 I can’t get the pressure to where it used to be — where do I start?
  • Page 20 1450 Code No Description Code No Description AR1322730 Screw AR1320020 Pump Head AR620301 Plug AR180101 O Ring AR1260162 Plug AR820361 Plug AR960160 O Ring AR1260200 Crankshaft AR1269050 Complete Valve AR1320260 Crankshaft AR880830 O Ring AR1380520 AR1320340 Support Ring AR1320370 Bearing AR1260220 Gasket AR1260750...
  • Page 28 RK MODEL: 15.20H Part No Description Part No Description AR960160 O Ring AR1343510 Screw AR960090 Plug AR1380120 0.10mm shim 1÷3 AR1380740 Plug AR1380130 0.20mm shim 1÷3 AR1389051 Complete Valve AR1380530 0.25mm shim 1÷3 AR880830 O Ring AR1382810 0.05mm shim 1÷3 AR880581 Plug AR740290...
  • Page 30: Ec Declaration Of Conformity

    DS EN 60335-2-79 Applied conformity evaluation method Appendix V Sound power level dB(A): Tornado Bowser P2 Tornado Bowser P4 Tornado Bowser D1 Measured Guaranteed HAV – All triggers and lances have vibration levels below 2.5 m/s/s ² I hereby declare that the equipment named above has been designed to comply with the relevant sections of the above referenced specifications.
