SONOMA ACADIA STATIONARY CHAIR ASSEMBLY INSTRUCTIONS
A
B
C
D
E
F
G
H
I
SAVE THESE INSTRUCTIONS
STYLE #:
71SRRCU14
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
FIGURE
QUANTITY
10 PCS + 1 PC
10 PCS + 1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
DESCRIPTION
RIGHT ARM/LEG
LEFT ARM/LEG
SEAT
BACK
BOLT
(M6*15MM)
FLAT WASHER
ALLEN WRENCH
SEAT CUSHION
BACK CUSHION
Page 1/3
Advertisement
Table of Contents
Related Manuals for Sonoma ACADIA 71SRRCU14
Summary of Contents for Sonoma ACADIA 71SRRCU14
- Page 1 SAVE THESE INSTRUCTIONS SONOMA ACADIA STATIONARY CHAIR ASSEMBLY INSTRUCTIONS STYLE #: 71SRRCU14 ASSEMBLE ON A FLAT, PROTECTED SURFACE. FIGURE DESCRIPTION PART LIST QUANTITY 1 PC RIGHT ARM/LEG 1 PC LEFT ARM/LEG 1 PC SEAT 1 PC BACK BOLT 10 PCS + 1 PC...
- Page 2 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SRRCU14 STEP 1 A. PLACE RIGHT ARM/LEG (A) ON A FLAT, PROTECTED SURFACE. B. CONNECT SEAT (C) TO RIGHT ARM/LEG (A) WITH BOLTS (E) AND FLAT WASHERS (F) USING ALLEN WRENCH (G). DO NOT TIGHTEN COMPLETELY.
- Page 3 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SRRCU14 STEP 4 A. ROTATE CHAIR TO THE UPRIGHT POSITION. B. CONNECT BACK (D) TO RIGHT ARM/LEG (A) AND LEFT ARM/LEG (B) WITH BOLTS (E) AND FLAT WASHERS (F) USING ALLEN WRENCH (G). C. TIGHTEN ALL BOLTS. STEP 5 A.
- Page 4 SAVE THESE INSTRUCTIONS SONOMA ACADIA SIDE TABLE ASSEMBLY INSTRUCTIONS STYLE #: 71SRRCU14 ASSEMBLE ON A FLAT, PROTECTED SURFACE. FIGURE DESCRIPTION PART LIST QUANTITY 1 PC 4 PCS BOLT 4 PCS + 1 PC (M8*50MM) 4 PCS + 1 PC FLAT WASHER...
- Page 5 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SRRCU14 STEP 1 A. PLACE TOP (A) UPSIDE DOWN ON A FLAT, PROTECTED SURFACE. B. CONNECT LEGS (B) TO TOP (A) USING BOLT (C), FLAT WASHER (E) AND FLAT WASHER (D) WITH WRENCH (F). TIGHTEN COMPLETELY. STEP 2 A.
