SONOMA BRAMPTON WICKER CHAIR ASSEMBLY INSTRUCTIONS
PART LIST
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
SAVE THESE INSTRUCTIONS
STYLE #: 71SRRWK05
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
FIGURE
10 PCS + 1 PC
QUANTITY
1 PC
1 PC
1 PC
1 PC
1 PC
4 PCS + 1 PC
2 PCS + 1 PC
4 PCS + 1 PC
2 PCS + 1 PC
2 PCS + 1 PC
2 PCS + 1 PC
4 PCS + 1 PC
4 PCS + 1 PC
2 PCS + 1 PC
DESCRIPTION
RIGHT ARM
LEFT ARM
BACK
SEAT
BASE
SHORT BOLT
(M6*25MM)
MEDIUM BOLT
(M6*30MM)
LONG BOLT
(M6*45MM)
SMALL FLAT WASHER
PLASTIC WASHER
SHORT HEX BOLT
(M8*34MM)
LONG HEX BOLT
(M8*38MM)
LOCK WASHER
LARGE FLAT WASHER
PLATE
Page 1/5
Advertisement
Related Manuals for Sonoma BRAMPTON 71SRRWK05
Summary of Contents for Sonoma BRAMPTON 71SRRWK05
- Page 1 SAVE THESE INSTRUCTIONS SONOMA BRAMPTON WICKER CHAIR ASSEMBLY INSTRUCTIONS STYLE #: 71SRRWK05 ASSEMBLE ON A FLAT, PROTECTED SURFACE. FIGURE DESCRIPTION PART LIST QUANTITY 1 PC RIGHT ARM 1 PC LEFT ARM 1 PC BACK 1 PC SEAT 1 PC BASE...
-
Page 2: Seat Cushion
ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SRRWK05 4 PCS + 1 PC 1 PC ALLEN WRENCH 2 PCS WRENCH 1 PC SEAT CUSHION 1 PC BACK CUSHION Page 2/5... - Page 3 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SRRWK05 STEP 1 A. PLACE RIGHT ARM (A) ON A FLAT, PROTECTED SURFACE. B. CONNECT THE BOTTOM OF RIGHT ARM (A) TO BACK (C) WITH SHORT BOLT (F) AND SMALL FLAT WASHER (I) USING ALLEN WRENCH (Q). DO NOT TIGHTEN COMPLETELY.
- Page 4 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SRRWK05 STEP 4 A. CONNECT BOTTOM OF SEAT (D) TO LEFT ARM (B) WITH LONG BOLTS (H) AND SMALL FLAT WASHERS (I) USING ALLEN WRENCH (Q) AS SHOWN. DO NOT TIGHTEN COMPLETELY. B. CONNECT FRONT OF SEAT (D) TO LEFT ARM (B) WITH SHORT BOLT (F) AND SMALL FLAT WASHER (I) USING ALLEN WRENCH (Q).
-
Page 5: Warranty
ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SRRWK05 ** WE RECOMMEND THAT YOU SAVE THE ALLEN WRENCH AND WRENCHES AND PERIODICALLY TIGHTEN ALL BOLTS. WEIGHT LIMIT 250 LBS CARE AND CLEANING FRAME: WIPE CLEAN WITH A MILD SOAP AND WATER SOLUTION, RINSE WITH CLEAN WATER, AND DRY THOROUGHLY. CUSHION: SPOT CLEAN WITH A SOFT CLOTH.
