SONOMA CANTON GLASS CABINET ASSEMBLY INSTRUCTIONS
PHILLIPS HEAD SCREWDRIVER NEEDED FOR ASSEMBLY; NOT INCLUDED.
PART LIST
A
B
C
D
E
F
G
H
I
J
K
SAVE THESE INSTRUCTIONS
STYLE #: 71SNRST01
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
FIGURE
QUANTITY
12 PCS + 1 PC
12 PCS + 1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
DESCRIPTION
TOP
BOTTOM
LEFT SIDE
RIGHT SIDE
MIDDLE SHELF
FRONT CROSSBAR
LEFT DOOR
RIGHT DOOR
BACK PANEL
CAM LOCK
CAM BOLT
Page 1/8
Advertisement
Table of Contents
Related Manuals for Sonoma 71SNRST01
Summary of Contents for Sonoma 71SNRST01
- Page 1 SAVE THESE INSTRUCTIONS SONOMA CANTON GLASS CABINET ASSEMBLY INSTRUCTIONS STYLE #: 71SNRST01 ASSEMBLE ON A FLAT, PROTECTED SURFACE. PHILLIPS HEAD SCREWDRIVER NEEDED FOR ASSEMBLY; NOT INCLUDED. FIGURE DESCRIPTION PART LIST QUANTITY 1 PC 1 PC BOTTOM 1 PC LEFT SIDE...
- Page 2 SAVE THESE INSTRUCTIONS SONAMA CANTON GLASS CABINET ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SNRST01 ASSEMBLE ON A FLAT, PROTECTED SURFACE. PHILLIPS HEAD SCREWDRIVER NEEDED FOR ASSEMBLY; NOT INCLUDED. FIGURE DESCRIPTION PART LIST QUANTITY LONG WOOD DOWEL 12 PCS + 1 PC (Dia.
- Page 3 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SNRST01 STEP 1 A. INSERT CAM BOLTS (K) INTO THE PRE-DRILLED SMALL HOLES ON TOP (A), LEFT SIDE (C), AND RIGHT SIDE (D) USING PHILLIPS HEAD SCREWDRIVER, NOT INCLUDED. TIGHTEN COMPLETELY. A/C/D STEP 2 A. PLACE TOP (A) UPSIDE DOWN ON A FLAT, PROTECTED SURFACE.
- Page 4 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SNRST01 STEP 4 A. PLACE LEFT SIDE (C) ON A FLAT, PROTECTED SURFACE. B. PLACE A SMALL AMOUNT OF GLUE (V) IN DOWEL HOLES ON LEFT SIDE (C). INSERT LONG WOOD DOWELS (L). C. PLACE A SMALL AMOUNT OF GLUE (V) ON THE TOPS OF LONG WOOD DOWELS (L).
- Page 5 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SNRST01 STEP 8 BACK VIEW A. INSERT CAM LOCKS (J) ON LEFT SIDE (C) AND RIGHT SIDE (D). B. TURN CAM LOCKS USING PHILLIPS HEAD SCREWDRIVER, NOT INCLUDED, TO SECURE TOP (A) TO LEFT SIDE (C) AND RIGHT SIDE (D).
- Page 6 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SNRST01 STEP 11 A. ATTACH LEFT DOOR (G) TO LEFT SIDE (C) WITH HINGE SCREWS (T) USING PHILLIPS HEAD SCREWDRIVER, NOT INCLUDED. B. ATTACH RIGHT DOOR (H) TO RIGHT SIDE (D) WITH HINGE SCREWS (T) USING PHILLIPS HEAD SCREWDRIVER, NOT INCLUDED.
- Page 7 ANTI-TIP HARDWARE MOUNTING INSTRUCTIONS FOR DRYWALL STYLE #: 71SNRST01 PHILLIPS HEAD SCREWDRIVER, DRILL, & 7/16" DRILL BIT NEEDED FOR ASSEMBLY; NOT INCLUDED. FOR SAFETY REASONS, INSTALL THIS PRODUCT USING THE INCLUDED ANTI-TIP HARDWARE TO HELP PREVENT THE PRODUCT FROM UNEXPECTEDLY TIPPING OR SHIFTING.
- Page 8 ANTI-TIP HARDWARE MOUNTING INSTRUCTIONS FOR DRYWALL (CONTINUED) STYLE #: 71SNRST01 STEP 3 A. ALIGN METAL "L" BRACKETS (3) ON BACK OF CABINET TO THE METAL "L" BRACKETS (3) ON WALL. B. FEED ZIP TIES (5) THROUGH METAL "L" BRACKETS (3) TO CONNECT CABINET TO WALL.
