INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch;
do not use any phone in your building.
•
Leave the building immediately.
•
Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
•
If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
DANGER
A barrier designed to reduce the risk of burns from the
hot viewing glass is provided with this appliance and shall
be installed for the protection of children and other at-risk
individuals.
HOMEOWNER'S MANUAL
WARNING
HOT GLASS
CAUSE BURNS.
DO NOT TOUCH
UNTIL COOLED.
NEVER
ALLOW CHILDREN
TO TOUCH GLASS.
ZERO CLEARANCE GAS
FIREPLACE HEATER SERIES:
This appliance may be installed in an
aftermarket, permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
WILL
GLASS
DIRECT vENT
DvCT40CSP95(N,P)-1
UL FILe No. mH30033
This fireplace is design
certified in accordance
with American National
Standard/CSA Standard
ANSI Z21.88/CSA 2.33
and by Underwriters
Laboratories as a Direct
Vent Gas Fireplace
Heater and shall be
installed according to
these instructions.
GAS-FIRED
Advertisement
Related Manuals for Empire Comfort Systems DVCT40CSP95P
Summary of Contents for Empire Comfort Systems DVCT40CSP95P
- Page 1 HOMEOWNER’S MANUAL INSTALLER: DIRECT vENT Leave this manual with the appliance. ZERO CLEARANCE GAS CONSUMER: FIREPLACE HEATER SERIES: Retain this manual for future reference. DvCT40CSP95(N,P)-1 WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE multifunction Remote operating Instructions ....................... 3-9 Lighting Instructions ...............................10 maintenance And Service ............................11-12 Important Safety Information ............................13 Safety Information For Users of Propane Gas ......................14 Requirements For massachusetts ..........................15 Warranty ..................................16 COMBUSTIBLE MATERIAL WARNING Do not attach combustible material above your fireplace. This is a fire hazard. -
Page 3: Multifunction Remote Operating Instructions
MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Figure 2 TECHNICAL DATA Remote Control Supply voltage 4.5 V (three 1.5 V AAA batteries) Ambient temperature ratings 0-50°C (32 - 122°F) Radio frequency 315 mHz WARNING The transmitter and receiver are radio frequency devices. Placing the receiver in or near metal may severely reduce the signal range. - Page 4 MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Initializing the System for the First Time With the batteries already installed in the Transmitter, push Remove the wall cover. Remove cover on the wall mounted the on button. The Receiver will “beep” four times to indicate battery back-up holder.
- Page 5 MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Turn On the Appliance With the system oFF, press the oN/oFF Button on the Transmit- ter. The Transmitter display will show some other active Icons on the screen. At the same time the Receiver will activate the appli- ance.
- Page 6 MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS The Thermostat Feature may be disabled if desired. With all three AAA type batteries installed: Take out one AAA battery. While re-inserting the AAA battery, Push and hold down the thermostat button. This will disable the thermostat feature on the transmitter.
- Page 7 MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Remote Dimmer Control (Light) The auxiliary function controls the power light outlet by the dimmable light control. To activate this function, use the mode Button Figure 3 to index to the light icon. See Figures 20 and 21. The intensity of the output can be adjusted through six levels.
- Page 8 MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Continuous Pilot/ Intermittent Pilot (CPI/IPI) Selection Button Lock With the system in “oFF” position press the mode Button Figure This function will lock the Buttons to avoid unsupervised operation. 3 to index to the CPI mode icon. See Figures 26 and 27. To activate this function, press the moDe and UP Buttons at the same time.
- Page 9 MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Using the Fireplace without a Remote Control Lockout State Definition The fireplace can be turned oN (HI only) and oFF with the wall A lockout state is reached when an ignition error occurs. The switch. The fireplace flame oN/oFF is the only function that will lockout state will remain set in memory as long as the power operate;...
-
Page 10: Lighting Instructions
LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance must be lighted with the remote control. C. -
Page 11: Maintenance And Service
Empire Comfort Systems. • Clean Burner and Control Compartment Do not abuse or strike the glass. Keep the control compartment, logs, and burner areas surrounding the logs clean by vacuuming or brushing at least twice a year. - Page 12 MAINTENANCE AND SERvICE Light Bulb(s) Replacement Barrier & Glass Removal 1. Remove the following items: 1. Lift barrier screen and pull towards you. • barrier screen 2. Use the Glass Latch Tool to grip the latch bar and pry it over •...
-
Page 13: Important Safety Information
IMPORTANT SAFETY INFORMATION FOR THE HOMEOWNER Annual Inspection • This fireplace must be installed and serviced by your dealer • Have the fireplace inspected annually before use. or a qualified service technician. other than cleaning the • more frequent inspection and cleaning may be required if the glass and replacing the light bulbs, there are no user- fireplace is installed in an area exposed to pet hair or dust, serviceable components. -
Page 14: Safety Information For Users Of Propane Gas
SAFETY INFORMATION FOR USERS OF PROPANE GAS Propane is a flammable gas which can cause fires and The odorant in escaped gas can adsorb or absorb onto or explosions. In its natural state, propane is odorless and into walls, masonry and other materials and fabrics in a room. colorless. -
Page 15: Requirements For Massachusetts
REqUIREMENTS FOR MASSACHUSETTS For all side wall horizontally vented gas fueled equipment 4. INSPeCTIoN. The state or local gas inspector of the installed in every dwelling, building or structure used in side wall horizontally vented gas fueled equipment whole or in part for residential purposes, including those shall not approve the installation unless, upon owned or operated by the Commonwealth and where the inspection, the inspector observes carbon monoxide... -
Page 16: Warranty
WARRANTY empire Comfort Systems Inc. warranties this hearth product to be free from defects at the time of purchase and for the periods speci- fied below. Hearth products must be installed by a qualified technician and must be maintained and operated safely, in accordance with the instructions in the owner’s manual.
