Secuence of messages:
Message type 0
Power on
ask for Donwlink message for
remote settings
Downlink Message
It's possible set the device in the cloud without interacting with it locally, defining this type of downlink message
and CT value on the sigfox backend or in your platform. That method is optional but it's not necessary.
Byte 1
Easy Meter Setup byte
Field
(1byte)
Bit 7 1 (by default)
Bit 6 0 (by default)
Bit 5 1/0 enable/disable set Type uplink Messsage
Bit 4 1/0 enable/disable set Interval to send
Value
Bit 3 0 (by default)
Bit 2 0 (by default)
Bit 1 0 (by default)
Bit 0 0 (by default)
Example for downlink message:
B0 00 00 00 00 01 0F 00 → With this downlink message set the remote with type of message 01
and interval to send 15minutes.
Message Message
type 1 or 2 type 1 or 2
2 - 5 6 7 8
Type uplink Interval to Not
Not used
Message send Not
(4 bytes)
(1 byte) (minutes) used
0x00 0x00 01
[10...59] 0x00
0x00 0x00 02
4
