SenNet IoT Pulse Counter Sigfox Quick Start Manual page 2

www.satel-iberia.com
Input signals
This device is used to measure any type of meter with output pulse (reed or transistorized type) with low
frecuency.
Type input pulse
Maximum frecuency
Type
Leakage current (close reed)
*For industrials enviroment is it possible increase this leakeage current to avoid
detect electrical noise like an impulse. Contact with our support team.
Battery life
This device is desing to very long life. Life of batteries will depend of three variables:
type message , interval to send, number of impulses readed. Adjust interval to send and type of message by
customer requeriment
Battery life estimation
Type message 1 / 20 minutes sends
Type message 2 / 20 minutes sends
*Main condition, low rate of pulse.
If your rate of pulse counter is very high, use power supply versión.
10Hz
Reed / transistorizado
40uA *
7 years*
6 years*
2
Holding case
IP Grade
Temperature details
Working temperature -20ºC...+70ºC
Store temperature -20ºC...+75ºC
Holding
Dimensions 119 x 111 x 53 mm
Type mount Wall or din rail
Plastic Material
*If you need an upper grade contact with out support team.
wall mount (by default)
*specify on your order
SenNet Pulse Counter Sigfox
IP-60*
ABS – V0
rail din mount (accesory)
