www.satel-iberia.com
SenNet IoT CO
General description
SenNet IoT CO2-TH Sigfox is a low power device, that take samples of temperature, humidity and CO2 level with
a interval of time setup.
Use sigfox network to connect with your cloud or platform.
These are the reference at depend of power supply type battery or AC power:
Reference
CO2-TH Sigfox bat ++
CO2-TH Sigfox AC
Wired & Setup
-TH Sigfox
2
Power supply type
Battery
3.6v@18000mAh (LS26500 x2)
AC Power supply
100-265Vac
1
Basic steps to intall:
1.
Set interval to send (by default 15 minutes).
2.
Take note ID / PAC to sign the device on Sigfox Cloud.
3.
Plug-in pack batteries or AC power supply.
Setup parameters methods:
•
Throught donwlink message (see donwlink message seccion) ,
recommend method.
•
By cable micro-USB with PC console enter menu to set these
parameters.
Nivel de CO2
400-5.000ppm
(+/-30ppm)
Temperatura
0-50°C
(+/-1°C) *
Humedad
0-100%RH
(+/-5%) *
SenNet CO2-TH Sigfox
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SenNet IoT CO2-TH Sigfox
Summary of Contents for SenNet IoT CO2-TH Sigfox
- Page 1 Nivel de CO2 General description 400-5.000ppm SenNet IoT CO2-TH Sigfox is a low power device, that take samples of temperature, humidity and CO2 level with (+/-30ppm) a interval of time setup. Use sigfox network to connect with your cloud or platform.
- Page 2 , interval to send, number of impulses readed. Adjust interval to send and type of message by wall mount (by default) rail din mount (accesory) customer requeriment Battery life estimation 10 minutes sends 2 years 20 minutes sends 5 years 30 minutes sends 7 years *specify on your order SenNet CO2-TH Sigfox...
- Page 3 Type Message SenNet IoT Pulse Counter Sigfox is an very low power device capable to measure temperature / humidity and CO2 level. There is only one type of message 01, and its format to use on parser function is: A common point in all types of messages is the head (defined with 2 bytes) that includes important information embedded in the message (type device/type message/errors..
- Page 4 (by default) Bit 2 (by default) Bit 1 (by default) Bit 0 (by default) Example for downlink message: 90 00 00 00 00 01 0F 00 → With this downlink message setup interval to send to 15minutes. SenNet CO2-TH Sigfox...
-
Page 5: Warranty
For exposing the equipment to extreme temperatures, which exceed the operating or storage temperature limit. • Due to a modification of the product by the client without prior notice to Satel Spain. Faced with possible errors in this technical sheet, keep it updated in our website. SenNet CO2-TH Sigfox...
