- Page 1 Volume Measurement Reader VM200/ VM200BT Quick Start Guide V1.9...
-
Page 2: Data Output
Green LED. You can start your work now ! If it is fail, the VM200 will keep the Be-Be-Bi-Bi beeping and to flash LED. You have to plug again or check. Note: this manual is applicable to VM200 and VM200BT. -
Page 3: Set Up The Device
2. Set up the Device VM200 with USB Interface 1. Connect the Interface Cable(RJ45 end) to the VM200. 2. Connect the USB Interface cable to a PC/host. 3. Plug the power adaptor into the Power outlet. 4. Connect the power adaptor plug in the injector on the cable to power it on if required. - Page 4 3. Configurable Button Setting VM200 consists of two buttons. One “Trigger” button (A) and another “Touch” button (B). The two buttons are configurable in one of 6 optional combinations to be best fit to your application. Note: VM is Volume measurement The default buttons setting is <4>.
- Page 5 Button Behavior Setting Note: VM is Volume measurement, 2D is barcode reading, Switch is to switch (A)-button in between VM and 2D barcode reading. A:2D / B:VM A:VM / B:2D A:2D / B:Switch <A:VM / B:Switch> A:barcode then VM A:VM then barcode scan, B:redo scan scan, B:redo scan...
- Page 6 3. Reading Mode There are 3 measuring ways, Pitch scan- Appropriate to scan a cuboid shape with horizontal placement on the longer side of this object. Vertical scan- Appropriate to measure an irregular shape and its dimension output is the minimum cuboid shape can cover this irregular object.
- Page 7 Patenting Guiding Aimer Pitch scan How to aim and measure an object - When a user triggers a VM200 to measure (e.g.) a carton, he/she can manipulate it (move closer to or far from the carton) to lead the cross-shaped “+”...
- Page 8 Vertical scan How to aim and measure an object- When a user triggers a VM200 to measure (e.g.) a carton, he/she can manipulate it (move closer to or far from the carton) to lead the cross-shaped “+” laser aimer aims at the middle area above this carton.
- Page 9 5. Correct and Incorrect Reading Pitch scan CORRECT The width of the Horizontal line of “+” is close to or longer than the width of F-Edge on the measured face of the carton, and the Vertical line of “+” aimed at around the middle area of the F-Edge. INCORRECT Case A: too close to the carton, the width of the horizontal line of...
- Page 10 Vertical scan CORRECT The width of the Horizontal line of “+” is close to or longer than the width of the carton, the Vertical line “+” is located around the middle area above the carton INCORRECT Cases A: too rightward or B: too leftward, the vertical line of “+”...
- Page 11 6. Reading distance and angle Pitch scan The best reading distance is read from 40cm~150 cm to the surface of a carton / object. The best pitch (forward/backward) reading angle is 35°~65°. 65° 35° The best skew (leftward/rightward) reading angle is ±7°.
- Page 12 Vertical scan The best reading distance is read from 40cm to the upper surface of a carton / object and within 150cm from the ground. Keep vertical to the upper surface of the carton when measuring, and the best pitch (forward/backward) reading angle and best tilt (leftward/rightward) reading angle is ±10°...
- Page 13 Reading zone detection alarm setting <Alarm Enable> Alarm Disable...
- Page 14 7. Indicators - LED and Beeper General Operation...
- Page 15 Power and Bluetooth LED and Beeper for VM200BT...
- Page 16 The default data output is fixed length described as table, a space is in between each data column. ‘<2D>’ presents the barcode data, ‘<3D>’ presents the measurement data; For example, <3D> VM200 835DMT900338 CM 27.40 17.70 20.50 27.00 18.00 21.00 66.00 10206.00 <2D>7311271448044...
- Page 17 Outputted as Bytes of Value is Data Output ( presents a data (Example) space) W-Width (rounded) 20.1 20.00 H-Height (rounded) 102.4 102.00 L-Length (rounded) Sum of dimension 202.00 Volume 10102 10102.00 Dimensional weight Carriage Return Line Feed (Above examples of “Values is” are not relevant to each other, just for explanation purpose.) Note: Data values are outputted in fixed length.
- Page 18 9. Configuration Bar Code Version Information Set All Default Interface Selection <RS232> USB-VCOM...
- Page 19 Reading Mode <Good read off> Trigger On/Off Select Terminator <CR+LF> None...
- Page 20 Unit of Measurement <CM> INCH...
-
Page 21: Output Data
Output Data Width Disable <Width Enable> <Height Enable> Height Disable <Length Enable> Length Disable... - Page 22 <Volume Enable> Volume Disable <Sum Dimension Sum Dimension Enable> Disable D-Weight Enable <D-Weight Disable>...
-
Page 23: Setup Baud Rate
Setup Baud Rate 9600 19200 <115200>... - Page 24 2D Barcode Reader Configuration Symbology Selection < UPC-A ON> UPC-A OFF <UPC-E ON> UPC-E OFF...
- Page 25 <EAN-13/JAN-13/ EAN-13/JAN-13/ ISBN-13 ON> ISBN-13 OFF <EAN-8/JAN-8 ON> EAN-8/JAN-8 OFF <CODE 39 ON> CODE 39 OFF CODE 128 OFF <CODE 128 ON>...
- Page 26 <CODABAR/NW7 ON> CODABAR/NW7 OFF Interleaved 25 OFF <Interleaved 25 ON> <GS1 Data Bar- GS1 Data Bar- Omni directional OFF> Omni directional ON <GS1 Data Bar- GS1 Data Bar- Limited OFF> Limited ON...
- Page 27 <GS1 Data Bar- GS1 Data Bar- Expanded OFF> Expanded ON <QR Code ON> QR Code OFF <PDF417 ON> PDF417 OFF <Data Matrix ON> Data Matrix OFF...
- Page 28 <Micro QR OFF > Micro QR ON <Aztec OFF> Aztec ON Micro PDF417 ON <Micro PDF417 OFF> (Optional) Han Xin Code ON <Han Xin Code OFF> (Optional)
- Page 29 Select All Barcodes Send Character by ALT Method Enable <Disable>...
- Page 30 9. Download the Product Support Library You can visit Google drive to download the product support library by the below link. https://drive.google.com/drive/folders/1qaf 6tDcp7oNvMHpVYJIvSVVcB758wkDg Or, to scan this QRCode to get the download link. For more information, please contact our sales representatives or local distributors.
