Champtek IG300BT User Manual

Hide thumbs Also See for IG300BT:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
IG300BT
C1/C2 Area image Barcode Scanner
User's Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IG300BT and is the answer not in the manual?

Questions and answers

Related Manuals for Champtek IG300BT

Summary of Contents for Champtek IG300BT

  • Page 1 IG300BT C1/C2 Area image Barcode Scanner User’s Manual...

  • Page 2: Table Of Contents

    Conents Conents ............ 2 1. Introduction......... 5 1.1 Safety & Caution ......5 1.2 FCC Warning ........6 2. General Description ......7 2.1 Product Description ......7 2.2 Illustration ......... 7 3. Installation .......... 8 3.1 Unpacking ........8 3.2 Mounting ..........
  • Page 3 6.1 Factory Default ....... 17 6.2 Scanning Triggering ...... 17 6.3 Trigger Time Out ......19 6.4 Good Read Mode ......20 6.5 Buzzer Beep Tone ......20 6.5.1 Beep Tone Setup ......20 6.5.2 Good Read Beeps ...... 21 6.5.3 Beep Duration ......
  • Page 4 7.7.5 Postambles ......... 48 Appendixes ..........49 Decimal Value Table ....49 ASCII Table ........50 Readable Symbologies ....51 Technical Specifications..... 52 Scan Map ........55 Test Symbologies ......56...

  • Page 5: Introduction

    1. Introduction Thank you for purchasing this brand-new designed 2D imager hand held barcode scanner. This is a cutting-edge gun-type Area Imaging barcode scanner which is designed specifically for retailer, entertainment coupons, medical environment, shipping industry and etc. That adds on more user friendly functions and has replaceable cable that makes it more easily to be operated by the customers.

  • Page 6: Fcc Warning

    12) If there are the following situations please contact with the qualified serviceman to check this equipment. 13) The damage of wire or pin of power supply. 14) Some Liquid infiltrate into the equipment. 15) The equipment has been exposed to wet environment.

  • Page 7: General Description

    2. General Description 2.1 Product Description IG300BT is a high performance wireless 2D imager barcode scanner supporting liner, area imager barcode scanning. This device is very easy to configure by this manual, you can set up by scanning all necessary...

  • Page 8: Installation

    3.2 Mounting Once you have unpacked all components, you can start installing the device as below steps: IG300BT Scanner 1) The Scanner must be charged for a minimum of 8 hours before the scanner can be placed in full operation for the first time.
  • Page 9 LED and beeper warning. IG300BT Cradle Connect the supplied communication cable at the bottom side of the scanner and you will hear a “click” when the connection is made. Turn off the host system. Connect the other side of the communication cable to the right connector of your Host system.

  • Page 10: Cable Installation

    Cable Installation Connect cable and adaptor to Cradle. The other end of cable will be connected with Host device. Lock the iron panel of Cradle by screwdriver. Skip resistant pad position...

  • Page 11: Set Up Bluetooth Communication

    4. Set up Bluetooth Communication Before the operation, Bluetooth Communication must be set up between the scanner and cradle. 4.1 Pairing Each scanner has to be linked or paired to a cradle by scanning the unique Bluetooth MAC address code located on the bottom of cradle.

  • Page 12: Set Up Slave Mode Communication12

    ATTENTION: It is important to know that the scanner will only communicate with the cradle with the unique Bluetooth MAC address. Other scanner can not pair with that cradle until the original connection is broken. If the cradle pairs with another scanner, the cradle will disconnect with the first scanner and then re-connect with another scanner.

  • Page 13: Set Scanner Pin Code Mode

    4.4.1 Set Scanner Pin Code Mode Set Default Security Code <PINCODE = 000000> Set Security Code ON <Set Security code OFF> 4.4.2 Set Pin Code Character (PINCODE max. 6 digits/0-9and A-Z ASCII CODE) Set Default Security Code Barcode <PINCODE = 000000> Begin to Set PINCODE Go to the ASCII Tables in Appendixes;...

  • Page 14: Bluetooth Cradle Setup

    4.5 Bluetooth Cradle Setup 4.5.1 Set Cradle Security Mode Set Default Security Code Barcode <PINCODE = 000000> Set Security ON <Set Security OFF> 4.5.2 Set Cradle Pin Code (PINCODE max. 6 digits ,0-9,A-Z ASCII CODE ) Set Default Security Code Barcode <PINCODE = 000000>...

  • Page 15: Configuring

    5. Configuring 5.1 Preface How to configure this device: The Barcode Programming Feature gives the possibility to change the scanner settings with use programming codes. 5.2 Changing Scanner Settings with Programming Codes You can setup your device by scanning all necessary programming codes for parameters that meet applications.

  • Page 16: Changing Scanner Settings With Utility Tool

    5.3 Changing Scanner Settings with Utility Tool Manufacturer has setup this scanner with the most common used programming codes, It could be possible that you need more advanced settings to use the scanner without any problems into your application. In this case you can setup your scanner by using the advanced Utility Tool.

  • Page 17: Operating Settings

    6. Operating Settings 6.1 Factory Default Set Scanner /Cradle factory default The scanner and cradle factory default settings are < > shown with bold in the following pages. Reset all configuration parameters to their factory default setting. After this reset you must select all required parameters that meet applications.
  • Page 18 Flashing Flashing mode allows power up the lighting and decoding are on (no need to activate the trigger line) and after a period of inactivity lasting the time specified by the trigger timeout, the scanner starts flashing, checking for a bar code to be read. When a bar code is detected, the lighting and decoding automatically turn on and stay on until another period of inactivity (timeout), after the timeout...

  • Page 19: Trigger Time Out

    Presentation This mode allows power up lighting and decoding are on. After a period of inactivity lasting the time specified by the trigger timeout, the lighting turns off or is dimmed. When a new bar code is presented the lighting and decoding restart and stay on until another period inactivity.

  • Page 20: Good Read Mode

    6.4 Good Read Mode When active, the scan engine stops the reading session after a successful decoding. Note: This parameter is NOT used with continuous and continuous + flashing modes. <Active > Not Active 6.5 Buzzer Beep Tone 6.5.1 Beep Tone Setup <High >...

  • Page 21: Good Read Beeps

    6.5.2 Good Read Beeps <One Beep > Two Beeps None 6.5.3 Beep Duration 60 msec <80 msec> 200 msec...

  • Page 22: Timing

    6.5.4 Timing <During Transmission> Before Transmission After Transmission 6.5.5 Good Read Duration <80 msec> 0.5 sec 1 sec 6.5.6 Error Beep <On> 6.5.7 Setup Beep <On>...

  • Page 23: Imager Settings

    7. Imager Settings 7.1 Imager Mode You can set the best reading performance depends on the environment, your used application and type of barcodes. Linear mode for decode 1D Barcodes.  Area mode for decode 1D and 2D barcodes.  Area mode allows you to set the position of the VEGA in any direction regardless of the orientation of the barcode, and perform a good read on 1D and 2D...

  • Page 24: Sleep Mode

    7.2 Sleep Mode The scanner is equipped with sleep mode function to save battery energy when the scanner is not used for 1 minute or 10 minute. During sleep mode, all the functions and connection will be halted until pressing the trigger button of scanner to wake up and reconnect the communication with the cradle or Bluetooth device.

  • Page 25: Batch Mode

    7.3 Batch Mode This Batch mode function is enabled when you have scanned “Memory ON” barcode. Scanning data is stored in the memory of the scanner. This function is disabled when you have scanned “Memory OFF” barcode. When you have scanned “Out Of Range” barcode, The scanner transmits the scanning data of work range.

  • Page 26: Firmware Version

    7.4 Firmware Version Display the firmware version of the scanner, please scan below barcode. 7.4.1 Engine Firmware Version 7.4.2 Scanner Decoder Firmware Version 7.4.3 Cradle Decoder Firmware Version 7.4.4 Scanner Bluetooth MAC Address 7.4.5 Cradle Bluetooth MAC Address...

  • Page 27: Set Cradle Interface Barcode

    7.5 Set Cradle Interface Barcode Set Cradle KB Interface Barcode Set Cradle RS232 Interface Barcode <Set Cradle USB HID Interface Barcode> 7.6 Cradle RS232 Communication Parameter 7.6.1 Cradle Baud Rate 1200 2400 4800 9600 <19200>...

  • Page 28: Cradle Data Bits

    38400 7.6.2 Cradle Data Bits 7 data bits <8 data bits> 7.6.3 Cradle Stop bits <1 bit> 2 bits 7.6.4 Cradle Parity <None> Even...

  • Page 29: Cradle Hand Shaking

    Mark Space 7.6.5 Cradle Hand Shaking RTS/CTS Enable <RTS/CTS Disable> ACK/NAK Enable <ACK/NAK Disable> XON/XOFF Enable < XON/XOFF Disable >...

  • Page 30: Cradle Keyboard Wedge Mode Parameters

    7.6.6 Cradle Keyboard Wedge Mode Parameters 1) Terminal type <IBM PC/AT,PS/2> IBM PC/XT IBM PS/2 25, 30 2) Capslock Detection Enable <Disable>...
  • Page 31 3) Upper/Lower Case <No change> Upper Case Lower Case 3) Send Character by ALT Method Enable <Disable> 4) Select Numerical Pad <OFF>...
  • Page 32 5) Time out Between Characters <0 ms> 5 ms 10 ms 25 ms 50ms 100ms...
  • Page 33 6) Language Selection <US English> UK English Italian Spanish French German Swedish Switzerland Hungarian...
  • Page 34 Japanese Belgium Portuguese Denmark Netherlands Turkey Reserved 1...

  • Page 35: Decoding Selection

    7.7 Decoding Selection 7.7.1 Symbologies Selection Australian Post ON <Australian Post OFF> AZTEC ON <AZTEC OFF> BPO ON <BPO OFF> Canada Post ON <Canada Post OFF > CODABAR ON...
  • Page 36 <CODABAR OFF> Codablock A ON <Codablock A OFF > Codablock F ON <Codablock F OFF > CODE 11 ON <CODE 11 OFF> <CODE 39 ON> CODE 39 OFF...
  • Page 37 CODE 93 ON <CODE 93 OFF> <CODE 128 ON> CODE 128 OFF <GS1-128 ON> GS1-128 OFF <DATAMATRIX ON> DATAMATRIX OFF Dutch Post ON...
  • Page 38 <Dutch Post OFF> <EAN-8 ON> EAN-8 OFF <EAN-13 ON> EAN-13 OFF <EAN 128 ON> EAN 128 OFF GS1 CC-A/B ON <GS1 CC-A/B OFF>...
  • Page 39 GS1 CC-C ON <GS1 CC-C OFF> GS1 DataBar-Omni ON <GS1 DataBar Omni OFF > GS1 DataBar Limited ON <GS1 DataBar Limited OFF> GS1 DataBar Expanded ON <GS1 DataBar Expanded> Infomail ON...
  • Page 40 <Infomail OFF> Interleaved 2 of 5 ON <Interleaved 2 of 5 OFF> Japan Post ON <Japan Post OFF> Matrix 2 of 5 ON <Matrix 2 of 5 OFF > MaxiCode ON <MaxiCode OFF>...
  • Page 41 MicroPDF417 ON <MicroPDF417 OFF> MSI ON <MSI OFF> <PDF417 ON> PDF417 OFF Planet ON <Planet OFF> PLESSEY ON...
  • Page 42 <PLESSEY OFF> Postnet ON <Postnet OFF> QR Code ON <QR Code OFF> QR Code - model 1 ON <QR Code - model 1 OFF> Standard 2 of 5 ON <Standard 2 of 5 OFF> Sweden Post ON...
  • Page 43 <Sweden Post OFF > Telepen ON <Telepen OFF> TLC 39 ON <TLC 39 OFF> <UPC-A ON> UPC-A OFF <UPC-E ON> UPC-E OFF...

  • Page 44: Disable All Symbologies

    7.7.2 Disable All Symbologies. If you want to disable all Symbologies, please scan below programming code. Or you can scan the “Off” option to disable individual symbologies. Disable All Symbologies Note: Do not reset individual parameters settings for each symbology. When you enable a symbology, you will recover the parameter settings stored in memory.
  • Page 45 7.7.3 Multi Code The multicode function is used configure the scanner to read a series of bar codes and then transmit them all at once. <Not Active> Active Active Exclusive Number of bar codes – compose: 2 Number of bar codes – compose: 3 Number of bar codes - compose: 4 Number of bar codes –compose: 5 Number of bar codes –...

  • Page 46: Identifier (Udsi) Transmission For All Symbologies

    7.7.4 Activates user defined symbology identifier (UDSI) transmission for all symbologies. <Not Transmitted > UDSI Transmitted Data Format: [UDSI symbology id] <data> Symbology Default Identifier Australia Post Aztec Canada Post Codabar Codablock A Codablock F Code 11 Code 39 Code 93/93i Code 128 DataMatrix Dutch Post...
  • Page 47 EAN-8 EAN-13 GS1-128 GS1 Composite A/B GS1 Composite C GS1 DataBar GS1 DataBar Limited GS1 DataBar Expanded Interleaved 2 of 5 Japan Post Matrix 2 of 5 MaxiCode MicroPDF417 MSI Code PDF417 Planet Plessey Code Postnet QR Code Standard 2 of 5 Sweden Post Telepen TLC 39...

  • Page 48: Postambles

    7.7.5 Postambles The scanner can be programmed to output Barcode data according to the following format: [BAR CODE DATA] [POSTAMBLE STRING] Postamble None <CR+LF >...

  • Page 49: Appendixes

    Appendixes A. Decimal Value Table...

  • Page 50: Ascii Table

    B. ASCII Table...

  • Page 51: Readable Symbologies

    C. Readable Symbologies 1D Symbologies Default Symbologies Readable Enable ○ ○ EAN/UPC ○ ○ UCC/EAN128 ○ ISBN ○ ISBT ○ Code 11 ○ ○ Code 39 ○ Code 93/93i ○ ○ Code 128 ○ Interleaved 2 of 5 ○ Matrix 2 of 5 ○...

  • Page 52: Technical Specifications

    2D Symbologies Default Symbologies Readable Enable ○ Data Matrix ○ ○ PDF417 ○ MicroPDF417 ○ MaxiCode ○ QR code ○ Aztec ○ EAN.UCC composite D. Technical Specifications D-1 Physical Characteristics Weight IG-300BT Scanner Approx. 210g Cradle Approx. 105g Accessory KBW cable Approx.
  • Page 53 Vertical 80°±10% (Left 40°/ Right 40°) Interface IG-300BT KBW, RS-232, USB (HID KBW) b) Bluetooth Characteristics (for IG-300BT series) Bluetooth Module Bluetooth V2.0 Standard Frequency Band 2.402GHz ~ 2.480GHz Modulation Method GFSK for 1Mbps RF Output Power Under 4dBm (Class 2) Class2;...
  • Page 54 2 blink and 2 beeps low Battery warning 2 long blink and 2 long good read beeps but transmit fail continue on in charging 3 short beeps BT disconnect 2 blink per 2 second on connecting BT disconnect Blue flash before sleep 1 blink per 2 second BT connected...

  • Page 55: Scan Map

    E. Scan Map Symbology Density Minimum Maximum Distance Distance (+/- 10%) (+/- 10%) Code 39 0.125 mm 5.2 cm 12.1 cm 0.20mm 2.0 cm 21.5 cm 0.25mm 2.4 cm 26 cm 0.5mm 4 cm 44 cm 7 cm 82 cm UPC / EAN 0.33 mm 4 cm...

  • Page 56: Test Symbologies

    F. Test Symbologies Scan one or more of these barcodes to test barcode symbologies you enabled. Codabar Code 39 Code 93 Code 128 DataMatrix EAN 8 1234 5670 EAN13 1 234567 890128 EAN 128 Interleaved 2 of 5 MSI code...
  • Page 57 PDF417 GS1 DataBar Omnidirectional GS1 DataBar Omni Stacked GS1 DataBar Expanded GS1DataBar Expanded Stacked GS1 DataBar Limited UPC A 12345 67890 UPC E 123456...
  • Page 58 0145-88E0041...
