- Page 1 ALPHA LITE ALPHA LITE USER MANUAL USER MANUAL BOOK BOOK D L S E R I E S D L 1 0 0 D L 1 0 0...
- Page 2 Product name. Product name. DL100 DL100 Precautions 〔 WARNING 〕 Do not open or disassemble the cover to reduce the risk of electric shock. Please wear safety equipment such as safety helmet during work. Please install the signs below for people to bypass when install the product on high truss.
-
Page 3: Table Of Contents
ALPHA LITE ┃ USER MANUAL BOOK C o n t e n t s Safety Information Fixture Information Connection and Setting Fixture Information Connection Diagram Power Connection Fixture Exterior View Dimensions Lighting On/Off Address Setting Technical Specifications... -
Page 4: Fixture Information
Product name. Product name. DL100 DL100 Product name. DL100 ⇒ Average CRI 97 or higher ⇒ COB LED Chip ⇒ Horizontal 360˚, vertical 27˚ angle adjustable ⇒ All-in-one Main drive controller ⇒ Maintain the last signal when DMX signal is lost ⇒... -
Page 5: Fixture Exterior View
ALPHA LITE ┃ USER MANUAL BOOK Fixture Exterior View... -
Page 6: Dimensions
Product name. DL100 Dimensions... -
Page 7: Technical Specifications
ALPHA LITE ┃ USER MANUAL BOOK Technical Specifications 100W LED Chip Type 50,000 Estimated LED Lifetime (hours) 3200 / 5600 (FCT) White Light (K) CRI 97 / TLCI 97 Color Rendition (%) 0~100 (16-bit) Dimming (%) Cut-off Size Diameter 205-230 / 8.1-9.1... -
Page 8: Connection Diagram
Product name. DL100 Connection Diagram Controller SMPS... -
Page 9: Power Connection
ALPHA LITE ┃ USER MANUAL BOOK Power Connection SMPS - AC connection Connect 100~220V Free Volt AC input cord to connector. Brown Yellow - Green Blue * Check the status when connecting. Connector < image 01 > SMPS – AC Thru connection Other controller SMPS can be connected to SMPS connector with AC power cord. -
Page 10: Lighting On/Off
Product name. DL100 Lighting On/Off Manual operation without DMX signal. Light on Dip switch #1 and #10 go down, The light turn on. Light off Dip switch #1 goes up while the light is on, the light turns off. WARNING 1. -
Page 11: Address Setting
ALPHA LITE ┃ USER MANUAL BOOK Address Setting Free Recommended Application Dip switch value (binary) can be easily converted. This APP is only for explaining the settings and you don’t have to use this APP. DMX Calc (Android) DMX Dip (iOS) - Page 12 ALPHA LITE USER MANUAL BOOK 82-2-6317-0464 <Tel > 82-2-2039-0464 <Fax> hello@alpha-lite.net <E-mail> www.alpha-lite.net <Web> 2-4 Floor, 5-8, Gyeongin-ro 88-gil,Yeongdeungpo-gu,Seoul,Republic of Korea, 07363...
