MTI Freedom Micro II Product Manual page 4

Instructions & Videos:
AR: attar.store.mobiletechinc.com
COR: att.store.mobiletechinc.com
TRACK KIT CONFIGURATIONS
Solid Surface, Grommet
or Radial Track
Spacer Adapter
Spacer Screws
Track Mounting Tabs
Mounting Tab Screws Long
TRACK INSTALLATION
1
Attach Spacer Adapter with the spacer screws using the
Double-Sided System Tool. Make sure that the spacer
number is facing down.
www.MTIGS.com | T:800.897.1350
-CONTROLLED DOCUMENT-
Questions & Troubleshooting:
800.897.1350
Through Track
with Acrylic Top
Spacer Adapter
Spacer Screws
Track Mounting Tabs
Mounting Tab Screws Long
M0494 A-0 Status: Approved
Product Ordering:
AR: attar.store.mobiletechinc.com
COR: att.store.mobiletechinc.com
Rotate the mounting tabs onto the mounting screws
2
until flush with bottom of screw. Make sure the
DOTTED side of the mounting tabs is facing DOWN.
P/N M0494 rev A ©2022 MTI All Rights Reserved
ECO-113512
Order Inquiries:
attsalessupport@mtigs.com
Aluminum Track
or Panel Wall
Spacer Adapter
Spacer Screws
Track Mounting Tabs
Mounting Tab Screws Short
4
