MTI Freedom Micro II Product Manual page 3

Instructions & Videos:
AR: attar.store.mobiletechinc.com
COR: att.store.mobiletechinc.com
REQUIRED TOOLS
OEM POWER CABLE ROUTING
1 Riser, spacers, and baseplate come pre-assembled as shown. Upon opening the box, loosen all four screws 3-4 turns to
route OEM power cable in next step. If your base has track adapter baseplate, follow these same steps.
Feed OEM power cable included with device through
2
cable channel between the riser and baseplate. Cable
should be routed such that the device end of the cable
is inserted to the back of the riser and exits from the
front of the riser.
www.MTIGS.com | T:800.897.1350
-CONTROLLED DOCUMENT-
Questions & Troubleshooting:
800.897.1350
M0494 A-0 Status: Approved
Product Ordering:
AR: attar.store.mobiletechinc.com
COR: att.store.mobiletechinc.com
3
Tighten all four baseplate screws after routing OEM
power cable.
P/N M0494 rev A ©2022 MTI All Rights Reserved
ECO-113512
