Goodman GMEC96 Series Manual

Heating Input: 30,000-120,000 BTU/h
Standard Features
• Energy-efficient, multi-speed ECM blower motor
• Heavy-duty, aluminized-steel tubular heat exchanger
• Stainless-steel secondary heat exchanger
• Two-stage gas valve provides quiet, economical heating
• Durable Silicon Nitride igniter
• Quiet two-speed induced draft blower
• Self-diagnostic control board with constant
memory fault code history output to a LED
• Color-coded low-voltage terminals with provisions
for electronic air cleaner and humidifier
• Low continuous fan speed options offer quiet air circulation
• All models comply with California 40 ng/J
Low NOx emissions standard
• Can no longer be installed in California's South Coast
Air Quality Management District (SCAQMD)
on or after October 1, 2019.
• AHRI Certified; ETL Listed
SS-GMEC96
Downloaded from ManualsNet.com
* Complete warranty details available from your local dealer or at www.goodmanmfg.com. To receive the Lifetime Heat Exchanger Limited Warranty (good for as long
as you own your home), 10-Year Unit Replacement Limited Warranty and 10-Year Parts Limited Warranty, online registration must be completed within 60 days of
installation. Online registration is not required in California or Québec.
search engine
Cabinet Features
• Designed for multi-position installation -
upflow, horizontal left or right
• Certified for direct vent (2-pipe)
or non-direct vent (1-pipe)
• Easy-to-install top venting with optional side venting
• Convenient left or right connection
for gas and electrical service
• Cabinet air leakage (Q
• Heavy-gauge steel cabinet with durable finish
• Fully insulated heat exchanger and blower section
• Airtight solid bottom or side return with easy-cut tabs
for effortless removal in bottom air-inlet applications
www.goodmanmfg.com
GMEC96
Two-Stage, Multi-Speed
ECM Gas Furnace
Up to 96% AFUE
Contents
Nomenclature ........................................ 2
Product Specifications ........................... 3
Dimensions ............................................ 4
Airflow Specifications ............................ 5
Wiring Diagrams .................................. 17
Accessories .......................................... 18
) ≤ 2%
Leak
12/21
Supersedes 10/19
