14

Settings

DDCS address setting (S1, S2)

Switches S1 and S2 define a node address for the APBU-44C(E) when it is
connected to a DDCS link (typically a PC).
The DDCS address is the combined value of S1 and S2.
S1
0
0
•••
0
1
•••
F
Installation
4 4
1 2 3 4
D I P
S1 S2
S2 DDCS Notes
address
0 00h
1 01h Default
••• •••
F 0Fh
0 10h
••• •••
F FFh
L O G I C V E R S I O N
B A R C O D E L A B E L
5 6
O N
–
•••
–
–
•••
–
