- Page 1 THRED-O-MATIC ® 66-A Instructions for use www.Rothenberger-USA.com...
-
Page 2: Table Of Contents
Groover Head Assemblies ..........14 Snap-O-Matic Die Head Assemblies ........15 Carriage Assembly ..............16 Oil Line Schematic ..............17 Lubrication Assembly ............18 Wiring Diagram ..............19 Die Segment Index ............20-21 Thread Sizes & Specifications ........22-23 Warranty .............. Back Cover Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... -
Page 3: Operator Safety Instructions
On/Off made or authorized by Rothenberger can Switch should always be accessible to operator. result in serious injury and void Rothenberger's warranty and liability. 12. Operate in proper environment. Machine should not be operated in damp locations. Wear hearing REMEMBER: protection in noisy shop environments. -
Page 4: Specifications
"66-A" are made thicker to provide for proper oil drainage out of the pipe. Care should be taken in mounting machine to maintain the height differential. Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... -
Page 5: Operating Procedure
It is best to ream the pipe before groove depth scale or coupling for this purpose. threading. Visually you may determine signs of a dull or improperly sharpened cutting tool if you notice excessive burr on pipe after cutting. Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... -
Page 6: Die Head Adjustment
2. Snap-O-Matic heads - Loosen two screws and move selector plate in the direction indicated on the selector plate . Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... - Page 7 3. Remove spindle cover. 4. Tighten brake adjustment bolt. 5. Start machine. 6. Push "stop" button and spindle should coast ¼-½ revolution. If not, repeat steps 4, 5 and 6. 7. Replace spindle cover. Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com...
-
Page 8: Main Assembly-Exploded Views
THRED-O-MATIC 66-A ® Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... -
Page 9: Main Assembly-Parts
4675 PILLOW BLOCK,TRANSMISSION R04201377R CLAMP OIL LINE 22ACL SLEEVE 04313-1 SWITCH, PUSH BUT. R04201452R HANDLE, 44A/66A BASE DOOR R04201205R SCREW, MACH. SLT PH HDK-961, #10-32X1" R04201222R SELF TAPER R04201586R GUARD, SPLASH R04201222R SELF TAPER Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... -
Page 10: Transmission Assembly-Exploded View
THRED-O-MATIC 66-A ® Transmission Assembly No. 6662 Exploded View Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... -
Page 11: Transmission Assembly-Parts
VEP015 Expansion Plug 7/8 ........2 U0200-2385-RBK Rebuild Kit - Includes all Bold Shaded items .... 1 VHH005 Hex HD Cap Screw 5/16-18x7/8 ....8 VHH055 Hex HD Cap Screw 3/8-16x3 1/4 ....4 Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... -
Page 12: Cutter Assembly, Wheel Type
P/N 00097 PART NO. DESCRIPTION 01894 REAMER CONE, 22ACL 13212, 57011 5-BLADE R04201595R HOLDER, CONE REAMER U-717 PIN, SPRING, 0.187DX1.25 L R04201396R KNOB, 22ACL 1652 CONE REAMER R04201191R SCREW, SHOULDER-3/4 LONG & DIA, 5/8-11X7/8 TD Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... -
Page 13: Spindle Assembly
WASHER FLAT WIDE 3/8" DA-104-W R04201181R SCREW, SET, HEX CUP PTH-508-D,1/2"-13X1-1/4" R04201482R SPRING, BRAKE BAND R04200108R REAMER, BLADE 2-1/2"-4" R04201750R BRAKE BAND, 66A R04200183R REAMER, BLADE, 5"-6"12238 R04201481R BOLT, ADJUSTING, BRAKE 33A, 44A, 4261-1 Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... -
Page 14: Groover Head Assemblies
SCREW CAP HEX 1/2-13X1/2 R04201070R LOCK WASHER HELIC. SPRG C-110-HC 5/16" 25 R04201123R SCREW CAP SOC HDF-208 5/16-18X1-1/2" 15 R04201113R SCREW CAP SOC HDF-105 1/4-20x3/4" 26 R04201637R EXTENSION DIE SLOT 122261 R04201033R NUT, HEX 1/4-20 Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... -
Page 15: Snap-O-Matic Die Head Assemblies 2
⁄ " R04201922R BALL, BEARING. ⁄ " DIA. R04201359R PIN, DIE HEAD,1431-1 R04201636R SPRING COMPRESSION DIE,12220 HEAD — DIES, SET OF 4, SPECIFY SIZE AND TYPE (SEE DIE TABLES) R04201617R PLUG, EXPANS, .375 DIA. Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... -
Page 16: Carriage Assembly
ADAPTER, DIEHD,1.0-2.0 R04201594R PIN,SMALL DIE HD ADPTR 01572 PIN, DIEHEAD REST R04201028R SCREW, CAP,HEX 1/2-13XA-505-P,1/2-13 X 1/2 R04201178R SCREW, SET, HEX CUP PTH-503-D, 1/2"-13X1/2" R04201152R SCREW, SET, HEX CUP PTH-104-D, 1/4"-20X3/8" R04201838R PIN,CUTTER PIVOT Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... -
Page 17: Oil Line Schematic
THRED-O-MATIC 66-A ® Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... -
Page 18: Lubrication Assembly
12 R04202024R 13739-26 TUBING 26" R04202021R SLEEVE, COMPRESSION13736 13 R04201115R SCREW, CAP, SOC 22ACLF-107, 1/4-20X1" R04202022R BUSHING, COMPRESSION13737 14 R04203209R LOCK WASHER,HEL 22ACL C-109-MP, 1/4" R04202024R 13739-21 TUBING 21" 15 R04201087R WASHER, FLATDA-102-W, WIDE 1/4" Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... -
Page 19: Wiring Diagram
THRED-O-MATIC 66-A ® Thred-O-Matic "66-A" Wiring Diagrams ® Three Phase Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... -
Page 20: Die Segment Index
Dies 1" - 2" Series "44-A" and "66-A" Snap-O-Matic (5 segments) ⁄ " - 3" ⁄ " - 4" P/N 00041 P/N 00042 Dies 2 ⁄ " - 3" Dies 3 ⁄ " - 4" Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... - Page 21 THRED-O-MATIC 66-A ® Series "66-A" 5" - 6" P/N 00043 Dies 5" - 6" Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com...
-
Page 22: Thread Sizes & Specifications
THRED-O-MATIC 66-A ® Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com... - Page 23 THRED-O-MATIC 66-A ® Phone 800-545-7698 • FAX 815-633-0879 www.rothenberger-usa.com...
-
Page 24: Warranty
ROTHENBERGER liability does not extend beyond the repair or replacement of its product as warranted above. In no event shall ROTHENBERGER be liable for claims based upon breach of expressed or implied warranty, negligence or otherwise for any damages whether direct, immediate, incidental, foreseeable, consequential, or special.
