C-Mount Eyepiece Coupler
Part Number Focal Length
CCF28 28 mm
CCF35 35 mm
CCF35 45 mm
†Sold separately
Rigid Borescope Light Post Adapter
Manufacturer
GE Inspection Technologies
Henke-Sass Wolf
Olympus
®
Richard Wolf
KARL STORZ
†Sold separately
GE Inspection Technologies: productivity through
inspection solutions
GE inspection Technologies provides technology-driven
inspection solutions that deliver productivity, quality and safety.
We design, manufacture and service ultrasonic, remote visual,
radiographic and eddy current equipment and systems. We offer
specialized solutions that will help you improve productivity in
your applications in the aerospace, power generation, oil and
gas, automotive or metals industries.
www.ge.com/inspectiontechnologies
†
Recommended Scope
Rigid borescope greater than
4.0 mm diameter.
All fiberscopes and 2.7 mm
diameter rigid borescope.
1.7 mm and 1.9 mm diameter rigid
borescopes. Fiberscopes less than
2.0 mm in diameter.
Adapter Part Number
Included
Included
LGA-PAM†
LGA-PWF†
LGA-PS†
Borescope Adapter Kit Contents (Part No. MV1QABSA)
• Mentor Visual iQ Borescope Adapter
• Nylon carrying case
• GE Inspection Technologies light post adapter
• Quick start guide
Technical Specifications
Camera: 1/3" COLOR, SUPER HAD CCD
Pixel Count: 470,000 pixels
Camera coupling: 28 mm, 35 mm and 45 mm C-Mount
Illumination: Powered by Dual Internal High Intensity LEDs
Cable length: 1.97 m (6.46 ft.)
Weight: 0.89 kg (1.97 lbs.)
Construction: Painted Magnesium Body, Stainless Steel manocoil
with Rugged Neoperene Elastomer outer layer
Operating -20° to 46°C (-4° to 115°F)
Temperature:
Storage -25° to 60°C (-13° to 140°F)
Temperature:
Hazardous Not rated for use in hazardous environments
Environments:
