Di481 Intergrated Dishwasher Instruction Manual .indd 1
Di481 Intergrated Dishwasher Instruction Manual .indd 1
D i s h w a s h e r
I n s t r u c t i o n M a n u a l
D I 481
17/07/2020 15:17
17/07/2020 15:17

Advertisement

loading
Need help?

Need help?

Do you have a question about the DI481 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Caple DI481

Summary of Contents for Caple DI481

  • Page 1 I n s t r u c t i o n M a n u a l D I 481 Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk Di481 Intergrated Dishwasher Instruction Manual .indd 1 Di481 Intergrated Dishwasher Instruction Manual .indd 1...

  • Page 2: Table Of Contents

    Cleaning and Maintenance Installation Instruction Troubleshooting Technical Information Caple Contact Details Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 2 Di481 Intergrated Dishwasher Instruction Manual .indd 2 17/07/2020 15:17 17/07/2020 15:17...
  • Page 3 - Please unplug before cleaning or performing maintenance on the appliance. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 3 Di481 Intergrated Dishwasher Instruction Manual .indd 3 17/07/2020 15:17 17/07/2020 15:17...
  • Page 4 - Improper connection of the equipment-earthing conductor can result in the risk of an electric shock. - Check with a qualified electrician or Caple service representative if you are in doubt whether the appliance is properly grounded.
  • Page 5 - The appliance may only be used with correctly adjusted door springs. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 5 Di481 Intergrated Dishwasher Instruction Manual .indd 5 17/07/2020 15:17 17/07/2020 15:17...
  • Page 6 - If the supply cord is damaged, it must be replaced by Caple, its service agent or a similarly qualified person in order to avoid a hazard. - During installation, the power supply must not be excessively or dangerously bent or flattened.

  • Page 7: Warnings

    Collection of such waste separately for special treatment is necessary. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 7 Di481 Intergrated Dishwasher Instruction Manual .indd 7 17/07/2020 15:17 17/07/2020 15:17...

  • Page 8: Environmental Protection

    (placed on the inside of the appliance storage drawer). Registration can also be completed online by visiting www.caple.co.uk. Ensure you keep your warranty card safe, you may need to show it to Caple Service together with proof of purchase.

  • Page 9: Quick Operation Guide

    They will also dry better.Unload the appliance, starting from the lower b asket. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 9 Di481 Intergrated Dishwasher Instruction Manual .indd 9 17/07/2020 15:17...

  • Page 10: Control Panel

    Dispenser Filter assembly Adjuster Cup Shelf Lower Basket Inlet pipe connector Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 10 Di481 Intergrated Dishwasher Instruction Manual .indd 10 17/07/2020 15:17 17/07/2020 15:17...

  • Page 11: Dishwasher Features

    » Add 1.5Kg dishwasher salt and then fill the salt container with water. » Fill the Rinse Aid dispenser. » Fill in detergent. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 11 Di481 Intergrated Dishwasher Instruction Manual .indd 11 17/07/2020 15:17 17/07/2020 15:17...
  • Page 12 °dH: German degree (EN 50242) °fH: French degree °Clark: British degree Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 12 Di481 Intergrated Dishwasher Instruction Manual .indd 12 17/07/2020 15:17 17/07/2020 15:17...
  • Page 13 Instruction manual Di481 Please keep this instruction manual for future reference by s al ty w ater. Thi s is out of w arra nty. Di481 Intergrated Dishwasher Instruction Manual .indd 13 Di481 Intergrated Dishwasher Instruction Manual .indd 13 17/07/2020 15:17 17/07/2020 15:17 1.
  • Page 14 (e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 14 Di481 Intergrated Dishwasher Instruction Manual .indd 14 17/07/2020 15:17 17/07/2020 15:17...
  • Page 15 Detergents with its ch emica l ingredients are necessary to remove dirt, crush dirt a nd tr anspo rt it out of the dishwasher. Mo st of the comm ercial qu ality detergen ts are suitable for this pu rpos e. Di481 Intergrated Dishwasher Instruction Manual .indd 15 Di481 Intergrated Dishwasher Instruction Manual .indd 15...
  • Page 16 In this case please choose a programme with a higher temperature. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 16 Di481 Intergrated Dishwasher Instruction Manual .indd 16 17/07/2020 15:17...
  • Page 17 Take care to keep it out of reach of children. Take care to keep it out of reach of children. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 17 Di481 Intergrated Dishwasher Instruction Manual .indd 17 17/07/2020 15:17 17/07/2020 15:17...
  • Page 18 » Please observe the manufacturer’s recommendations on the detergent packaging. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 18 Di481 Intergrated Dishwasher Instruction Manual .indd 18 17/07/2020 15:17 17/07/2020 15:17...

  • Page 19: Loading The Dishwasher Baskets

    » Silver and aluminium parts have a tendency to discolour during washing. » Glazed patterns may fade if machine washed frequently. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 19 Di481 Intergrated Dishwasher Instruction Manual .indd 19 17/07/2020 15:17 17/07/2020 15:17...
  • Page 20 » Please do not overload your dishwasher. This is important for good results and for reasonable consumption of energy. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 20 Di481 Intergrated Dishwasher Instruction Manual .indd 20 17/07/2020 15:17 17/07/2020 15:17...
  • Page 21 Pull handle and lower ft the basket for Instruction manual Di481 Please keep this instruction manual for future reference for lower position pper position Di481 Intergrated Dishwasher Instruction Manual .indd 21 Di481 Intergrated Dishwasher Instruction Manual .indd 21 17/07/2020 15:17 17/07/2020 15:17...
  • Page 22 Large serving bowl Dessert dishes Dinner plates Soup plates Oval plates Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 22 Di481 Intergrated Dishwasher Instruction Manual .indd 22 17/07/2020 15:17 17/07/2020 15:17...
  • Page 23 Do not let any item Do not let any item d through the extend through the extend through the Di481 Intergrated Dishwasher Instruction Manual .indd 23 Di481 Intergrated Dishwasher Instruction Manual .indd 23 17/07/2020 15:17 17/07/2020 15:17...
  • Page 24 Do not le the sharp point down. Always l point do Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 24 Di481 Intergrated Dishwasher Instruction Manual .indd 24 17/07/2020 15:17 17/07/2020 15:17...
  • Page 25 10A 250VAC. Make sure that the water supply is turned on to full pressure. Insert the plug into the socket. The power supply is 220-240 VAC /50 HZ, the specification Di481 Intergrated Dishwasher Instruction Manual .indd 25 Di481 Intergrated Dishwasher Instruction Manual .indd 25...
  • Page 26 » Close the door » The dishwasher will start running again Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 26 Di481 Intergrated Dishwasher Instruction Manual .indd 26 17/07/2020 15:17 17/07/2020 15:17...
  • Page 27 It is dangerous to open the door during a wash cycle, because the hot water or steam may scald you. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 27 Di481 Intergrated Dishwasher Instruction Manual .indd 27 17/07/2020 15:17 17/07/2020 15:17...
  • Page 28 Step 1 Turn the filter in anti-clockwise direction, ： Instruction manual Di481 Please keep this instruction manual for future reference Step 2：lift the filter assembly up Di481 Intergrated Dishwasher Instruction Manual .indd 28 Di481 Intergrated Dishwasher Instruction Manual .indd 28 17/07/2020 15:17 17/07/2020 15:17...
  • Page 29 When cleaning the filters, don’t knock on them. Otherwise, the filters could be contorted and the performance of the dishwasher could be decreased. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 29 Di481 Intergrated Dishwasher Instruction Manual .indd 29 17/07/2020 15:17 17/07/2020 15:17...
  • Page 30 5. Remove the filter at the bottom of the dishwasher and use a sponge to soak up water in the sump. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 30 Di481 Intergrated Dishwasher Instruction Manual .indd 30 17/07/2020 15:17 17/07/2020 15:17...
  • Page 31 Periodic cleaning with a damp sponge will prevent this from occurring. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 31 Di481 Intergrated Dishwasher Instruction Manual .indd 31 17/07/2020 15:17...
  • Page 32 Please check the accompanying installation accessories (fixing for aesthetic door panel). Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 32 Di481 Intergrated Dishwasher Instruction Manual .indd 32 17/07/2020 15:17 17/07/2020 15:17...
  • Page 33 （ ） 20 MAX 8- 2 4- 2 Instruction manual Di481 Please keep this instruction manual for future reference (Unit: mm) should Di481 Intergrated Dishwasher Instruction Manual .indd 33 Di481 Intergrated Dishwasher Instruction Manual .indd 33 17/07/2020 15:17 17/07/2020 15:17...
  • Page 34 ） 20 MAX 8- 2 4- 2 (Unit: mm) (Unit: mm) Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 34 Di481 Intergrated Dishwasher Instruction Manual .indd 34 17/07/2020 15:17 17/07/2020 15:17...
  • Page 35 2. Insert the four long screws Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 35 Di481 Intergrated Dishwasher Instruction Manual .indd 35 17/07/2020 15:17 17/07/2020 15:17...
  • Page 36 1000mm. φ 40mm Drain pipe Instruction manual Di481 Please keep this instruction manual for future reference φ 40mm Di481 Intergrated Dishwasher Instruction Manual .indd 36 Di481 Intergrated Dishwasher Instruction Manual .indd 36 17/07/2020 15:17 17/07/2020 15:17...
  • Page 37 » Marble or granite work top: Fix the side with Screw. (7) Figure 7 Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 37 Di481 Intergrated Dishwasher Instruction Manual .indd 37 17/07/2020 15:17 17/07/2020 15:17...
  • Page 38 , replace the socket, rather than using a adapter as they could cause overheating Please keep this instruction manual for future reference and burns. Di481 Intergrated Dishwasher Instruction Manual .indd 38 Di481 Intergrated Dishwasher Instruction Manual .indd 38 17/07/2020 15:17...
  • Page 39 After installation, please make sure to keep this manual. The content of this manual is very helpful to the users. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 39 Di481 Intergrated Dishwasher Instruction Manual .indd 39 17/07/2020 15:17 17/07/2020 15:17...
  • Page 40 7. All packing materials and printings should be taken out from the dishwasher. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 40 Di481 Intergrated Dishwasher Instruction Manual .indd 40 17/07/2020 15:17...
  • Page 41 The lid of the softer Check the lip. Ensure the fix is fine. is loose Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 41 Di481 Intergrated Dishwasher Instruction Manual .indd 41 17/07/2020 15:17 17/07/2020 15:17...
  • Page 42 Detergent left in Dishes block detergent cups. Re-loading the dishes properly. dispenser cups Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 42 Di481 Intergrated Dishwasher Instruction Manual .indd 42 17/07/2020 15:17 17/07/2020 15:17...
  • Page 43 » If there is water in the base pan because of an overfill or small leak, the water should be removed before restarting the dishwasher. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 43 Di481 Intergrated Dishwasher Instruction Manual .indd 43 17/07/2020 15:17 17/07/2020 15:17...
  • Page 44 9 place settings Power supply: see rating label Capacity: 10 place settings Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 44 Di481 Intergrated Dishwasher Instruction Manual .indd 44 17/07/2020 15:17 17/07/2020 15:17...
  • Page 45 230 V~ / 50 Hz Water pressure (flow pressure) 0.4-10 bar = 0.04-1 MPa Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 45 Di481 Intergrated Dishwasher Instruction Manual .indd 45 17/07/2020 15:17 17/07/2020 15:17...
  • Page 46 The manual is based on the European Union’s standards and rules. Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 46 Di481 Intergrated Dishwasher Instruction Manual .indd 46 17/07/2020 15:17 17/07/2020 15:17...
  • Page 47 N OT E S : Instruction manual Di481 Please keep this instruction manual for future reference Di481 Intergrated Dishwasher Instruction Manual .indd 47 Di481 Intergrated Dishwasher Instruction Manual .indd 47 17/07/2020 15:17 17/07/2020 15:17...
  • Page 48 Caple Service T: 0117 938 1900 Fourth Way E: service@caple.co.uk Avonmouth www.caple.co.uk Bristol BS11 8DW Di481 Intergrated Dishwasher Instruction Manual .indd 48 Di481 Intergrated Dishwasher Instruction Manual .indd 48 17/07/2020 15:17 17/07/2020 15:17...
