Page 1: Operation Manual
SPLIT TYPE ROOM AIR CONDITIONER OPERATION MANUAL HSU-10HM03/R2(DB) HSU-12HM03/R2(DB) HSU-10HT03/R2(DB) HSU-12HT03/R2(DB) Please read this operation manual before using the air conditioner. - Page 2 Damaged air conditioners are not to be put into operation. In case of doubt, consult your supplier. Use of the air conditioner is to be carried out in strict compliance with the relative instructions set forth in the User's Guide.
- Page 3 Cautions Do not obstruct or cover the ventilation grille of the air conditioner. Do not put fingers or any other things into the inlet/outlet and swing louver. Do not allow children to play with the air conditioner. In no case should children be allowed to sit on the outdoor unit.
-
Page 4: Safety Instruction
Installation Please call Sales/Service Shop for the Installation. Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. lnstallation in a inadequate place may cause accidents. Do not install in the following place. - Page 5 Cautions When abnormality such as burnt-small found, immediately stop the operation button and contact sales shop. Connect power supply cord to the outlet completely STRICT ENFORCEMENT Do not use power supply cord in a bundle. PROHIBITION Do not start or stop the operation by disconnecting the power supply cord and so on.
-
Page 6: Parts And Functions
Parts and Functions Indoor unit Signal receiving window Inlet grille Air Purifying Filterr (inside) Vertical louver (Use remote controller to adjust up and down air flow. Donít adjust it manually) Horizontal louver (adjust left and right air flow) Control panel Operation indicator Healthy operation indicator Human sensing indicator... - Page 7 Parts and Functions button(light sensing) It is to set light sensing function, which enables normal operation for strong indoor light (day) or sleeprunning mode for weak indoor light (night). 2.RESET When the remote controller appears abnormal, use a sharp pointed article to press this button to reset the remote controller normal.
- Page 8 Parts and Functions 36. CODE Used to select CODE A or B with a press,A or B will be displayed on LCD. please select A without special explanation NOTE: The following functions and related displays are nto available: CODE and LIGHT. Clock Set When unit is started for the first time and after replacing batteries in remote controller, clock should be adjusted as follows:...
-
Page 9: Health Operation
Remote Controller BRIEF INTRODUCTION TO HEALTH OPERATION The anion generator in the air conditioner can generate a lot of anion to effectively balance the quantity of position and anion in the air and also to kill bacteria and speed up the dust sediment in the room and finally clean the air in the room. -
Page 10: Auto Operation
Remote controller: AUTO Then Select Auto operation 3.Unit stop Press ON/OFF button, the unit stops. About Auto Operation Under the mode of auto operation, air conditioner will automatically select Cool or Heat operation according to room temperature. COOL HEAT... -
Page 11: Cool Operation
Press FAN button. For each press, fan speed changes as follows: Remote controller: Air conditioner is running under dispalyed wind speed. When FAN is set to AUTO, the air conditioner automatically adjusts the fan speed according to room temperature. 5.Unit stop Press ON/OFF button, the unit stops. -
Page 12: Dry Operation
Press FAN button. For each press, fan speed changes as follows: Remote controller: Air conditioner is running under dispalyed wind speed. In DRY mode, when room temperature becomes 2 higher than temp.setting,unit will run intermittently at LOW speed regardless of FAN setting. -
Page 13: Fan Operation
Operation Fan Operation Remote controller 1. Unit start Press ON/OFF on the remote controller, unit starts. 2.Select operation mode Press MODE button. For each press, operation mode changes as follows: Remote controller: AUTO Then Select FAN operation 3.Fan speed selection Press FAN button. -
Page 14: Heat Operation
Operation Heat Operation Remote controller 1. Unit start Press ON/OFF on the remote controller, unit starts. 2.Select operation mode Press MODE button. For each press, operation mode changes as follows: Remote controller: AUTO Then Select HEAT operation 3.Select temp.setting Press TEMP. button Every time the button is pressed, temp.setting increase 1 C,if kept depressed, it will increase rapidly... -
Page 15: Air Flow Direction Adjustment
Operation Air Flow Direction Adjustment 1.Status display of air sending diretion 2.Up and down air flow direction For each press of as follows according to different operation modes: COOL/DRY/FAN remote controller: HEAT remote controller: Pos.5 AUTO Pos.1 remote controller: The vertical flap will swing according to the above positoins 3.Left and right air flow direction For each press of remote controller:... -
Page 16: Sleep Operation
Operation Sleep Operation Before going to bed, you can simply press the SLEEP button and unit will operate in SLEEP mode and bring you a sound sleep. Use of SLEEP function After the unit starts, set the operation status, then press SLEEP button before which the clock must be adjusted and time being set. -
Page 17: Remote Controller
Operation Timer On/Off Operation Remote Controller Hints: After replacing batteries or a power failure happens, time setting should be reset. Remote controller possesses memory function, when use TIMER mode next time, just press SET button after mode selecting if time setting is the same as previous one. Set clock correctly before starting TIMER operation. -
Page 18: Timer On-Off Operation
Operation Timer On-Off Operation Remote Controller Set clock correctly before starting TIMER operation. 1. After unit starts, select your desired operation mode Operation mode will be displayed on LCD. 2. Timer mode selection Press TIMER button to change TIMER mode. Every time the button is pressed, display changes as follows: Remote controller: TIMER ON... -
Page 19: Power/Soft Operation
Operation POWER/SOFT Operation POWER Operation Remote Controller When you need rapid heating or cooling, you can use this function. Selecting of POWER operation Press POWER/SOFT button. Every time the button is pressed,display changes as follows: Stop the display at " In POWER operation status: In HEAT or COOL mode, fan speed automatically runs in HI mode for 15 min then returns to original status setting. -
Page 20: Health Airflow Operation
3.In cooling, it is better to select the mode. 4.In cooling and dry, using the air conditioner for a long time under the high air humidity, a phenomenon falling drips of water occurs at the outlet grille . 5.Select the appropriate fan direction according to the actual... - Page 21 Operation 1.Unit start After switching on and setting running mode,the LCD screen will display the operating conditions. 2.Selecting natural air function Press and natural air function actuates. Press cancel the displayed symbol of After selecting natural air function, fan speed and left/right air direction are set as AUTO whereas after cancellation thereof, fan speed automatically resumes the status before selecting natural air function.
- Page 22 3.If light sensing and human sensing are both selected, when the photosensor detects ìdarkî, the air conditioner wonít change its running mode even the human sensor detects human activity. 4.The human sensor could detect animals such as dogs and cats as well as heat sources e.g.
- Page 23 : If intelligent operation doesnít meet your desire, e.g. slight human activity couldnít be sensed, it shall be cancelled. About installing position of air conditioner (indoor unit) and sensible zone of human sensor: The dashed area shown in the figure is the sensible zone and the blank area is the dead zone.
-
Page 24: Emergency And Test Operation
Operation Emergency and Test Operation Emergency operation: Use this operation only when the remote controller is defective or lost. When the emergency operation switch is pressed,the" Pi "sound is heard once, which means the start of this operation. In this operation, the system automatically selects the operation modes, cooling or heating, according to the room temperature. -
Page 25: Maintenance
Maintenance For Smart Use of The Air Conditioner Setting of proper room temperature Close doors and windows during operation If the unit is not to be used for a long time, turn off the power supply main switch. Do not block the air inlet... -
Page 26: Air Filter Cleaning
Close the inlet grille. Indoor Body Wipe the air conditioner by using a soft and dry cloth.For serious stains,use a neutral detergent diluted with water.Wring the water out of the cloth before wiping.then wipe off the detergent completely. - Page 27 Maintenance Replancement of Air Purifying Filter 1.Open the lnlet Grille Open the inlet grille by pushing each ends of the inlet grille upward.(use thumbs to push 2.Detach the standard air filter Slide the knob slightly upward to release the filter, then withdraw it. 3.Detach old Air Purifying Filter 4.Attach old Air Purifying Filter Put air purifying filter appliances into the...
-
Page 28: Cleaning The Body
Maintenance To Keep Your Air conditioner in Good Condition after Season. Operate in cooling mode for 2-3 hours. To prevent breeding mold or bad smell, be sure to operate at the desinnated temperature or 30 mode and High speed fan mode for 2-3 hours. -
Page 29: Connecting The Earthing Cable
Maintenance Before Setting in High season Cleaning the standard air filter. Operation without filter may cause troubles.Be sure to attach both right and left filters prior to the operation. Each of them are of different shapes. Connecting the earthing cable. Incomplete earthing may cause an electric shock. -
Page 30: Troubleshooting
When the electric plug is pulled out and reinserted, the protection circuit will work for 3 minutes to protect the air conditioner. During unit operation or at stop, a swishing or gurgling noise may be heard. At first 2-3 minutes after unit start, this noise is more noticeable.
