Install and power up
STEP 1
Install the front camera behind the rear view mirror. Install the rear camera at the top
of the back windshield. Remove any foreign matter and clean and dry the windshield
before installation.
Warning
y Do not install the product in a location where it can obstruct the driver's field
of vision.
Turn off the engine. Open the cover of the microSD card slot, gently push the
card into the slot until it locks into place and close the cover.
To insert the SIM card, remove the bracket from front camera. Then open SIM slot
by using SIM eject tool.
SIM 카드
Note
y DR750X LTE Plus is only compatible with 4G LTE network.
DR750X LTE Plus 13
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for BlackVue DR750X LTE Plus
Summary of Contents for BlackVue DR750X LTE Plus
- Page 1 To insert the SIM card, remove the bracket from front camera. Then open SIM slot by using SIM eject tool. SIM 카드 Note y DR750X LTE Plus is only compatible with 4G LTE network. DR750X LTE Plus 13...
- Page 2 Note y For detailed information about activation of SIM card, please check "SIM activation guide" in the packaging box or visit BlackVue Help Center: https://helpcenter. blackvue.com -> SIM Activation Guide (LTE Series). Peel off the protective film from the double-sided tape and attach the front camera to the windshield behind the rear-view mirror.
- Page 3 Plug the power cord into the cigarette lighter socket and the front camera. Use the pry tool to lift the edges of the windshield trim/molding and tuck in the power cord. Power cord Rear camera connection cable DR750X LTE Plus 15...
- Page 4 Turn on the engine. The BlackVue dashcam will power up and start recording. Video files are stored on the microSD card. Turn off the engine. The dashcam will automatically stop recording and power down. To record in parking mode while the engine is off please install a parking mode kit/battery from the BlackVue Power Magic range of accessories (sold separately).
- Page 5 STEP 2 Playback Playing video files on your smartphone (Android/iOS) Search for the BlackVue app in the Google Play Store or Apple App Store and install it on your smartphone. “Pair” your smartphone with the BlackVue dashcam via Wi-Fi direct.
- Page 6 (v) Open the BlackVue app and select Connect to camera. Select the video file you want to play from the video list. Note y Wi-Fi direct lets you connect your smartphone to your dashcam via Wi-Fi within a range of 10m.
- Page 7 Download BlackVue Viewer program from www.blackvue.com > Support > Downloads and install it on your computer. Run BlackVue Viewer. To play, select a video and click on the play button or double click the selected video. DR750X LTE Plus 19...
- Page 8 Windows/macOS Viewer Note y All images shown are for illustration purpose only. Actual program may differ from images shown. 20 BLACKVUE...
- Page 9 The dashcam's time zone is initially set to (GMT-11). To display the correct time please select your time zone. Using your smartphone (Android/iOS) “Pair” your smartphone with the BlackVue dashcam via Wi-Fi direct (for details see STEP 2 ‘Playing video files on your smartphone’) Open the BlackVue app and select Connect to camera .
- Page 10 (km/h, MPH, off ), LEDs on/off, voice guidance volume, Cloud settings etc. For more information about changing the settings in BlackVue Viewer, please download the manual from www.blackvue.com > Support > Manuals. 22 BLACKVUE...
- Page 11 Register your dashcam with your account (i) In the BlackVue app select Connect to Cloud and login to your account. (ii) Tap Yes to enable push notifications (this setting can be adjusted at any time later). (iii) Press + and then select (iv) Register your camera using one of the following methods: QR Code: Press Scan QR Code and line up the QR Code on your smartphone’s...
- Page 12 Connect your BlackVue dashcam to a Wi-Fi hotspot for Cloud connectivity (i) Make sure your BlackVue dashcam and mobile Wi-Fi hotspot are on. (ii) “Pair” your smartphone with the BlackVue dashcam via Wi-Fi direct (for details see STEP 2 ‘Playing video files on your smartphone’) (iii) Open the BlackVue app.
- Page 13 Up to 3 Wi-Fi hotspot SSIDs can be saved (e.g. home, portable hotspot and work). y The BlackVue DR750X LTE Plus dashcam is not compatible with 5GHz wireless networks. (vi) Go back to the Firmware settings menu, tap and tap Save.
- Page 14 (iii) Open the BlackVue app and select Connect to camera > (iv) Configure the APN settings to activate the SIM card. For detailed information, please check "SIM activation guide" in the packaging box or visit BlackVue Help Center: https://helpcenter.blackvue.com -> SIM Activation Guide (LTE Series).
- Page 15 Note y To use the BlackVue Cloud Service, SIM card must be properly activated for Internet access via LTE network. y When the dashcam is connected to internet, you can use BlackVue Cloud features such as remote Live View and Video playback, Real-time location, push notification, Auto-upload, remote Firmware update etc.
-
Page 16: Tips For Optimal Performance
Download BlackVue Mac Viewer from www.blackvue.com > Support > Downloads and install it on your computer. Insert the microSD card into the microSD card reader and connect the reader to your computer. Launch the copy of BlackVue Viewer that is installed on your computer. Click the Format button and select the microSD card from the list of drives in the left frame. -
Page 17: Customer Support
Customer Support For customer support, manuals and firmware updates please visit www.blackvue.com You can also email a Customer Support expert at cs@pittasoft.com DR750X LTE Plus 29... -
Page 18: Product Specifications
Product specifications: Model Name DR750X LTE Plus Built - in 4G LTE module compatible with nano SIM Front: Bla ck / Width 137.6 mm x Height 43 mm / 159 g Color/Size/Weight Rear: Black / Width 67.4 mm x Height 25 mm / 25 g... - Page 19 (Maximum power consumption is to be less than 100 VA or 8 A). Operation -20 °C − 70 °C (-4 °F − 158 °F) Temperature Storage -20 °C − 70 °C (-4 °F − 158 °F) Temperature DR750X LTE Plus 31...
- Page 20 Software * Windows 7 or higher and Mac OS X Sierra (v10.12) or higher Application BlackVue Application (Android 5.0 or higher, iOS 11 or higher) Others Adaptive Format Free File Management System * STARVIS is a trademark of Sony Corporation.
- Page 21 Notes...
- Page 22 Notes...
-
Page 23: Product Warranty
Product Warranty The term of this product warranty is 1 year from the purchase date. (Accessories such as an External Battery/ microSD Card: 6 Months) We, PittaSoft Co., Ltd., provide the product warranty according to the Consumer Dispute Settlement Regulations (drawn up by the Fair Trade Commission). - Page 24 FCC ID: YCK-DR750XLTEP / IC: 23402-DR750XLTEP Contains FCC ID: XMR201605EC25A / Contains IC: 10224A-201611EC25A Product | Car Dashcam Model Name | DR750X LTE Plus DR750-2CH LTE Manufacturer | Pittasoft Co., Ltd. Address | 4F ABN Tower, 331, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do,...
